Unity【Live Capture】- 关于人脸捕捉的解决方案（一）
【摘要】
最近项目里有人脸捕捉的需求，刚开始时参考的下面这篇文章，使用官方发布的Facial AR Remote，需要我们自己构建IOS客户端，因此需要准备包括MacOS操作系统、Xcode等开发环境，在Unity构建出Xcode工程后，还要考虑开发许可证等问题，而且在尝试时，我使用的Xcode13版本，在编译上还有一些问题，比较麻烦。
htt...
最近项目里有人脸捕捉的需求，刚开始时参考的下面这篇文章，使用官方发布的Facial AR Remote，需要我们自己构建IOS客户端，因此需要准备包括MacOS操作系统、Xcode等开发环境，在Unity构建出Xcode工程后，还要考虑开发许可证等问题，而且在尝试时，我使用的Xcode13版本，在编译上还有一些问题，比较麻烦。
https://www.163.com/dy/article/E70U8CLT0526E124.html
随后发现了另一个解决方案，即Live Capture，IOS客户端已经发布于App Store中，名称Unity Face Capture：
Live Capture在Package Manager中通过git url的方式进行添加，地址：
Live Capture官方手册地址：
https://docs.unity.cn/Packages/com.unity.live-capture@1.0/manual/index.html
PDF文档下载地址：
文档很详细，也可以参考下面的步骤：
1.新建空物体，添加Take Recoder组件，它依赖Playable Director组件，添加Take Recorder时自动添加Playable Director：
2.将制作好的包含人脸的模型拖入场景，挂载ARKit Face Actor组件，然后将其做成Prefab预制体。
3.在Take Recoder组件下方点击+按钮，添加ARKit Face Device，并将其Actor设为步骤2中挂载了ARKit Face Actor组件的人脸模型：
4.在Project窗口右键，Create / Live Capture / ARKit Face Capture / Mapper，创建一个Head Mapper资产，将其Rig Prefab设为步骤2中生成的Prefab，并设置人脸模型中对应的的Left Eye、RightEye、Head骨骼节点：
5.点击Head Mapper资产中的Add Renderer按钮，绑定BlendShape，名称如果与ARKit中要求一致则会自动绑定好，否则需要一一对应设置：
6.将编辑好的Head Mapper资产赋值给步骤2挂载的ARKit Face Actor组件中的Mapper：
7.Window / Live Capture / Connections 打开Connections窗口，创建服务器，点击Start即可启动：
8.启动后打开IOS客户端，点击Connect进行连接，若连接不上，检查一下手机和电脑是否处于同一网段，检查电脑防火墙，最好都关掉。
另外值得注意的是，服务端的启动是通过在Connections编辑器窗口中点击Start开启的，因此它的使用环境是在Unity编辑器环境中，如果想打包后运行时使用，需要将其从Package Manager中迁移到工程Assets目录下，并创建脚本编写启动方法：
创建LiveCaptureServer类，继承Server：
-
using System;
-
using System.IO;
-
using System.Linq;
-
using System.Text;
-
using UnityEngine;
-
using System.Collections.Generic;
-
using Unity.LiveCapture.Networking;
-
using Unity.LiveCapture.Networking.Discovery;
-
-
namespace Unity.LiveCapture.CompanionApp
-
{
-
[CreateAssetMenu(menuName = "Live Capture/Server")]
-
public class LiveCaptureServer : Server
-
{
-
const int k_DefaultPort = 9000;
-
-
/// <summary>
-
/// The server executes this event when a client has connected.
-
/// </summary>
-
public static event Action<ICompanionAppClient> ClientConnected = delegate { };
-
-
/// <summary>
-
/// The server executes this event when a client has disconnected.
-
/// </summary>
-
public static event Action<ICompanionAppClient> ClientDisconnected = delegate { };
-
-
struct ConnectHandler
-
{
-
public string Name;
-
public DateTime Time;
-
public Func<ICompanionAppClient, bool> Handler;
-
}
-
-
readonly Dictionary<string, Type> s_TypeToClientType = new Dictionary<string, Type>();
-
static readonly List<ConnectHandler> s_ClientConnectHandlers = new List<ConnectHandler>();
-
-
/// <summary>
-
/// Adds a callback used to take ownership of a client that has connected.
