关于k8s中ETCD集群备份灾难恢复的一些笔记

山河已无恙发表于 2023/03/03 15:17:46 2023/03/03

【摘要】写在前面集群电源不稳定，或者节点动不动就宕机,一定要做好备份，ETCD 的快照文件很容易受影响损坏。重置了很多次集群，才认识到备份的重要博文内容涉及etcd 运维基础知识了解静态 Pod 方式 etcd 集群灾备与恢复 Demo定时备份的任务编写二进制 etcd 集群灾备恢复 Demo理解不足小伙伴帮忙指正我所渴求的，無非是將心中脫穎語出的本性付諸生活，為何竟如此艱難呢 ------赫尔...

写在前面

集群电源不稳定，或者节点动不动就宕机,一定要做好备份，ETCD 的快照文件很容易受影响损坏。
重置了很多次集群，才认识到备份的重要
博文内容涉及
- etcd 运维基础知识了解
- 静态 Pod 方式 etcd 集群灾备与恢复 Demo
- 定时备份的任务编写
- 二进制 etcd 集群灾备恢复 Demo
理解不足小伙伴帮忙指正

我所渴求的，無非是將心中脫穎語出的本性付諸生活，為何竟如此艱難呢 ------赫尔曼·黑塞《德米安》

etcd 概述

etcd 是 CoreOS团队于2013年6月发起的开源项目，它的目标是构建一个高可用的分布式键值(key-value)数据库。

etcd 内部采用 raft 协议作为一致性算法，etcd基于Go语言实现。

完全复制：集群中的每个节点都可以使用完整的存档
高可用性：Etcd可用于避免硬件的单点故障或网络问题
一致性：每次读取都会返回跨多主机的最新写入
简单：包括一个定义良好、面向用户的API(gRPC)
安全：实现了带有可选的客户端证书身份验证的自动化TLS
快速：每秒10000次写入的基准速度
可靠：使用Raft算法实现了强一致、高可用的服务存储目录

ETCD 集群运维相关的基本知识：

读写端口为： 2379，数据同步端口： 2380
ETCD集群是一个分布式系统,使用Raft协议来维护集群内各个节点状态的一致性。
主机状态 Leader, Follower, Candidate
当集群初始化时候，每个节点都是Follower角色，通过心跳与其他节点同步数据
通过Follower读取数据，通过Leader写入数据
当Follower在一定时间内没有收到来自主节点的心跳，会将自己角色改变为Candidate，并发起一次选主投票
配置etcd集群，建议尽可能是奇数个节点，而不要偶数个节点,推荐的数量为 3、5 或者 7 个节点构成一个集群。
使用 etcd 的内置备份/恢复工具从源部署备份数据并在新部署中恢复数据。恢复前需要清理数据目录
数据目录下 snap: 存放快照数据,etcd防止WAL文件过多而设置的快照，存储etcd数据状态。
数据目录下 wal: 存放预写式日志,最大的作用是记录了整个数据变化的全部历程。在etcd中，所有数据的修改在提交前，都要先写入到WAL中。
一个 etcd 集群可能不应超过七个节点,写入性能会受影响，建议运行五个节点。一个 5 成员的 etcd 集群可以容忍两个成员故障，三个成员可以容忍1个故障。

常用配置参数：

ETCD_NAME 节点名称，默认为defaul
ETCD_DATA_DIR 服务运行数据保存的路
ETCD_LISTEN_PEER_URLS 监听的同伴通信的地址，比如http://ip:2380，如果有多个，使用逗号分隔。需要所有节点都能够访问，所以不要使用 localhost
ETCD_LISTEN_CLIENT_URLS 监听的客户端服务地址
ETCD_ADVERTISE_CLIENT_URLS 对外公告的该节点客户端监听地址，这个值会告诉集群中其他节点
ETCD_INITIAL_ADVERTISE_PEER_URLS 对外公告的该节点同伴监听地址，这个值会告诉集群中其他节
ETCD_INITIAL_CLUSTER 集群中所有节点的信息
ETCD_INITIAL_CLUSTER_STATE 新建集群的时候，这个值为 new；假如加入已经存在的集群，这个值为existing
ETCD_INITIAL_CLUSTER_TOKEN 集群的ID，多个集群的时候，每个集群的ID必须保持唯一

静态 Pod方式集群备份恢复

单节点ETCD备份恢复

如果 etcd 为单节点部署，可以直接 物理备份，直接备份对应的数据文件目录即可，恢复 的话可以直接把备份的 etcd 数据目录复制到 etcd 指定的目录。恢复完成需要恢复 /etc/kubernetes/manifests 内 etcd.yaml 文件原来的状态。

