K8s 集群高可用master节点Etcd挂掉如何恢复?

举报
山河已无恙 发表于 2024/03/19 01:52:26 2024/03/19
【摘要】 写在前面很常见的集群运维场景，整理分享博文内容为 K8s 集群高可用 master 节点故障如何恢复的过程理解不足小伙伴帮忙指正 不必太纠结于当下，也不必太忧虑未来，当你经历过一些事情的时候，眼前的风景已经和从前不一样了。——村上春树遇到了什么问题今天做实验发现 ，集群其中一个 master 节点上的 etcd 和 apiserver 都挂掉了┌──[root@vms100.liruilon...

写在前面

  • 很常见的集群运维场景，整理分享
  • 博文内容为 K8s 集群高可用 master 节点故障如何恢复的过程
  • 理解不足小伙伴帮忙指正

不必太纠结于当下，也不必太忧虑未来，当你经历过一些事情的时候，眼前的风景已经和从前不一样了。——村上春树

遇到了什么问题

今天做实验发现 ，集群其中一个 master 节点上的 etcd 和 apiserver 都挂掉了

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get nodes
NAME                          STATUS   ROLES           AGE    VERSION
vms100.liruilongs.github.io   Ready    control-plane   415d   v1.25.1
vms101.liruilongs.github.io   Ready    control-plane   415d   v1.25.1
vms102.liruilongs.github.io   Ready    control-plane   415d   v1.25.1
vms103.liruilongs.github.io   Ready    <none>          415d   v1.25.1
vms105.liruilongs.github.io   Ready    <none>          415d   v1.25.1
vms106.liruilongs.github.io   Ready    <none>          415d   v1.25.1
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

vms100.liruilongs.github.io 这个节点 上的 apiserver 和 etcd

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep apiserver
kube-system          kube-apiserver-vms100.liruilongs.github.io            0/1     CrashLoopBackOff   1448 (3m23s ago)   415d   192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms101.liruilongs.github.io            1/1     Running            272 (3h18m ago)    415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms102.liruilongs.github.io            1/1     Running            246 (3h18m ago)    415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep etcd
kube-system          etcd-vms100.liruilongs.github.io                      0/1     CrashLoopBackOff   1244 (3m6s ago)    415d   192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms101.liruilongs.github.io                      1/1     Running            167 (3h18m ago)    415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms102.liruilongs.github.io                      1/1     Running            173 (3h18m ago)    415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>

查看 keepalived 对应的静态Pod运行正常

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep keep
kube-system          keepalived-vms100.liruilongs.github.io                1/1     Running            63 (3h50m ago)    415d   192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          keepalived-vms101.liruilongs.github.io                1/1     Running            54 (3h51m ago)    415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          keepalived-vms102.liruilongs.github.io                1/1     Running            60 (3h51m ago)    415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

所以可能是 etcd 数据不同步，或者什么原因 导致etcd 挂掉了。因为 每个 master 节点的 apiserver 只和 本节点的 etcd 进行 通信(每个 etcd 的写请求会转发到 etcd 的领导节点)，etcd 挂掉，apiserver 无法提供能力，所以也会挂掉。

通过 etcdctl 可以发现 vms100.liruilongs.github.io 上的 etcd 彻底死掉了

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379 \
 --cert="/etc/kubernetes/pki/etcd/server.crt" \
 --key="/etc/kubernetes/pki/etcd/server.key"  \
 --cacert="/etc/kubernetes/pki/etcd/ca.crt" \
 member list -w table
Error: dial tcp 127.0.0.1:2379: connect: connection refused

如何排查

这里我们换一个 etcd 节点 执行 命令

查看 etcd 集群成员

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ssh vms101.liruilongs.github.io
Last login: Sat Mar  2 09:52:01 2024 from 192.168.26.100
┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379 \
 --cert="/etc/kubernetes/pki/etcd/server.crt"  \
 --key="/etc/kubernetes/pki/etcd/server.key" \
  --cacert="/etc/kubernetes/pki/etcd/ca.crt" \
  member list -w table
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|        ID        | STATUS  |            NAME             |         PEER ADDRS          |        CLIENT ADDRS         |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|  ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 |
| 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 |
| b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+

