云原生之使用docker部署TestLink测试平台

一、TestLink介绍

TestLink 是基于web的测试用例管理系统，主要功能是测试用例的创建、管理和执行，并且还提供了一些简单的统计功能。

二、TestLink的特点

• 测试需求管理

• 测试用例管理

• 测试用例对测试需求的覆盖管理

• 测试计划的制定

• 测试用例的执行

• 大量测试数据的度量和统计功能。

• 目前在XLS导入上存在缺陷，但可以使用第三方的“Testlink Convert”工具实现XLS/TXT/XML导入导出。

• 软件特色

• 免费开源

• 邮箱提醒

• 权限控制

• 系统可定制

• 插件支持

• 广泛的技术支持

三、检查docker信息

[root@node ~]# docker info
Client:
 Context:    default
 Debug Mode: false
 Plugins:
  app: Docker App (Docker Inc., v0.9.1-beta3)
  buildx: Docker Buildx (Docker Inc., v0.8.2-docker)
  compose: Docker Compose (Docker Inc., v2.6.0)
  scan: Docker Scan (Docker Inc., v0.17.0)

Server:
 Containers: 2
  Running: 2
  Paused: 0
  Stopped: 0
 Images: 112
 Server Version: 20.10.17
 Storage Driver: overlay2
  Backing Filesystem: xfs
  Supports d_type: true
  Native Overlay Diff: true
  userxattr: false
 Logging Driver: json-file
 Cgroup Driver: cgroupfs
 Cgroup Version: 1
 Plugins:
  Volume: local
  Network: bridge host ipvlan macvlan null overlay
  Log: awslogs fluentd gcplogs gelf journald json-file local logentries splunk syslog
 Swarm: inactive
 Runtimes: io.containerd.runc.v2 io.containerd.runtime.v1.linux runc
 Default Runtime: runc
 Init Binary: docker-init
 containerd version: 10c12954828e7c7c9b6e0ea9b0c02b01407d3ae1
 runc version: v1.1.2-0-ga916309
 init version: de40ad0
 Security Options:
  seccomp
   Profile: default
 Kernel Version: 3.10.0-957.el7.x86_64
 Operating System: CentOS Linux 7 (Core)
 OSType: linux
 Architecture: x86_64
 CPUs: 8
 Total Memory: 11.68GiB
 Name: node
 ID: EIOB:6IAO:NQTR:AJBA:O6KS:SNWP:JEDK:GXBG:55FP:IOSK:WRH3:QOAU
 Docker Root Dir: /var/lib/docker
 Debug Mode: false
 Registry: https://index.docker.io/v1/
 Labels:
 Experimental: false
 Insecure Registries:
  127.0.0.0/8
 Registry Mirrors:
  https://sp4mg57h.mirror.aliyuncs.com/
 Live Restore Enabled: false

四、创建mariadb容器

1.创建安装目录

mkdir  -p /data/testlink/mariadb

2.目录授权

[root@node testlink]# chmod -R 755 /data/testlink/

3.创建网络

[root@node testlink]# docker network create testlink
d5764ed407ae63b7008b27f1100ea2d935524fe9ad688a5bfd0c619919fc387c

4.创建mariadb容器

docker run -d --name mariadb --net testlink --restart=always --privileged=true -e MARIADB_ROOT_PASSWORD=testlink -e MARIADB_USER=testlink  -e MARIADB_PASSWORD=testlink -e MARIADB_DATABASE=testlink     bitnami/mariadb

5.检查mariadb容器状态

[root@node testlink]# docker ps
CONTAINER ID   IMAGE               COMMAND                  CREATED         STATUS         PORTS     d15485b61d9f   bitnami/mariadb     "/opt/bitnami/script…"   50 seconds ago   Up 49 seconds   3306/tcp                                                                               mariadb

五、安装Testlink

1.创建Testlink容器

docker run -d -p 8088:8080 -p 8445:8443  --name testlink --net testlink --restart=always --privileged=true -e TESTLINK_DATABASE_USER=testlink -e TESTLINK_DATABASE_PASSWORD=testlink -e TESTLINK_DATABASE_NAME=testlink bitnami/testlink

2.查看Testlink容器状态

[root@node testlink]# docker ps
CONTAINER ID   IMAGE               COMMAND                  CREATED          STATUS          PORTS                                                                                  NAMES
2b2fdb57fc44   bitnami/testlink    "/opt/bitnami/script…"   9 seconds ago    Up 8 seconds    0.0.0.0:8088->8080/tcp, :::8088->8080/tcp, 0.0.0.0:8445->8443/tcp, :::8445->8443/tcp   testlink
6e8810ca40de   bitnami/mariadb     "/opt/bitnami/script…"   46 seconds ago   Up 45 seconds   3306/tcp                                                                               mariadb

3.查看Testlink容器日志

[root@node testlink]# docker logs testlink
testlink 08:51:11.04
testlink 08:51:11.04 Welcome to the Bitnami testlink container
testlink 08:51:11.04 Subscribe to project updates by watching https://github.com/bitnami/bitnami-docker-testlink
testlink 08:51:11.04 Submit issues and feature requests at https://github.com/bitnami/bitnami-docker-testlink/issues
testlink 08:51:11.04
testlink 08:51:11.05 INFO  ==> ** Starting TestLink setup **
realpath: /bitnami/apache/conf: No such file or directory
testlink 08:51:11.08 INFO  ==> Configuring PHP options
testlink 08:51:11.09 INFO  ==> Validating settings in MYSQL_CLIENT_* env vars
testlink 08:51:11.16 INFO  ==> Configuring TestLink with settings provided via environment variables
testlink 08:51:11.18 INFO  ==> Ensuring TestLink directories exist
testlink 08:51:11.19 INFO  ==> Trying to connect to the database server
testlink 08:51:11.47 INFO  ==> Persisting TestLink installation

testlink 08:51:11.55 INFO  ==> ** TestLink setup finished! **
testlink 08:51:11.56 INFO  ==> ** Starting Apache **
[Wed Oct 19 08:51:11.604934 2022] [ssl:warn] [pid 1] AH01909: www.example.com:8443:0 server certificate does NOT include an ID which matches the server name
[Wed Oct 19 08:51:11.605262 2022] [ssl:warn] [pid 1] AH01909: www.example.com:8443:0 server certificate does NOT include an ID which matches the server name
[Wed Oct 19 08:51:11.623747 2022] [ssl:warn] [pid 1] AH01909: www.example.com:8443:0 server certificate does NOT include an ID which matches the server name
[Wed Oct 19 08:51:11.623984 2022] [ssl:warn] [pid 1] AH01909: www.example.com:8443:0 server certificate does NOT include an ID which matches the server name
[Wed Oct 19 08:51:11.632656 2022] [mpm_prefork:notice] [pid 1] AH00163: Apache/2.4.52 (Unix) OpenSSL/1.1.1d PHP/7.4.27 configured -- resuming normal operations
[Wed Oct 19 08:51:11.632699 2022] [core:notice] [pid 1] AH00094: Command line: '/opt/bitnami/apache/bin/httpd -f /opt/bitnami/apache/conf/httpd.conf -D FOREGROUND'
192.168.3.11 - - [19/Oct/2022:08:51:31 +0000] "GET / HTTP/1.1" 200 126
192.168.3.11 - - [19/Oct/2022:08:51:31 +0000] "GET /login.php HTTP/1.1" 200 830
192.168.3.11 - - [19/Oct/2022:08:52:23 +0000] "-" 408 -

六、登录Testlink

user/bitnami

七、进入Testlink首页