也可以基于快照进行备份

备份命令

┌──[root@vms81.liruilongs.github.io]-[/backup_20230127]
└─$ETCDCTL_API=3 etcdctl --endpoints="https://127.0.0.1:2379" \
 --cert="/etc/kubernetes/pki/etcd/server.crt"  \
 --key="/etc/kubernetes/pki/etcd/server.key"  \
 --cacert="/etc/kubernetes/pki/etcd/ca.crt"
snapshot save snap-$(date +%Y%m%d%H%M).db
Snapshot saved at snap-202301272133.db

恢复命令

┌──[root@vms81.liruilongs.github.io]-[/backup_20230127]
└─$ETCDCTL_API=3 etcdctl snapshot restore ./snap-202301272133.db \
 --name vms81.liruilongs.github.io  \
 --cert="/etc/kubernetes/pki/etcd/server.crt"  \
 --key="/etc/kubernetes/pki/etcd/server.key"  \
 --cacert="/etc/kubernetes/pki/etcd/ca.crt" \
 --initial-advertise-peer-urls=https://192.168.26.81:2380  \
 --initial-cluster="vms81.liruilongs.github.io=https://192.168.26.81:2380"  \
 --data-dir=/var/lib/etcd
2023-01-27 21:40:01.193420 I | mvcc: restore compact to 484325
2023-01-27 21:40:01.199682 I | etcdserver/membership: added member cbf506fa2d16c7 [https://192.168.26.81:2380] to cluster 46c9df5da345274b
┌──[root@vms81.liruilongs.github.io]-[/backup_20230127]
└─$

具体对应的参数值，可以通过 etcd 静态 pod 的 yaml 文件获取

┌──[root@vms81.liruilongs.github.io]-[/var/lib/etcd/member]
└─$kubectl describe  pods etcd-vms81.liruilongs.github.io | grep -e "--"
      --advertise-client-urls=https://192.168.26.81:2379
      --cert-file=/etc/kubernetes/pki/etcd/server.crt
      --client-cert-auth=true
      --data-dir=/var/lib/etcd
      --initial-advertise-peer-urls=https://192.168.26.81:2380
      --initial-cluster=vms81.liruilongs.github.io=https://192.168.26.81:2380
      --key-file=/etc/kubernetes/pki/etcd/server.key
      --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.81:2379
      --listen-metrics-urls=http://127.0.0.1:2381
      --listen-peer-urls=https://192.168.26.81:2380
      --name=vms81.liruilongs.github.io
      --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
      --peer-client-cert-auth=true
      --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
      --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
      --snapshot-count=10000
      --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
┌──[root@vms81.liruilongs.github.io]-[/var/lib/etcd/member]
└─$

集群ETCD备份恢复

集群节点状态

┌──[root@vms100.liruilongs.github.io]-[~/ansible/helm]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" member list -w table
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|        ID        | STATUS  |            NAME             |         PEER ADDRS          |        CLIENT ADDRS         |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
|  ee392e5273e89e2 | started | vms100.liruilongs.github.io | https://192.168.26.100:2380 | https://192.168.26.100:2379 |
| 11486647d7f3a17b | started | vms102.liruilongs.github.io | https://192.168.26.102:2380 | https://192.168.26.102:2379 |
| e00e3877df8f76f4 | started | vms101.liruilongs.github.io | https://192.168.26.101:2380 | https://192.168.26.101:2379 |
+------------------+---------+-----------------------------+-----------------------------+-----------------------------+
┌──[root@vms100.liruilongs.github.io]-[~/ansible/helm]

version 及 leader 信息。

┌──[root@vms100.liruilongs.github.io]-[~/ansible/kubescape]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster  -w table
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
|          ENDPOINT           |        ID        | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
| https://192.168.26.100:2379 |  ee392e5273e89e2 |   3.5.4 |   37 MB |     false |       100 |    3152364 |
| https://192.168.26.102:2379 | 11486647d7f3a17b |   3.5.4 |   36 MB |     false |       100 |    3152364 |
| https://192.168.26.101:2379 | e00e3877df8f76f4 |   3.5.4 |   36 MB |      true |       100 |    3152364 |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
┌──[root@vms100.liruilongs.github.io]-[~/ansible/kubescape]
└─$

集群情况下，备份可以单节点备份，前面我们也讲过，etcd 集群为完全复制，单节点备份

┌──[root@vms100.liruilongs.github.io]-[~]
└─$yum -y install etcd

没有 etcdctl 工具，需要安装一下 etcd 或者从其他的地方单独拷贝一下。这里我们安装下，然后把 etcetl 拷贝到其他集群节点。

备份

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ENDPOINT=https://127.0.0.1:2379
┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl --endpoints $ENDPOINT  --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" snapshot save snapshot.db
Snapshot saved at snapshot.db