-
/// </summary>
-
/// <param name="handler">The callback function. It must return true if it takes ownership of a client.</param>
-
/// <param name="name">The name of the client to prefer. If set, this handler has priority over clients that have the given name.</param>
-
/// <param name="time">The time used to determine the priority of handlers when many are listening for the same
-
/// client <paramref name="name"/>. More recent values have higher priority.</param>
-
/// <exception cref="ArgumentNullException">Thrown if <paramref name="handler"/> is null.</exception>
-
public static void RegisterClientConnectHandler(Func<ICompanionAppClient, bool> handler, string name, DateTime time)
-
{
-
if (handler == null)
-
throw new ArgumentNullException(nameof(handler));
-
-
DeregisterClientConnectHandler(handler);
-
-
s_ClientConnectHandlers.Add(new ConnectHandler
-
{
-
Name = name,
-
Time = time,
-
Handler = handler,
-
});
-
}
-
-
/// <summary>
-
/// Removes a client connection callback.
-
/// </summary>
-
/// <param name="handler">The callback to remove.</param>>
-
/// <exception cref="ArgumentNullException">Thrown if <paramref name="handler"/> is null.</exception>
-
public static void DeregisterClientConnectHandler(Func<ICompanionAppClient, bool> handler)
-
{
-
if (handler == null)
-
throw new ArgumentNullException(nameof(handler));
-
-
for (var i = 0; i < s_ClientConnectHandlers.Count; i++)
-
{
-
if (s_ClientConnectHandlers[i].Handler == handler)
-
{
-
s_ClientConnectHandlers.RemoveAt(i);
-
}
-
}
-
}
-
-
public void Init()
-
{
-
foreach (var (type, attributes) in AttributeUtility.GetAllTypes<ClientAttribute>())
-
{
-
if (!typeof(CompanionAppClient).IsAssignableFrom(type))
-
{
-
Debug.LogError($"{type.FullName} must be assignable from {nameof(CompanionAppClient)} to use the {nameof(ClientAttribute)} attribute.");
-
continue;
-
}
-
-
foreach (var attribute in attributes)
-
{
-
s_TypeToClientType[attribute.Type] = type;
-
}
-
}
-
}
-
-
[SerializeField, Tooltip("The TCP port on which the server will listen for incoming connections. Changes to the port only take effect after restarting the server.")]
-
int m_Port = k_DefaultPort;
-
[SerializeField, Tooltip("Start the server automatically after entering play mode.")]
-
bool m_AutoStartOnPlay = true;
-
-
readonly DiscoveryServer m_Discovery = new DiscoveryServer();
-
readonly NetworkServer m_Server = new NetworkServer();
-
readonly Dictionary<Remote, ICompanionAppClient> m_RemoteToClient = new Dictionary<Remote, ICompanionAppClient>();
-
-
/// <summary>
-
/// The TCP port on which the server will listen for incoming connections.
-
/// </summary>
-
/// <remarks>
-
/// Changes to the port only take effect after restarting the server.
-
/// </remarks>
-
public int Port
-
{
-
get => m_Port;
-
set
-
{
-
if (m_Port != value)
-
{
-
m_Port = value;
-
OnServerChanged(true);
-
}
-
}
-
}
-
-
/// <summary>
-
/// Start the server automatically after entering play mode.
-
/// </summary>
-
public bool AutoStartOnPlay
-
{
-
get => m_AutoStartOnPlay;
-
set
-
{
-
if (m_AutoStartOnPlay != value)
-
{
-
m_AutoStartOnPlay = value;
-
OnServerChanged(true);
-
}
-
}
-
}
-
-
/// <summary>
-
/// Are clients able to connect to the server.
-
/// </summary>
-
public bool IsRunning => m_Server.IsRunning;
-
-
/// <summary>
-
/// The number of clients currently connected to the server.
-
/// </summary>
-
public int ClientCount => m_RemoteToClient.Count;
-
-
/// <inheritdoc/>
-
protected override void OnEnable()
-
{
-
base.OnEnable();
-
-
m_Server.RemoteConnected += OnClientConnected;
-
m_Server.RemoteDisconnected += OnClientDisconnected;
-
}
-
-
/// <inheritdoc/>
-
protected override void OnDisable()
-
{
-
base.OnDisable();
-
-
m_Discovery.Stop();
-
m_Server.Stop();
-
-
m_Server.RemoteConnected -= OnClientConnected;
-
m_Server.RemoteDisconnected -= OnClientDisconnected;
-
}
-
-
/// <summary>
-
/// Gets the currently connected clients.
-
/// </summary>
-
/// <returns>A new collection containing the client handles.</returns>
-
public IEnumerable<ICompanionAppClient> GetClients()
-
{
-
return m_RemoteToClient.Values;
-
}
-
-
/// <inheritdoc />
-
public override string GetName() => "Companion App Server";
-
-
/// <summary>
-
/// Start listening for clients connections.
