一、背景

      用户在产品优化迭代时直接将新版本上线发布，一旦遇到线上事故或BUG，影响极大，解决问题周期较长，甚至有时不得不回滚到前一版本，严重影响了使用体验。同时也存在多个服务同时有新版本进行发布，新版本之间要求流量匹配。这时我们可以通过istio进行灰度流量控制。

二、全链路灰度发布以及sourceLabel功能原理

    当前集群中，多个微服务，每个微服务都有多个版本，如果能做到流量传递只会发生在同版本的服务之间，就能做到全链路的灰度发布。如下图所示，在入口网关流量按照权重分配到appa的v1版本和v2版本后，appa的v1版本pod访问appb业务时，只会访问appb的v1版本；而appa的v2版本pod访问appb业务时，只会访问appb的v2版本。

   我们可以利用virtualService中的sourceLabels能力对源负载进行标签匹配，如下virtualService配置说明，如果源pod label为 app:appa & subset: v1(即上图的appa-v1)访问appb service，则转发给 host:appb & subnet:v1 对应的endpoint（即上图的appb-v1）

apiVersion: networking.istio.io/v1beta1
kind: VirtualService
metadata:
  name: vs-appb
spec:
  hosts:
    - appb
  http:
    - route:
        - destination:
            host: appb
            subset: v1
      match:
        - sourceLabels:   # 关键配置，用于规定源Pod为appa-v1访问appb对应的转发后端
            app: appa
            version: v1
    - route:
        - destination:
            host: appb
            subset: v2
      match:
        - sourceLabels:   # 关键配置，用于规定源Pod为appa-v2访问appb对应的转发后端
            app: appa
            version: v2
    - route:
        - destination:     # 默认规则，用于规定其他源Pod访问appb对应的转发后端
            host: appb
            subset: v1

     该virtualService创建后，会作用到所有的envoy上（包括appa-v1和appa-v2），当业务访问appb clusterip或者域名后，对应的envoy就会拦截业务流量，根据virtualService、destinationRule规则判断进行后端选择。

三、操作示例

3.1  部署deployment、service

     部署appa的v1和v2版本、app2的v1和v2版本和appa、appb对应的service

apiVersion: v1
kind: Service
metadata:
  name: appa
  labels:
    app: appa
    service: appa
spec:
  ports:
  - port: 8000
    name: http
  selector:
    app: appa
---
apiVersion: v1
kind: Service
metadata:
  name: appb
  labels:
    app: appb
    service: appb
spec:
  ports:
  - port: 8000
    name: http
  selector:
    app: appb
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: appa-v1
  labels:
    app: appa
    version: v1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: appa
      version: v1
  template:
    metadata:
      labels:
        app: appa
        version: v1
    spec:
      imagePullSecrets:
        - name: default-secret
      containers:
      - name: default
        image: swr.cn-north-4.myhuaweicloud.com/k8s-solution/go-http-sample:1.0
        imagePullPolicy: IfNotPresent
        env:
        - name: version
          value: v1
        - name: app
          value: appa
        - name: upstream_url
          value: "http://appb:8000/"
        ports:
        - containerPort: 8000
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: appb-v1
  labels:
    app: appb
    version: v1
spec:
  replicas: 1
  selector:
    matchLabels:
      app: appb
      version: v1
  template:
    metadata:
      labels:
        app: appb
        version: v1
    spec:
      imagePullSecrets:
        - name: default-secret
      containers:
      - name: default
        image: swr.cn-north-4.myhuaweicloud.com/k8s-solution/go-http-sample:1.0
        imagePullPolicy: IfNotPresent
        env:
        - name: version
          value: v1
        - name: app
          value: appb
        ports:
        - containerPort: 8000