校验快照 hash 值

┌──[root@vms100.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl --write-out=table snapshot status snapshot.db
+----------+----------+------------+------------+
|   HASH   | REVISION | TOTAL KEYS | TOTAL SIZE |
+----------+----------+------------+------------+
| 46aa26ed |   217504 |       2711 |      27 MB |
+----------+----------+------------+------------+
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

恢复

这里的 etcd 集群部署，采用堆叠的方式，通过静态 pod 运行，位于每个控制节点的上。

一定要备份，恢复前需要把原来的数据文件备份清理，在恢复前需要确保 etcd 和 api-Service 已经停掉。获取必要的参数

┌──[root@vms100.liruilongs.github.io]-[~]
└─$kubectl describe pod etcd-vms100.liruilongs.github.io -n kube-system  | grep -e '--'
      --advertise-client-urls=https://192.168.26.100:2379
      --cert-file=/etc/kubernetes/pki/etcd/server.crt
      --client-cert-auth=true
      --data-dir=/var/lib/etcd
      --experimental-initial-corrupt-check=true
      --experimental-watch-progress-notify-interval=5s
      --initial-advertise-peer-urls=https://192.168.26.100:2380
      --initial-cluster=vms100.liruilongs.github.io=https://192.168.26.100:2380
      --key-file=/etc/kubernetes/pki/etcd/server.key
      --listen-client-urls=https://127.0.0.1:2379,https://192.168.26.100:2379
      --listen-metrics-urls=http://127.0.0.1:2381
      --listen-peer-urls=https://192.168.26.100:2380
      --name=vms100.liruilongs.github.io
      --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
      --peer-client-cert-auth=true
      --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
      --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
      --snapshot-count=10000
      --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
┌──[root@vms100.liruilongs.github.io]-[~]
└─$

恢复的时候：停掉所有 Master 节点的 kube-apiserver和 etcd 这两个静态pod 。 kubelet 每隔 20s 会扫描一次这个目录确定是否发生静态 pod 变动。移动Yaml文件即可停掉。

这是使用 Ansible ，集群所有节点执行。

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "mv  /etc/kubernetes/manifests/etcd.yaml  /tmp/ " -i host.yaml
192.168.26.102 | CHANGED | rc=0 >>

192.168.26.101 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "mv   /etc/kubernetes/manifests/kube-apiserver.yaml  /tmp/ " -i host.yaml
192.168.26.101 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

确实静态 Yaml 文件发生移动

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "ls /etc/kubernetes/manifests/" -i host.yaml
192.168.26.102 | CHANGED | rc=0 >>
haproxy.yaml
keepalived.yaml
kube-controller-manager.yaml
kube-scheduler.yaml
192.168.26.100 | CHANGED | rc=0 >>
haproxy.yaml
keepalived.yaml
kube-controller-manager.yaml
kube-scheduler.yaml
192.168.26.101 | CHANGED | rc=0 >>
haproxy.yaml
keepalived.yaml
kube-controller-manager.yaml
kube-scheduler.yaml
┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$

清空所有集群节点的 etcd 数据目录

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "rm -rf /var/lib/etcd/" -i host.yaml
[WARNING]: Consider using the file module with state=absent rather than running 'rm'.  If you need to use command because file is insufficient you can add 'warn:
false' to this command task or set 'command_warnings=False' in ansible.cfg to get rid of this message.
192.168.26.101 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

复制快照备份文件到集群所有节点

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master  -m copy -a "src=snap-202302070000.db dest=/root/" -i host.yaml

在 vms100.liruilongs.github.io 上面恢复

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ETCDCTL_API=3 etcdctl snapshot restore snap-202302070000.db \
 --name vms100.liruilongs.github.io  \
 --cert="/etc/kubernetes/pki/etcd/server.crt" \
 --key="/etc/kubernetes/pki/etcd/server.key"  \
 --cacert="/etc/kubernetes/pki/etcd/ca.crt"   \
 --endpoints="https://127.0.0.1:2379" \
 --initial-advertise-peer-urls="https://192.168.26.100:2380"  \
 --initial-cluster="vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380" \
 --data-dir=/var/lib/etcd
2023-02-08 12:50:27.598250 I | mvcc: restore compact to 2837993
2023-02-08 12:50:27.609440 I | etcdserver/membership: added member ee392e5273e89e2 [https://192.168.26.100:2380] to cluster 4816f346663d82a7
2023-02-08 12:50:27.609480 I | etcdserver/membership: added member 70059e836d19883d [https://192.168.26.101:2380] to cluster 4816f346663d82a7
2023-02-08 12:50:27.609487 I | etcdserver/membership: added member b8cb9f66c2e63b91 [https://192.168.26.102:2380] to cluster 4816f346663d82a7