-
/// </summary>
-
public void StartServer()
-
{
-
if (!NetworkUtilities.IsPortAvailable(m_Port))
-
{
-
Debug.LogError($"Unable to start server: Port {m_Port} is in use by another program! Close the other program, or assign a free port using the Live Capture Window.");
-
return;
-
}
-
-
if (m_Server.StartServer(m_Port))
-
{
-
// start server discovery
-
var config = new ServerData(
-
"Live Capture",
-
Environment.MachineName,
-
m_Server.ID,
-
PackageUtility.GetVersion(LiveCaptureInfo.Version)
-
);
-
var endPoints = m_Server.EndPoints.ToArray();
-
-
m_Discovery.Start(config, endPoints);
-
}
-
-
OnServerChanged(false);
-
}
-
-
/// <summary>
-
/// Disconnects all clients and stop listening for new connections.
-
/// </summary>
-
public void StopServer()
-
{
-
m_Server.Stop();
-
m_Discovery.Stop();
-
-
OnServerChanged(false);
-
}
-
-
/// <inheritdoc/>
-
public override void OnUpdate()
-
{
-
m_Server.Update();
-
m_Discovery.Update();
-
}
-
-
void OnClientConnected(Remote remote)
-
{
-
m_Server.RegisterMessageHandler(remote, InitializeClient, false);
-
}
-
-
void OnClientDisconnected(Remote remote, DisconnectStatus status)
-
{
-
if (m_RemoteToClient.TryGetValue(remote, out var client))
-
{
-
try
-
{
-
ClientDisconnected.Invoke(client);
-
}
-
catch (Exception e)
-
{
-
Debug.LogError(e);
-
}
-
-
m_RemoteToClient.Remove(remote);
-
OnServerChanged(false);
-
}
-
}
-
-
void InitializeClient(Message message)
-
{
-
try
-
{
-
if (message.ChannelType != ChannelType.ReliableOrdered)
-
{
-
return;
-
}
-
-
var streamReader = new StreamReader(message.Data, Encoding.UTF8);
-
var json = streamReader.ReadToEnd();
-
var data = default(ClientInitialization);
-
-
try
-
{
-
data = JsonUtility.FromJson<ClientInitialization>(json);
-
}
-
catch (Exception)
-
{
-
Debug.LogError($"{nameof(CompanionAppServer)} failed to initialize client connection! Could not parse JSON: {json}");
-
return;
-
}
-
-
if (!s_TypeToClientType.TryGetValue(data.Type, out var clientType))
-
{
-
Debug.LogError($"Unknown client type \"{data.Type}\" connected to {nameof(CompanionAppServer)}!");
-
return;
-
}
-
-
var remote = message.Remote;
-
var client = Activator.CreateInstance(clientType, m_Server, remote, data) as CompanionAppClient;
-
client.SendProtocol();
-
-
m_RemoteToClient.Add(remote, client);
-
-
AssignOwner(client);
-
-
ClientConnected.Invoke(client);
-
OnServerChanged(false);
-
}
-
catch (Exception e)
-
{
-
Debug.LogException(e);
-
}
-
finally
-
{
-
message.Dispose();
-
}
-
}
-
-
void AssignOwner(ICompanionAppClient client)
-
{
-
// connect to the registered handler that was most recently used with this client if possible
-
foreach (var handler in s_ClientConnectHandlers.OrderByDescending(h => h.Time.Ticks))
-
{
-
try
-
{
-
if (handler.Name == client.Name)
-
{
-
if (handler.Handler(client))
-
return;
-
}
-
}
-
catch (Exception e)
-
{
-
Debug.LogException(e);
-
}
-
}
-
-
// fall back to the first free device that is compatible with the client
-
foreach (var handler in s_ClientConnectHandlers)
-
{
-
try
-
{
-
if (handler.Handler(client))
-
return;
-
}
-
catch (Exception e)
-
{
-
Debug.LogException(e);
-
}
-
}
-
}
-
}
-
}
更改CompanionAppDevice类：
-
using System;
-
using UnityEngine;
-
-
namespace Unity.LiveCapture.CompanionApp
-
{
-
/// <summary>
-
/// A type of <see cref="LiveCaptureDevice"/> that uses a <see cref="ICompanionAppClient"/> for communication.
-
/// </summary>
-
interface ICompanionAppDevice
-
{
-
/// <summary>
-
/// Clears the client assigned to this device.
