控制工具基础案例

1. 阻尼振荡器














      #include <ct/core/core.h>













      int main(int argc, char** argv)













      {












    // a damped oscillator has two states, position and velocity












    const size_t state_dim = ct::core::SecondOrderSystem::STATE_DIM;  // = 2












    // create a state













          ct::core::StateVector<state_dim> x;












    // we initialize it at a point with unit deflection and zero velocity












    x(0) = 1.0;












    x(1) = 0.0;












    // create an oscillator, which is a predefined system in ct_core












    double w_n = 10;












    std::shared_ptr<ct::core::SecondOrderSystem> oscillator(new ct::core::SecondOrderSystem(w_n));












    // create an integrator













          ct::core::Integrator<state_dim> integrator(oscillator);












    // simulate 1000 steps












    double dt = 0.001;













          ct::core::Time t0 = 0.0;












    size_t nSteps = 1000;













          integrator.integrate_n_steps(x, t0, nSteps, dt);












    // print the new state













          std::cout << "state after integration: " << x.transpose() << std::endl;












    return 0;













      }









2. 一个受摩擦力影响的简单质点














      #include <ct/core/core.h> // as usual, include CT













      // create a class that derives from ct::core::System













      class Masspoint : public ct::core::System<2>













      {













      public:













          EIGEN_MAKE_ALIGNED_OPERATOR_NEW

























    static const size_t STATE_DIM = 2;












    // constructor












    Masspoint(double mass, double d) : mass_(mass), d_(d) {}












    // copy constructor












    Masspoint(const Masspoint& other) : mass_(other.mass_), d_(other.d_) {}












    // destructor













          ~Masspoint() = default;












    // clone method for deep copying












    Masspoint* clone() const override













          {












        return new Masspoint(*this);  // calls copy constructor













          }












    // The system dynamics. We override this method which gets called by e.g. the Integrator












    void computeDynamics(const ct::core::StateVector<STATE_DIM>& x,













       const ct::core::Time& t,













       ct::core::StateVector<STATE_DIM>& derivative) override













          {












        // first part of state derivative is the velocity












        derivative(0) = x(1);












        // second part is the acceleration which is caused by damper forces












        derivative(1) = -d_ / mass_ * x(1);













          }













      private:












    double mass_;












    double d_;













      };






















      #include <ct/core/core.h>













      #include <ct/core/examples/Masspoint.h>













      int main(int argc, char** argv)













      {












    // a damped oscillator has two states, position and velocity












    const size_t state_dim = Masspoint::STATE_DIM;  // = 2












    // create a state













          ct::core::StateVector<state_dim> x;












    // we initialize it at 0













          x.setZero();












    // create our mass point instance












    double mass = 1.0;












    double d = 0.01;












    std::shared_ptr<Masspoint> masspoint(new Masspoint(mass, d));












    // create an integrator













          ct::core::Integrator<state_dim> integrator(masspoint);












    // simulate 1000 steps












    double dt = 0.001;













          ct::core::Time t0 = 0.0;












    size_t nSteps = 1000;













          integrator.integrate_n_steps(x, t0, nSteps, dt);












    // print the new state













          std::cout << "state after integration: " << x.transpose() << std::endl;












    return 0;













      }