在 vms101.liruilongs.github.io 上恢复

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ssh 192.168.26.101
Last login: Wed Feb  8 12:48:31 2023 from 192.168.26.100
┌──[root@vms101.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl snapshot restore snap-202302070000.db --name vms101.liruilongs.github.io  --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt"   --endpoints="https://127.0.0.1:2379" --initial-advertise-peer-urls="https://192.168.26.101:2380"  --initial-cluster="vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380,vms102.liruilongs.github.io=https://192.168.26.102:2380" --data-dir=/var/lib/etcd
2023-02-08 12:52:21.976748 I | mvcc: restore compact to 2837993
2023-02-08 12:52:21.991588 I | etcdserver/membership: added member ee392e5273e89e2 [https://192.168.26.100:2380] to cluster 4816f346663d82a7
2023-02-08 12:52:21.991622 I | etcdserver/membership: added member 70059e836d19883d [https://192.168.26.101:2380] to cluster 4816f346663d82a7
2023-02-08 12:52:21.991629 I | etcdserver/membership: added member b8cb9f66c2e63b91 [https://192.168.26.102:2380] to cluster 4816f346663d82a7

在 vms102.liruilongs.github.io 上恢复

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ssh 192.168.26.102
Last login: Wed Feb  8 12:48:31 2023 from 192.168.26.100
┌──[root@vms102.liruilongs.github.io]-[~]
└─$ETCDCTL_API=3 etcdctl snapshot restore snap-202302070000.db --name vms102.liruilongs.github.io  --cert="/etc/kubernetes/pki/etcd/server.crt" --key="/etc/kubernetes
/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt"   --endpoints="https://127.0.0.1:2379" --initial-advertise-peer-urls="https://192.168.26.102:2380"
--initial-cluster="vms100.liruilongs.github.io=https://192.168.26.100:2380,vms101.liruilongs.github.io=https://192.168.26.101:2380,vms102.liruilongs.github.io=https:/
/192.168.26.102:2380" --data-dir=/var/lib/etcd
2023-02-08 12:53:32.338663 I | mvcc: restore compact to 2837993
2023-02-08 12:53:32.354619 I | etcdserver/membership: added member ee392e5273e89e2 [https://192.168.26.100:2380] to cluster 4816f346663d82a7
2023-02-08 12:53:32.354782 I | etcdserver/membership: added member 70059e836d19883d [https://192.168.26.101:2380] to cluster 4816f346663d82a7
2023-02-08 12:53:32.354790 I | etcdserver/membership: added member b8cb9f66c2e63b91 [https://192.168.26.102:2380] to cluster 4816f346663d82a7
┌──[root@vms102.liruilongs.github.io]-[~]
└─$

恢复完成后移动 etcd,api-service 静态pod 配置文件

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "mv /tmp/kube-apiserver.yaml  /etc/kubernetes/manifests/ " -i host.yaml
192.168.26.101 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "mv /tmp/etcd.yaml  /etc/kubernetes/manifests/etcd.yaml " -i host.yaml
192.168.26.101 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$

确认移动成功。

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ansible k8s_master -m command -a "ls /etc/kubernetes/manifests/" -i host.yaml
192.168.26.100 | CHANGED | rc=0 >>
etcd.yaml
haproxy.yaml
keepalived.yaml
kube-apiserver.yaml
kube-controller-manager.yaml
kube-scheduler.yaml
192.168.26.101 | CHANGED | rc=0 >>
etcd.yaml
haproxy.yaml
keepalived.yaml
kube-apiserver.yaml
kube-controller-manager.yaml
kube-scheduler.yaml
192.168.26.102 | CHANGED | rc=0 >>
etcd.yaml
haproxy.yaml
keepalived.yaml
kube-apiserver.yaml
kube-controller-manager.yaml
kube-scheduler.yaml
┌──[root@vms100.liruilongs.github.io]-[~/ansible]

任意节点查看 etcd 集群信息。恢复成功

┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$kubectl get pods
The connection to the server 192.168.26.99:30033 was refused - did you specify the right host or port?
┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster  -w table
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
|          ENDPOINT           |        ID        | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
| https://192.168.26.100:2379 |  ee392e5273e89e2 |   3.5.4 |   37 MB |     false |         2 |        146 |
| https://192.168.26.101:2379 | 70059e836d19883d |   3.5.4 |   37 MB |      true |         2 |        146 |
| https://192.168.26.102:2379 | b8cb9f66c2e63b91 |   3.5.4 |   37 MB |     false |         2 |        146 |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
┌──[root@vms100.liruilongs.github.io]-[~/ansible]
└─$