查看节点状态

┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379 \
  --cert="/etc/kubernetes/pki/etcd/server.crt" \
  --key="/etc/kubernetes/pki/etcd/server.key"  \
  --cacert="/etc/kubernetes/pki/etcd/ca.crt" \
   endpoint status --cluster  -w table
Failed to get the status of endpoint https://192.168.26.100:2379 (context deadline exceeded)
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
|          ENDPOINT           |        ID        | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
| https://192.168.26.101:2379 | 70059e836d19883d |   3.5.4 |   88 MB |     false |       603 |   22208417 |
| https://192.168.26.102:2379 | b8cb9f66c2e63b91 |   3.5.4 |   88 MB |      true |       603 |   22208417 |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+

确定 ETCD 节点故障

┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  \
 --cert="/etc/kubernetes/pki/etcd/server.crt"  \
 --key="/etc/kubernetes/pki/etcd/server.key"  \
 --cacert="/etc/kubernetes/pki/etcd/ca.crt" \
 endpoint  health --cluster  -w table
https://192.168.26.101:2379 is healthy: successfully committed proposal: took = 3.753357ms
https://192.168.26.102:2379 is healthy: successfully committed proposal: took = 2.989943ms
https://192.168.26.100:2379 is unhealthy: failed to connect: dial tcp 192.168.26.100:2379: connect: connection refused
Error: unhealthy cluster

查看 etcd 的容器日志

┌──[root@vms100.liruilongs.github.io]-[~]
└─$docker ps -a | grep etcd
0f2f98ebf8c3   a8a176a5d5d6                                        "etcd --advertise-cl…"   4 minutes ago   Exited (2) 4 minutes ago                  k8s_etcd_etcd-vms100.liruilongs.github.io_kube-system_e8c17bb99f9bd8119cdd769556041e18_1252
a4b39d16a753   registry.aliyuncs.com/google_containers/pause:3.8   "/pause"                 4 hours ago     Up 4 hours                                k8s_POD_etcd-vms100.liruilongs.github.io_kube-system_e8c17bb99f9bd8119cdd769556041e18_54
┌──[root@vms100.liruilongs.github.io]-[~]
└─$docker logs 0f2f98ebf8c3
{"level":"info","ts":"2024-03-16T14:46:54.644Z","caller":"etcdmain/etcd.go:73","msg":"Running: ","args":["etcd","--advertise-client-urls=https://192.168.26.100:2379","--cert-file=/etc/kubernetes/pki/etcd/server.crt","--client-cert-auth=true","--data-dir=/var/lib/etcd","--experimental-initial-corrupt-check=true","--experimental-watch-progress-notify-interval=5s","--initial-advertise-peer-urls=https://192.168.26.100:2380","--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380","--key-file=/etc/kubernetes/pki/etcd/server.key","--listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379","--listen-metrics-urls=http://127.0.0.1:2381","--listen-peer-urls=https://192.168.26.100:2380","--name=vms100.liruilongs.github.io","--peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt","--peer-client-cert-auth=true","--peer-key-file=/etc/kubernetes/pki/etcd/peer.key","--peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt","--snapshot-count=10000","--trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt"]}
{"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"etcdmain/etcd.go:116","msg":"server has been already initialized","data-dir":"/var/lib/etcd","dir-type":"member"}
{"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:131","msg":"configuring peer listeners","listen-peer-urls":["https://192.168.26.100:2380"]}
{"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:479","msg":"starting with peer TLS","tls-info":"cert = /etc/kubernetes/pki/etcd/peer.crt, key = /etc/kubernetes/pki/etcd/peer.key, client-cert=, client-key=, trusted-ca = /etc/kubernetes/pki/etcd/ca.crt, client-cert-auth = true, crl-file = ","cipher-suites":[]}
{"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:139","msg":"configuring client listeners","listen-client-urls":["https://127.0.0.1:2379","https://192.168.26.100:2379"]}
{"level":"info","ts":"2024-03-16T14:46:54.645Z","caller":"embed/etcd.go:308","msg":"starting an etcd server","etcd-version":"3.5.4","git-sha":"08407ff76","go-version":"go1.16.15","go-os":"linux","go-arch":"amd64","max-cpu-set":4,"max-cpu-available":4,"member-initialized":true,"name":"vms100.liruilongs.github.io","data-dir":"/var/lib/etcd","wal-dir":"","wal-dir-dedicated":"","member-dir":"/var/lib/etcd/member","force-new-cluster":false,"heartbeat-interval":"100ms","election-timeout":"1s","initial-election-tick-advance":true,"snapshot-count":10000,"snapshot-catchup-entries":5000,"initial-advertise-peer-urls":["https://192.168.26.100:2380"],"listen-peer-urls":["https://192.168.26.100:2380"],"advertise-client-urls":["https://192.168.26.100:2379"],"listen-client-urls":["https://127.0.0.1:2379","https://192.168.26.100:2379"],"listen-metrics-urls":["http://127.0.0.1:2381"],"cors":["*"],"host-whitelist":["*"],"initial-cluster":"","initial-cluster-state":"new","initial-cluster-token":"","quota-size-bytes":2147483648,"pre-vote":true,"initial-corrupt-check":true,"corrupt-check-time-interval":"0s","auto-compaction-mode":"periodic","auto-compaction-retention":"0s","auto-compaction-interval":"0s","discovery-url":"","discovery-proxy":"","downgrade-check-interval":"5s"}
panic: freepages: failed to get all reachable pages (page 7744: multiple references)