-
/// </summary>
-
void ClearClient();
-
}
-
-
/// <summary>
-
/// A type of <see cref="LiveCaptureDevice"/> that uses a <see cref="ICompanionAppClient"/> for communication.
-
/// </summary>
-
/// <typeparam name="TClient">The type of client this device communicates with.</typeparam>
-
public abstract class CompanionAppDevice<TClient> : LiveCaptureDevice, ICompanionAppDevice
-
where TClient : class, ICompanionAppClient
-
{
-
bool m_ClientRegistered;
-
bool m_Recording;
-
TClient m_Client;
-
readonly SlateChangeTracker m_SlateChangeTracker = new SlateChangeTracker();
-
readonly TakeNameFormatter m_TakeNameFormatter = new TakeNameFormatter();
-
string m_LastAssetName;
-
-
bool TryGetInternalClient(out ICompanionAppClientInternal client)
-
{
-
client = m_Client as ICompanionAppClientInternal;
-
-
return client != null;
-
}
-
-
/// <summary>
-
/// This function is called when the object becomes enabled and active.
-
/// </summary>
-
protected virtual void OnEnable()
-
{
-
CompanionAppServer.ClientDisconnected += OnClientDisconnected;
-
LiveCaptureServer.ClientDisconnected += OnClientDisconnected;
-
RegisterClient();
-
}
-
-
/// <summary>
-
/// This function is called when the behaviour becomes disabled.
-
/// </summary>
-
/// <remaks>
-
/// This is also called when the object is destroyed and can be used for any cleanup code.
-
/// When scripts are reloaded after compilation has finished, OnDisable will be called, followed by an OnEnable after the script has been loaded.
-
/// </remaks>
-
protected virtual void OnDisable()
-
{
-
CompanionAppServer.ClientDisconnected -= OnClientDisconnected;
-
CompanionAppServer.DeregisterClientConnectHandler(OnClientConnected);
-
LiveCaptureServer.ClientConnected -= OnClientDisconnected;
-
LiveCaptureServer.DeregisterClientConnectHandler(OnClientConnected);
-
-
StopRecording();
-
UnregisterClient();
-
}
-
-
/// <summary>
-
/// This function is called when the behaviour gets destroyed.
-
/// </summary>
-
protected override void OnDestroy()
-
{
-
base.OnDestroy();
-
-
ClearClient();
-
}
-
-
/// <inheritdoc/>
-
public override bool IsReady()
-
{
-
return m_Client != null;
-
}
-
-
/// <inheritdoc/>
-
public override bool IsRecording()
-
{
-
return m_Recording;
-
}
-
-
/// <inheritdoc/>
-
public override void StartRecording()
-
{
-
if (!m_Recording)
-
{
-
m_Recording = true;
-
-
OnRecordingChanged();
-
SendRecordingState();
-
}
-
}
-
-
/// <inheritdoc/>
-
public override void StopRecording()
-
{
-
if (m_Recording)
-
{
-
m_Recording = false;
-
-
OnRecordingChanged();
-
SendRecordingState();
-
}
-
}
-
-
/// <summary>
-
/// Gets the client currently assigned to this device.
-
/// </summary>
-
/// <returns>The assigned client, or null if none is assigned.</returns>
-
public TClient GetClient()
-
{
-
return m_Client;
-
}
-
-
/// <summary>
-
/// Assigns a client to this device.
-
/// </summary>
-
/// <param name="client">The client to assign, or null to clear the assigned client.</param>
-
/// <param name="rememberAssignment">Try to auto-assign the client to this device when it reconnects in the future.</param>
-
public void SetClient(TClient client, bool rememberAssignment)
-
{
-
if (m_Client != client)
-
{
-
UnregisterClient();
-
-
if (m_Client != null)
-
{
-
ClientMappingDatabase.DeregisterClientAssociation(this, m_Client, rememberAssignment);
-
}
-
-
m_Client = client;
-
-
if (m_Client != null)
-
{
-
// if any device is also using this client, we must clear the client from the previous device.