遇到的问题：

如果某一节点有下面的报错，或者集群节点添加不成功，添加了两个，需要按照上面的步骤重复进行。

panic: tocommit(258) is out of range [lastIndex(0)]. Was the raft log corrupted, truncated, or lost? 问题处理

┌──[root@vms100.liruilongs.github.io]-[~/back]
└─$ETCDCTL_API=3 etcdctl  --endpoints https://127.0.0.1:2379  --cert="/etc/kubernetes/pki/etcd/server.crt"  --key="/etc/kubernetes/pki/etcd/server.key"  --cacert="/etc/kubernetes/pki/etcd/ca.crt" endpoint status --cluster  -w table
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
|          ENDPOINT           |        ID        | VERSION | DB SIZE | IS LEADER | RAFT TERM | RAFT INDEX |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+
| https://192.168.26.100:2379 |  ee392e5273e89e2 |   3.5.4 |   37 MB |      true |         2 |      85951 |
| https://192.168.26.101:2379 | 70059e836d19883d |   3.5.4 |   37 MB |     false |         2 |      85951 |
+-----------------------------+------------------+---------+---------+-----------+-----------+------------+

备份定时任务编写

这里的定时备份通过，systemd.service 和 systemd.timer 实现，定时运行 etcd_back.sh 备份脚本，并设置开机自启

很简单没啥说的

┌──[root@vms81.liruilongs.github.io]-[~/back]
└─$systemctl cat etcd-backup
# /usr/lib/systemd/system/etcd-backup.service
[Unit]
Description= "ETCD 备份"
After=network-online.target

[Service]
Type=oneshot
Environment=ETCDCTL_API=3
ExecStart=/usr/bin/bash /usr/lib/systemd/system/etcd_back.sh


[Install]
WantedBy=multi-user.target

每天午夜执行一次

┌──[root@vms81.liruilongs.github.io]-[~/back]
└─$systemctl cat etcd-backup.timer
# /usr/lib/systemd/system/etcd-backup.timer
[Unit]
Description="每天备份一次 ETCD"

[Timer]
OnBootSec=3s
OnCalendar=*-*-* 00:00:00
Unit=etcd-backup.service

[Install]
WantedBy=multi-user.target

备份脚本

┌──[root@vms100.liruilongs.github.io]-[~/ansible/backup]
└─$cat etcd_back.sh
#!/bin/bash

#@File    :   erct_break.sh
#@Time    :   2023/01/27 23:00:27
#@Author  :   Li Ruilong
#@Version :   1.0
#@Desc    :   ETCD 备份
#@Contact :   1224965096@qq.com

if [ ! -d /root/back/ ];then
   mkdir -p /root/back/
fi
STR_DATE=$(date +%Y%m%d%H%M)

ETCDCTL_API=3 etcdctl \
--endpoints="https://127.0.0.1:2379"  \
--cert="/etc/kubernetes/pki/etcd/server.crt"  \
--key="/etc/kubernetes/pki/etcd/server.key"  \
--cacert="/etc/kubernetes/pki/etcd/ca.crt"   \
snapshot save /root/back/snap-${STR_DATE}.db

ETCDCTL_API=3 etcdctl --write-out=table snapshot status /root/back/snap-${STR_DATE}.db

sudo chmod  o-w,u-w,g-w  /root/back/snap-${STR_DATE}.db

服务和定时任务的备份部署

┌──[root@vms100.liruilongs.github.io]-[~/ansible/backup]
└─$cat deply.sh
#!/bin/bash

#@File    :   erct_break.sh
#@Time    :   2023/01/27 23:00:27
#@Author  :   Li Ruilong
#@Version :   1.0
#@Desc    :   ETCD 备份部署
#@Contact :   1224965096@qq.com

cp ./* /usr/lib/systemd/system/
systemctl enable etcd-backup.timer --now
systemctl enable etcd-backup.service --now
ls /root/back/