goroutine 109 [running]:
go.etcd.io/bbolt.(*DB).freepages.func2(0xc00009c480)
        /go/pkg/mod/go.etcd.io/bbolt@v1.3.6/db.go:1056 +0xe9
created by go.etcd.io/bbolt.(*DB).freepages
        /go/pkg/mod/go.etcd.io/bbolt@v1.3.6/db.go:1054 +0x1cd
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

如何解决

这里最快的办法是重新同步一下这个节点的数据，即把这个故障节点移出 集群，清理完故障节点旧数据在重新添加，操作步骤

  • 清理数据目录，移动静态Pod 的yaml 文件：停止故障节点服务，然后删除etcd数据目录。
  • 移除故障节点：使用member remove命令剔除错误节点,可以在健康的节点执行命令。
  • 添加节点：使用member add命令添加故障节点。
  • 重新启动：移动故障节点yaml文件，进行启动

注: 静态Pod 通过加载指定目录的 yaml 文件来调度，kubelet 会定时扫描，删除移动 yaml 文件，静态 Pod 会自动停止,同理。添加 yaml 文件会自动创建静态 Pod

移动静态Pod 的yaml 文件

┌──[root@vms100.liruilongs.github.io]-[~]
└─$mv  /etc/kubernetes/manifests/{etcd.yaml,kube-apiserver.yaml}  /tmp/

删除etcd数据目录

┌──[root@vms100.liruilongs.github.io]-[~]
└─$rm -rf /var/lib/etcd/*

确认节点 的 etcd 和 apiservier 都已经停止

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep apiserver
kube-system          kube-apiserver-vms101.liruilongs.github.io            1/1     Running   272 (4h15m ago)   415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms102.liruilongs.github.io            1/1     Running   246 (4h15m ago)   415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep etcd
kube-system          etcd-vms101.liruilongs.github.io                      1/1     Running   167 (4h15m ago)   415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms102.liruilongs.github.io                      1/1     Running   173 (4h15m ago)   415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

获取故障节点 ID,下面的操作我们在健康的 etcd 节点执行，或者可以修改 --endpoints

┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://192.168.26.101:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|        ID        | STATUS  |            NAME             |         PEER ADDRS          |        CLIENT ADDRS         |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|  ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 |
| 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 |
| b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+