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: appa-v2
  labels:
    app: appa
    version: v2
spec:
  replicas: 1
  selector:
    matchLabels:
      app: appa
      version: v2
  template:
    metadata:
      labels:
        app: appa
        version: v2
    spec:
      imagePullSecrets:
        - name: default-secret
      containers:
      - name: default
        image: swr.cn-north-4.myhuaweicloud.com/k8s-solution/go-http-sample:1.0
        imagePullPolicy: IfNotPresent
        env:
        - name: version
          value: v2
        - name: app
          value: appa
        - name: upstream_url
          value: "http://appb:8000/"
        ports:
        - containerPort: 8000
---

apiVersion: apps/v1
kind: Deployment
metadata:
  name: appb-v2
  labels:
    app: appb
    version: v2
spec:
  replicas: 1
  selector:
    matchLabels:
      app: appb
      version: v2
  template:
    metadata:
      labels:
        app: appb
        version: v2
    spec:
      imagePullSecrets:
        - name: default-secret
      containers:
      - name: default
        image: swr.cn-north-4.myhuaweicloud.com/k8s-solution/go-http-sample:1.0
        imagePullPolicy: IfNotPresent
        env:
        - name: version
          value: v2
        - name: app
          value: appb
        ports:
        - containerPort: 8000

3.2 打通入口gateway按比例转发到appa的v1和v2版本

       gateway到appa可以按照比例，也可以按照head信息等，由于本文重点表述sourceLabels能力，不做详细说明。

apiVersion: networking.istio.io/v1beta1
kind: DestinationRule
metadata:
  name: dr-appa
spec:
  host: appa
  trafficPolicy:
    loadBalancer:
      simple: ROUND_ROBIN
  subsets:
    - labels:
        version: v1
      name: v1
    - labels:
        version: v2
      name: v2
---
apiVersion: networking.istio.io/v1beta1
kind: VirtualService
metadata:
  name: vs-gateway-appa
  namespace: istio-system
spec:
  gateways:
  - istio-system/app-gw
  - mesh
  hosts:
    - 192.168.1.106
    - appa.default.svc.cluster.local
  http:
  - delegate:
      name: vs-appa
      namespace: default
    match:
      - uri:
          prefix: /

---
apiVersion: networking.istio.io/v1beta1
kind: VirtualService
metadata:
  name: vs-appa
spec:

  http:
  - match:
      - gateways:
        - istio-system/app-gw
    route:
      - destination:
          host: appa
          subset: v1
        weight: 10
      - destination:
          host: appa
          subset: v2
        weight: 90
  - match:
      - gateways:
        - mesh
    route:
      - destination:
          host: appa
          subset: v1
        weight: 100
      - destination:
          host: appa
          subset: v2
        weight: 0

3.3 通过sourceLabels控制源Pod，使得不同label源Pod定向访问后端

apiVersion: networking.istio.io/v1beta1
kind: DestinationRule
metadata:
  name: dr-appb
spec:
  host: appb
  trafficPolicy:
    loadBalancer:
      simple: ROUND_ROBIN
  subsets:
    - labels:
        version: v1
      name: v1
    - labels:
        version: v2
      name: v2
---
apiVersion: networking.istio.io/v1beta1
kind: VirtualService
metadata:
  name: vs-appb
spec:
  hosts:
    - appb
  http:
    - route:
        - destination:
            host: appb
            subset: v1
      match:
        - sourceLabels:
            app: appa
            version: v1
    - route:
        - destination:
            host: appb
            subset: v2
      match:
        - sourceLabels:
            app: appa
            version: v2
     - route:
         - destination:
           host: appb
           subset: v1

3.4  测试验证

   访问入口网关gateway ip，while true;do curl http://gatewayip:86/;sleep 1;echo "";done   可以回显appa 和 appb的响应通道

    从上图可见，appa v2的pod 访问appb ，只会访问appb的v2 ，appa v1的pod访问appb，只会访问appb的v1，实现了全链路的灰度发布。

四、优缺点分析

• 优点：在开源istio的基础上，可以借助原生的sourceLabels进行治理，实现全链路的流量拓扑。配置简单明了，四层流量七层流量均可使用sourceLables进行路由匹配
• 缺点：当多个微服务多版本上线时，访问链路中某个微服务只有一个版本，下游流量汇聚到该服务后，该服务发出的流量不再携带多版本的labels，则流量标记会被清除

        如果我们强行将appc部署成两个服务appc-v1和appc-v2，提供相同的能力，也可以继续使用sourceLabels全链路。