日志查看

┌──[root@vms100.liruilongs.github.io]-[~/ansible/backup]
└─$journalctl -u etcd-backup.service -o cat
...................
Starting "ETCD 备份"...
Snapshot saved at /root/back/snap-202301290120.db
+----------+----------+------------+------------+
|   HASH   | REVISION | TOTAL KEYS | TOTAL SIZE |
+----------+----------+------------+------------+
| 74323316 |   640319 |       2250 |      27 MB |
+----------+----------+------------+------------+
Started "ETCD 备份".
Starting "ETCD 备份"...
Snapshot saved at /root/back/snap-202301290120.db
+----------+----------+------------+------------+
|   HASH   | REVISION | TOTAL KEYS | TOTAL SIZE |
+----------+----------+------------+------------+
| e75a16bf |   640325 |       2255 |      27 MB |
+----------+----------+------------+------------+
Started "ETCD 备份".
Starting "ETCD 备份"...
Snapshot saved at /root/back/snap-202301290121.db
+----------+----------+------------+------------+
|   HASH   | REVISION | TOTAL KEYS | TOTAL SIZE |
+----------+----------+------------+------------+
| eb5e9e86 |   640388 |       2318 |      27 MB |
+----------+----------+------------+------------+
Started "ETCD 备份".
Starting "ETCD 备份"...
Snapshot saved at /root/back/snap-202301290121.db
+----------+----------+------------+------------+
|   HASH   | REVISION | TOTAL KEYS | TOTAL SIZE |
+----------+----------+------------+------------+
| 30a91bb6 |   640402 |       2333 |      27 MB |
+----------+----------+------------+------------+
Started "ETCD 备份".

二进制集群备份恢复

二进制集群的备份恢复和静态 pod 的方式基本相同。

这里不同的是，下面的恢复方式使用，先恢复前两个节点，构成集群，第三个节点加入集群的方式。当前集群信息

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -m shell -a "etcdctl member list"
192.168.26.101 | CHANGED | rc=0 >>
2fd4f9ba70a04579: name=etcd-102 peerURLs=http://192.168.26.102:2380 clientURLs=http://192.168.26.102:2379,http://localhost:2379 isLeader=false
6f2038a018db1103: name=etcd-100 peerURLs=http://192.168.26.100:2380 clientURLs=http://192.168.26.100:2379,http://localhost:2379 isLeader=false
bd330576bb637f25: name=etcd-101 peerURLs=http://192.168.26.101:2380 clientURLs=http://192.168.26.101:2379,http://localhost:2379 isLeader=true
192.168.26.102 | CHANGED | rc=0 >>
2fd4f9ba70a04579: name=etcd-102 peerURLs=http://192.168.26.102:2380 clientURLs=http://192.168.26.102:2379,http://localhost:2379 isLeader=false
6f2038a018db1103: name=etcd-100 peerURLs=http://192.168.26.100:2380 clientURLs=http://192.168.26.100:2379,http://localhost:2379 isLeader=false
bd330576bb637f25: name=etcd-101 peerURLs=http://192.168.26.101:2380 clientURLs=http://192.168.26.101:2379,http://localhost:2379 isLeader=true
192.168.26.100 | CHANGED | rc=0 >>
2fd4f9ba70a04579: name=etcd-102 peerURLs=http://192.168.26.102:2380 clientURLs=http://192.168.26.102:2379,http://localhost:2379 isLeader=false
6f2038a018db1103: name=etcd-100 peerURLs=http://192.168.26.100:2380 clientURLs=http://192.168.26.100:2379,http://localhost:2379 isLeader=false
bd330576bb637f25: name=etcd-101 peerURLs=http://192.168.26.101:2380 clientURLs=http://192.168.26.101:2379,http://localhost:2379 isLeader=true
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

准备数据

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.100 -a  "etcdctl put name liruilong"
192.168.26.100 | CHANGED | rc=0 >>
OK
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "etcdctl get name"
192.168.26.102 | CHANGED | rc=0 >>
name
liruilong
192.168.26.100 | CHANGED | rc=0 >>
name
liruilong
192.168.26.101 | CHANGED | rc=0 >>
name
liruilong

在任意一台主机上对 etcd 做快照

#在任何一台主机上对 etcd 做快照
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.101 -a "etcdctl snapshot save snap20211010.db"
192.168.26.101 | CHANGED | rc=0 >>
Snapshot saved at snap20211010.db
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

此快照里包含了刚刚写的数据 name=liruilong，然后把快照文件复制到所有节点

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.101 -a "scp /root/snap20211010.db root@192.168.26.100:/root/"
192.168.26.101 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.101 -a "scp /root/snap20211010.db root@192.168.26.102:/root/"
192.168.26.101 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

清空数据所有节点数据

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "etcdctl del name"
192.168.26.101 | CHANGED | rc=0 >>
1
192.168.26.102 | CHANGED | rc=0 >>
0
192.168.26.100 | CHANGED | rc=0 >>
0
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

在所有节点上关闭 etcd，并删除/var/lib/etcd/里所有数据：

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$# 在所有节点上关闭 etcd，并删除/var/lib/etcd/里所有数据：
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "systemctl stop etcd"
192.168.26.100 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

192.168.26.101 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -m shell -a "rm -rf /var/lib/etcd/*"
[WARNING]: Consider using the file module with state=absent rather than running 'rm'.  If you need to
use command because file is insufficient you can add 'warn: false' to this command task or set
'command_warnings=False' in ansible.cfg to get rid of this message.
192.168.26.102 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