移除故障节点

┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt"  member remove ee392e5273e89e2
Member  ee392e5273e89e2 removed from cluster 4816f346663d82a7

重新添加

┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt"  member add vms100.liruilongs.github.io --peer-urls=https://192.168.26.100:2380
Member 456f71fdc1ad9917 added to cluster 4816f346663d82a7

ETCD_NAME="vms100.liruilongs.github.io"
ETCD_INITIAL_CLUSTER="vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380"
ETCD_INITIAL_ADVERTISE_PEER_URLS="https://192.168.26.100:2380"
ETCD_INITIAL_CLUSTER_STATE="existing"

回到 100 节点机器,移动 Yaml 文件，恢复节点

┌──[root@vms100.liruilongs.github.io]-[~]
└─$mv /tmp/{etcd.yaml,kube-apiserver.yaml} /etc/kubernetes/manifests/

确认 Pod 状态

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep etcd
kube-system          etcd-vms100.liruilongs.github.io                      1/1     Running   0                 16s    192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms101.liruilongs.github.io                      1/1     Running   167 (4h32m ago)   415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms102.liruilongs.github.io                      1/1     Running   173 (4h32m ago)   415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep apiserver
kube-system          kube-apiserver-vms100.liruilongs.github.io            1/1     Running   0                 24s    192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms101.liruilongs.github.io            1/1     Running   272 (4h32m ago)   415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms102.liruilongs.github.io            1/1     Running   246 (4h32m ago)   415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

查看 etcd 集群状态

┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table
+------------------+-----------+-----------------------------+-----------------------------+-----------------------------+
|        ID        |  STATUS   |            NAME             |         PEER ADDRS          |        CLIENT ADDRS         |
+------------------+-----------+-----------------------------+-----------------------------+-----------------------------+
| 54952f3b494c0286 | unstarted |                             | https://192.168.26.100:2380 |                             |
| 70059e836d19883d |   started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 |
| b8cb9f66c2e63b91 |   started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 |
+------------------+-----------+-----------------------------+-----------------------------+-----------------------------+

这里我们发现 新添加的节点状态不正常，一直是 unstarted

我们在 故障节点执行 etcd 命令。发现故障节点并没有添加到集群，而是作为一个单节点运行。

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table
+-----------------+---------+-----------------------------+-----------------------------+-----------------------------+
|       ID        | STATUS  |            NAME             |         PEER ADDRS          |        CLIENT ADDRS         |
+-----------------+---------+-----------------------------+-----------------------------+-----------------------------+
| ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 |
+-----------------+---------+-----------------------------+-----------------------------+-----------------------------+
┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster  -w table
+-----------------------------+-----------------+---------+---------+-----------+-----------+------------+
|          ENDPOINT           |       ID        | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX |
+-----------------------------+-----------------+---------+---------+-----------+-----------+------------+
| https://192.168.26.100:2379 | ee392e5273e89e2 |   3.5.4 |  815 kB |      true |         2 |       2261 |
+-----------------------------+-----------------+---------+---------+-----------+-----------+------------+
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

也没有同步 当前集群的数据

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide  --server=https://vms100.liruilongs.github.io:6443
No resources found

遇到这种情况，大部分原因是 某个节点的 etcd配置文件的问题，我的这个问题是 故障节点的 etcd 配置文件，没有集群信息相关配置，所以这里把集群相关配置写入配置

原本的配置文件

┌──[root@vms100.liruilongs.github.io]-[~]
└─$cat /etc/kubernetes/manifests/etcd.yaml
apiVersion: v1
kind: Pod
metadata:
  annotations:
    kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.26.100:2379
  creationTimestamp: null
  labels:
    component: etcd
    tier: control-plane
  name: etcd
  namespace: kube-system
spec:
  containers:
  - command:
    - etcd
    - --advertise-client-urls=https://192.168.26.100:2379
    - --cert-file=/etc/kubernetes/pki/etcd/server.crt
    - --client-cert-auth=true
    - --data-dir=/var/lib/etcd
    - --experimental-initial-corrupt-check=true
    - --experimental-watch-progress-notify-interval=5s
    - --initial-advertise-peer-urls=https://192.168.26.100:2380
    - --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380
    - --key-file=/etc/kubernetes/pki/etcd/server.key
    - --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379
    - --listen-metrics-urls=http://127.0.0.1:2381
    - --listen-peer-urls=https://192.168.26.100:2380
    - --name=vms100.liruilongs.github.io
    - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
    - --peer-client-cert-auth=true
    - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
    - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
    - --snapshot-count=10000
    - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
    image: registry.aliyuncs.com/google_containers/etcd:3.5.4-0
。。。。。。。。。。。。。。。。

集群信息不全的，添加后的配置文件

┌──[root@vms100.liruilongs.github.io]-[~]
└─$cat /etc/kubernetes/manifests/etcd.yaml
apiVersion: v1
kind: Pod
metadata:
  annotations:
    kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.26.100:2379
  creationTimestamp: null
  labels:
    component: etcd
    tier: control-plane
  name: etcd
  namespace: kube-system
spec:
  containers:
  - command:
    - etcd
    - --advertise-client-urls=https://192.168.26.100:2379
    - --cert-file=/etc/kubernetes/pki/etcd/server.crt
    - --client-cert-auth=true
    - --data-dir=/var/lib/etcd
    - --experimental-initial-corrupt-check=true
    - --experimental-watch-progress-notify-interval=5s
    - --initial-advertise-peer-urls=https://192.168.26.100:2380
    - --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380
    - --initial-cluster-state=existing
    - --key-file=/etc/kubernetes/pki/etcd/server.key
    - --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379
    - --listen-metrics-urls=http://127.0.0.1:2381
    - --listen-peer-urls=https://192.168.26.100:2380
    - --name=vms100.liruilongs.github.io
    - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
    - --peer-client-cert-auth=true
    - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
    - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
    - --snapshot-count=10000
    - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt

然后我们以上面相同的方式从新恢复一次，发现节点直接没有起来

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep apiserver
kube-system          kube-apiserver-vms100.liruilongs.github.io            0/1     CrashLoopBackOff   1 (18s ago)       39s    192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms101.liruilongs.github.io            1/1     Running            272 (5h29m ago)   415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          kube-apiserver-vms102.liruilongs.github.io            1/1     Running            246 (5h29m ago)   415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>
┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl get pod -A -o wide | grep etcd
kube-system          etcd-vms100.liruilongs.github.io                      0/1     CrashLoopBackOff   3 (21s ago)       53s    192.168.26.100   vms100.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms101.liruilongs.github.io                      1/1     Running            167 (5h29m ago)   415d   192.168.26.101   vms101.liruilongs.github.io   <none>           <none>
kube-system          etcd-vms102.liruilongs.github.io                      1/1     Running            173 (5h29m ago)   415d   192.168.26.102   vms102.liruilongs.github.io   <none>           <none>

查看日志

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl logs etcd-vms100.liruilongs.github.io -n kube-system
.............................
{"level":"fatal","ts":"2024-03-16T16:25:19.981Z","caller":"etcdmain/etcd.go:204","msg":"discovery failed","error":"error validating peerURLs {ClusterID:4816f346663d82a7 Members:[&{ID:b8cb9f66c2e63b91 RaftAttributes:{PeerURLs:[https://192.168.26.102:2380] IsLearner:false} Attributes:{Name:vms102.liruilongs.github.io ClientURLs:[https://192.168.26.102:2379]}} &{ID:3fbbbed942c51f7b RaftAttributes:{PeerURLs:[https://192.168.26.100:2380] IsLearner:false} Attributes:{Name: ClientURLs:[]}} &{ID:70059e836d19883d RaftAttributes:{PeerURLs:[https://192.168.26.101:2380] IsLearner:false} Attributes:{Name:vms101.liruilongs.github.io ClientURLs:[https://192.168.26.101:2379]}}] RemovedMemberIDs:[]}: member count is unequal","stacktrace":"go.etcd.io/etcd/server/v3/etcdmain.startEtcdOrProxyV2\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/etcd.go:204\ngo.etcd.io/etcd/server/v3/etcdmain.Main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/main.go:40\nmain.main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/main.go:32\nruntime.main\n\t/go/gos/go1.16.15/src/runtime/proc.go:225"}