192.168.26.101 | CHANGED | rc=0 >>

在所有节点上把快照文件的所有者和所属组设置为 etcd：

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "chown etcd.etcd /root/snap20211010.db"
[WARNING]: Consider using the file module with owner rather than running 'chown'.  If you need to use
command because file is insufficient you can add 'warn: false' to this command task or set
'command_warnings=False' in ansible.cfg to get rid of this message.
192.168.26.100 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

192.168.26.101 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$# 在每台节点上开始恢复数据：

在 100,101 节点上开始恢复数据


┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.100 -m script  -a "./snapshot_restore.sh"
192.168.26.100 | CHANGED => {
    "changed": true,
    "rc": 0,
    "stderr": "Shared connection to 192.168.26.100 closed.\r\n",
    "stderr_lines": [
        "Shared connection to 192.168.26.100 closed."
    ],
    "stdout": "2021-10-10 12:14:30.726021 I | etcdserver/membership: added member 6f2038a018db1103 [http://192.168.26.100:2380] to cluster af623437f584d792\r\n2021-10-10 12:14:30.726234 I | etcdserver/membership: added member bd330576bb637f25 [http://192.168.26.101:2380] to cluster af623437f584d792\r\n",
    "stdout_lines": [
        "2021-10-10 12:14:30.726021 I | etcdserver/membership: added member 6f2038a018db1103 [http://192.168.26.100:2380] to cluster af623437f584d792",
        "2021-10-10 12:14:30.726234 I | etcdserver/membership: added member bd330576bb637f25 [http://192.168.26.101:2380] to cluster af623437f584d792"
    ]
}
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$cat -n ./snapshot_restore.sh
     1  #!/bin/bash
     2
     3  # 每台节点恢复镜像
     4
     5  etcdctl snapshot restore /root/snap20211010.db \
     6  --name etcd-100 \
     7  --initial-advertise-peer-urls="http://192.168.26.100:2380" \
     8  --initial-cluster="etcd-100=http://192.168.26.100:2380,etcd-101=http://192.168.26.101:2380" \
     9  --data-dir="/var/lib/etcd/cluster.etcd"
    10
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$sed '6,7s/100/101/g' ./snapshot_restore.sh
#!/bin/bash

# 每台节点恢复镜像

etcdctl snapshot restore /root/snap20211010.db \
--name etcd-101 \
--initial-advertise-peer-urls="http://192.168.26.101:2380" \
--initial-cluster="etcd-100=http://192.168.26.100:2380,etcd-101=http://192.168.26.101:2380" \
--data-dir="/var/lib/etcd/cluster.etcd"

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$sed -i '6,7s/100/101/g' ./snapshot_restore.sh
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$cat ./snapshot_restore.sh
#!/bin/bash

# 每台节点恢复镜像

etcdctl snapshot restore /root/snap20211010.db \
--name etcd-101 \
--initial-advertise-peer-urls="http://192.168.26.101:2380" \
--initial-cluster="etcd-100=http://192.168.26.100:2380,etcd-101=http://192.168.26.101:2380" \
--data-dir="/var/lib/etcd/cluster.etcd"

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.101 -m script  -a "./snapshot_restore.sh"
192.168.26.101 | CHANGED => {
    "changed": true,
    "rc": 0,
    "stderr": "Shared connection to 192.168.26.101 closed.\r\n",
    "stderr_lines": [
        "Shared connection to 192.168.26.101 closed."
    ],
    "stdout": "2021-10-10 12:20:26.032754 I | etcdserver/membership: added member 6f2038a018db1103 [http://192.168.26.100:2380] to cluster af623437f584d792\r\n2021-10-10 12:20:26.032930 I | etcdserver/membership: added member bd330576bb637f25 [http://192.168.26.101:2380] to cluster af623437f584d792\r\n",
    "stdout_lines": [
        "2021-10-10 12:20:26.032754 I | etcdserver/membership: added member 6f2038a018db1103 [http://192.168.26.100:2380] to cluster af623437f584d792",
        "2021-10-10 12:20:26.032930 I | etcdserver/membership: added member bd330576bb637f25 [http://192.168.26.101:2380] to cluster af623437f584d792"
    ]
}
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

所有节点把/var/lib/etcd 及里面内容的所有者和所属组改为 etcd:etcd 然后分别启动 etcd

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "chown -R etcd.etcd /var/lib/etcd/"
[WARNING]: Consider using the file module with owner rather than running 'chown'.  If you need to use
command because file is insufficient you can add 'warn: false' to this command task or set
'command_warnings=False' in ansible.cfg to get rid of this message.
192.168.26.100 | CHANGED | rc=0 >>

192.168.26.101 | CHANGED | rc=0 >>

192.168.26.102 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "systemctl start etcd"
192.168.26.102 | FAILED | rc=1 >>
Job for etcd.service failed because the control process exited with error code. See "systemctl status etcd.service" and "journalctl -xe" for details.non-zero return code
192.168.26.101 | CHANGED | rc=0 >>

192.168.26.100 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

把剩下的 102 节点添加进集群

# etcdctl member add etcd_name –peer-urls=”https://peerURLs”
[root@vms100 cluster.etcd]# etcdctl member add etcd-102 --peer-urls="http://192.168.26.102:2380"
Member fbd8a96cbf1c004d added to cluster af623437f584d792

ETCD_NAME="etcd-102"
ETCD_INITIAL_CLUSTER="etcd-100=http://192.168.26.100:2380,etcd-101=http://192.168.26.101:2380,etcd-102=http://192.168.26.102:2380"
ETCD_INITIAL_ADVERTISE_PEER_URLS="http://192.168.26.102:2380"
ETCD_INITIAL_CLUSTER_STATE="existing"
[root@vms100 cluster.etcd]#

测试恢复结果

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.102 -m copy -a "src=./etcd.conf dest=/etc/etcd/etcd.conf force=yes"
192.168.26.102 | SUCCESS => {
    "ansible_facts": {
        "discovered_interpreter_python": "/usr/bin/python"
    },
    "changed": false,
    "checksum": "2d8fa163150e32da563f5e591134b38cc356d237",
    "dest": "/etc/etcd/etcd.conf",
    "gid": 0,
    "group": "root",
    "mode": "0644",
    "owner": "root",
    "path": "/etc/etcd/etcd.conf",
    "size": 574,
    "state": "file",
    "uid": 0
}
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible 192.168.26.102 -m shell -a "systemctl enable etcd --now"
192.168.26.102 | CHANGED | rc=0 >>

┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -m shell -a "etcdctl member list"
192.168.26.101 | CHANGED | rc=0 >>
6f2038a018db1103, started, etcd-100, http://192.168.26.100:2380, http://192.168.26.100:2379,http://localhost:2379
bd330576bb637f25, started, etcd-101, http://192.168.26.101:2380, http://192.168.26.101:2379,http://localhost:2379
fbd8a96cbf1c004d, started, etcd-102, http://192.168.26.102:2380, http://192.168.26.102:2379,http://localhost:2379
192.168.26.100 | CHANGED | rc=0 >>
6f2038a018db1103, started, etcd-100, http://192.168.26.100:2380, http://192.168.26.100:2379,http://localhost:2379
bd330576bb637f25, started, etcd-101, http://192.168.26.101:2380, http://192.168.26.101:2379,http://localhost:2379
fbd8a96cbf1c004d, started, etcd-102, http://192.168.26.102:2380, http://192.168.26.102:2379,http://localhost:2379
192.168.26.102 | CHANGED | rc=0 >>
6f2038a018db1103, started, etcd-100, http://192.168.26.100:2380, http://192.168.26.100:2379,http://localhost:2379
bd330576bb637f25, started, etcd-101, http://192.168.26.101:2380, http://192.168.26.101:2379,http://localhost:2379
fbd8a96cbf1c004d, started, etcd-102, http://192.168.26.102:2380, http://192.168.26.102:2379,http://localhost:2379
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$ansible etcd -a "etcdctl get name"
192.168.26.102 | CHANGED | rc=0 >>
name
liruilong
192.168.26.101 | CHANGED | rc=0 >>
name
liruilong
192.168.26.100 | CHANGED | rc=0 >>
name
liruilong
┌──[root@vms81.liruilongs.github.io]-[~/ansible]
└─$

博文部分内容参考

文中涉及参考链接内容版权归原作者所有，如有侵权请告知

https://etcd.io/docs/v3.5/faq/

https://etcd.io/docs/v3.6/op-guide/recovery/#restoring-a-cluster

https://kubernetes.io/zh-cn/docs/tasks/administer-cluster/configure-upgrade-etcd/

https://docs.vmware.com/en/VMware-Application-Catalog/services/tutorials/GUID-backup-restore-data-etcd-kubernetes-index.html

https://github.com/etcd-io/etcd/issues/13509

点赞
收藏
关注作者

0/1000

抱歉，系统识别当前为高风险访问，暂不支持该操作

全部回复

上滑加载中

设置昵称

在此一键设置昵称，即可参与社区互动！

*长度不超过10个汉字或20个英文字符，设置后3个月内不可修改。

确认取消

加入云驻计划，成为创作者

华为云周边好礼
免费体验产品
特殊身份标识
线下官方门票
内部专家零距离
与10000+优质创作者共同成长

立即加入