根据日志信息，可以看到有用的信息 RemovedMemberIDs:[]}: member count is unequal ,成员数量不相等,在分析日志

{
    "level": "info",
    "ts": "2024-03-16T16:25:19.961Z",
    "caller": "etcdmain/etcd.go:73",
    "msg": "Running: ",
    "args": [
        "etcd",
        "--advertise-client-urls=https://192.168.26.100:2379",
        "--cert-file=/etc/kubernetes/pki/etcd/server.crt",
        "--client-cert-auth=true",
        "--data-dir=/var/lib/etcd",
        "--experimental-initial-corrupt-check=true",
        "--experimental-watch-progress-notify-interval=5s",
        "--initial-advertise-peer-urls=https://192.168.26.100:2380",
        "--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380",
        "--initial-cluster-state=existing",
        "--key-file=/etc/kubernetes/pki/etcd/server.key",
        "--listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379",
        "--listen-metrics-urls=http://127.0.0.1:2381",
        "--listen-peer-urls=https://192.168.26.100:2380",
        "--name=vms100.liruilongs.github.io",
        "--peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt",
        "--peer-client-cert-auth=true",
        "--peer-key-file=/etc/kubernetes/pki/etcd/peer.key",
        "--peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt",
        "--snapshot-count=10000",
        "--trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt"
    ]
}
..............................................................................
{
    "level": "warn",
    "ts": "2024-03-16T16:25:19.981Z",
    "caller": "etcdmain/etcd.go:146",
    "msg": "failed to start etcd",
    "error": "error validating peerURLs {ClusterID:4816f346663d82a7 Members:[&{ID:b8cb9f66c2e63b91 RaftAttributes:{PeerURLs:[https://192.168.26.102:2380] IsLearner:false} Attributes:{Name:vms102.liruilongs.github.io ClientURLs:[https://192.168.26.102:2379]}} &{ID:3fbbbed942c51f7b RaftAttributes:{PeerURLs:[https://192.168.26.100:2380] IsLearner:false} Attributes:{Name: ClientURLs:[]}} &{ID:70059e836d19883d RaftAttributes:{PeerURLs:[https://192.168.26.101:2380] IsLearner:false} Attributes:{Name:vms101.liruilongs.github.io ClientURLs:[https://192.168.26.101:2379]}}] RemovedMemberIDs:[]}: member count is unequal"
}
{
    "level": "fatal",
    "ts": "2024-03-16T16:25:19.981Z",
    "caller": "etcdmain/etcd.go:204",
    "msg": "discovery failed",
    "error": "error validating peerURLs {ClusterID:4816f346663d82a7 Members:[&{ID:b8cb9f66c2e63b91 RaftAttributes:{PeerURLs:[https://192.168.26.102:2380] IsLearner:false} Attributes:{Name:vms102.liruilongs.github.io ClientURLs:[https://192.168.26.102:2379]}} &{ID:3fbbbed942c51f7b RaftAttributes:{PeerURLs:[https://192.168.26.100:2380] IsLearner:false} Attributes:{Name: ClientURLs:[]}} &{ID:70059e836d19883d RaftAttributes:{PeerURLs:[https://192.168.26.101:2380] IsLearner:false} Attributes:{Name:vms101.liruilongs.github.io ClientURLs:[https://192.168.26.101:2379]}}] RemovedMemberIDs:[]}: member count is unequal",
    "stacktrace": "go.etcd.io/etcd/server/v3/etcdmain.startEtcdOrProxyV2\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/etcd.go:204\ngo.etcd.io/etcd/server/v3/etcdmain.Main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/etcdmain/main.go:40\nmain.main\n\t/go/src/go.etcd.io/etcd/release/etcd/server/main.go:32\nruntime.main\n\t/go/gos/go1.16.15/src/runtime/proc.go:225"
}

可以看到它提示 可能错误与 vms102.liruilongs.github.io 节点相关

然后我们看一下 vms102.liruilongs.github.io 的配置文件

┌──[root@vms102.liruilongs.github.io]-[~]
└─$cat /etc/kubernetes/manifests/etcd.yaml
apiVersion: v1
kind: Pod
metadata:
  annotations:
    kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.26.102:2379
  creationTimestamp: null
  labels:
    component: etcd
    tier: control-plane
  name: etcd
  namespace: kube-system
spec:
  containers:
  - command:
    - etcd
    - --advertise-client-urls=https://192.168.26.102:2379
    - --cert-file=/etc/kubernetes/pki/etcd/server.crt
    - --client-cert-auth=true
    - --data-dir=/var/lib/etcd
    - --experimental-initial-corrupt-check=true
    - --experimental-watch-progress-notify-interval=5s
    - --initial-advertise-peer-urls=https://192.168.26.102:2380
    - --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380
    - --initial-cluster-state=existing
    - --key-file=/etc/kubernetes/pki/etcd/server.key
    - --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.102:2379
    - --listen-metrics-urls=http://127.0.0.1:2381
    - --listen-peer-urls=https://192.168.26.102:2380
    - --name=vms102.liruilongs.github.io
    - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
    - --peer-client-cert-auth=true
    - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
    - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
    - --snapshot-count=10000
    - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt

通过配置文件比对，可以发现，之前配置的故障节点的配置任然有问题，少了一个vms102.liruilongs.github.io=https://192.168.26.102:2380节点信息。

"--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380",
"--initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380"

修改完配置，按照上面相同的流程重新恢复节点， 节点恢复

通过 etcdctl 命令检查

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|        ID        | STATUS  |            NAME             |         PEER ADDRS          |        CLIENT ADDRS         |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
| 70059e836d19883d | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 |
| ac5f6045dbe477b3 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 |
| b8cb9f66c2e63b91 | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster  -w table
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
|          ENDPOINT           |        ID        | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
| https://192.168.26.101:2379 | 70059e836d19883d |   3.5.4 |   88 MB |     false |       603 |   22227327 |
| https://192.168.26.100:2379 | ac5f6045dbe477b3 |   3.5.4 |   88 MB |     false |       603 |   22227327 |
| https://192.168.26.102:2379 | b8cb9f66c2e63b91 |   3.5.4 |   88 MB |      true |       603 |   22227327 |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

故障节点恢复，在实际的操作中，添加完节点，我们需要确认故障节点的配置文件是否是正确的配置文件

© 2018-2024 liruilonger@gmail.com, All rights reserved. 保持署名-非商用-相同方式共享(CC BY-NC-SA 4.0)

【版权声明】本文为华为云社区用户原创内容，转载时必须标注文章的来源（华为云社区）、文章链接、文章作者等基本信息， 否则作者和本社区有权追究责任。如果您发现本社区中有涉嫌抄袭的内容，欢迎发送邮件进行举报，并提供相关证据，一经查实，本社区将立刻删除涉嫌侵权内容，举报邮箱： cloudbbs@huaweicloud.com
Kubernetes
  • 点赞
  • 收藏
  • 关注作者

评论（0）

0/1000
抱歉，系统识别当前为高风险访问，暂不支持该操作

全部回复

上滑加载中

设置昵称

在此一键设置昵称，即可参与社区互动！

*长度不超过10个汉字或20个英文字符，设置后3个月内不可修改。

*长度不超过10个汉字或20个英文字符，设置后3个月内不可修改。

确认 取消

加入云驻计划，成为创作者

  • 华为云周边好礼
  • 免费体验产品
  • 特殊身份标识
  • 线下官方门票
  • 内部专家零距离
  • 与10000+优质创作者共同成长
立即加入