-
if (ClientMappingDatabase.TryGetDevice(client, out var previousDevice))
-
{
-
previousDevice.ClearClient();
-
}
-
-
ClientMappingDatabase.RegisterClientAssociation(this, m_Client, rememberAssignment);
-
}
-
-
RegisterClient();
-
}
-
}
-
-
void RegisterClient()
-
{
-
if (!isActiveAndEnabled || m_ClientRegistered)
-
{
-
return;
-
}
-
-
LiveCaptureServer.DeregisterClientConnectHandler(OnClientConnected);
-
CompanionAppServer.DeregisterClientConnectHandler(OnClientConnected);
-
-
m_SlateChangeTracker.Reset();
-
-
if (TryGetInternalClient(out var client))
-
{
-
client.SetDeviceMode += ClientSetDeviceMode;
-
client.StartRecording += ClientStartRecording;
-
client.StopRecording += ClientStopRecording;
-
client.StartPlayer += ClientStartPlayer;
-
client.StopPlayer += ClientStopPlayer;
-
client.PausePlayer += ClientPausePlayer;
-
client.SetPlayerTime += ClientSetPlayerTime;
-
client.SetSelectedTake += ClientSetSelectedTake;
-
client.SetTakeData += ClientSetTakeData;
-
client.DeleteTake += ClientDeleteTake;
-
client.SetIterationBase += ClientSetIterationBase;
-
client.ClearIterationBase += ClientClearIterationBase;
-
client.TexturePreviewRequested += OnTexturePreviewRequested;
-
-
OnClientAssigned();
-
-
client.SendInitialize();
-
-
UpdateClient();
-
-
m_ClientRegistered = true;
-
}
-
else
-
{
-
ClientMappingDatabase.TryGetClientAssignment(this, out var clientName, out var time);
-
LiveCaptureServer.RegisterClientConnectHandler(OnClientConnected, clientName, time);
-
CompanionAppServer.RegisterClientConnectHandler(OnClientConnected, clientName, time);
-
}
-
}
-
-
void UnregisterClient()
-
{
-
if (!m_ClientRegistered)
-
{
-
return;
-
}
-
-
if (TryGetInternalClient(out var client))
-
{
-
OnClientUnassigned();
-
-
client.SendEndSession();
-
client.SetDeviceMode -= ClientSetDeviceMode;
-
client.StartRecording -= ClientStartRecording;
-
client.StopRecording -= ClientStopRecording;
-
client.StartPlayer -= ClientStartPlayer;
-
client.StopPlayer -= ClientStopPlayer;
-
client.PausePlayer -= ClientPausePlayer;
-
client.SetPlayerTime -= ClientSetPlayerTime;
-
client.SetSelectedTake -= ClientSetSelectedTake;
-
client.SetTakeData -= ClientSetTakeData;
-
client.DeleteTake -= ClientDeleteTake;
-
client.SetIterationBase -= ClientSetIterationBase;
-
client.ClearIterationBase -= ClientClearIterationBase;
-
client.TexturePreviewRequested -= OnTexturePreviewRequested;
-
-
m_ClientRegistered = false;
-
}
-
}
-
-
/// <inheritdoc />
-
public void ClearClient()
-
{
-
SetClient(null, true);
-
}
-
-
/// <summary>
-
/// Called to send the device state to the client.
-
/// </summary>
-
public virtual void UpdateClient()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
SendDeviceState(takeRecorder.IsLive());
-
-
var slate = takeRecorder.GetActiveSlate();
-
var hasSlate = slate != null;
-
var slateChanged = m_SlateChangeTracker.Changed(slate);
-
var take = hasSlate ? slate.Take : null;
-
-
var assetName = GetAssetName();
-
var assetNameChanged = assetName != m_LastAssetName;
-
m_LastAssetName = assetName;
-
-
if (TryGetInternalClient(out var client))
-
{
-
client.SendFrameRate(takeRecorder.IsLive() || take == null ? takeRecorder.FrameRate : take.FrameRate);
-
client.SendHasSlate(hasSlate);
-
client.SendSlateDuration(hasSlate ? slate.Duration : 0d);
-
client.SendSlateIsPreviewing(takeRecorder.IsPreviewPlaying());
-
client.SendSlatePreviewTime(takeRecorder.GetPreviewTime());
-
-
if (slateChanged || assetNameChanged)
-
{
-
if (hasSlate)
-
m_TakeNameFormatter.ConfigureTake(slate.SceneNumber, slate.ShotName, slate.TakeNumber);
-
else
-
m_TakeNameFormatter.ConfigureTake(0, "Shot", 0);
-
-
client.SendNextTakeName(m_TakeNameFormatter.GetTakeName());
-
client.SendNextAssetName(m_TakeNameFormatter.GetAssetName());
-
}
-
}
-
-
if (slateChanged)
-
{
-
SendSlateDescriptor(slate);
-
}
-
}
-
-
SendRecordingState();
-
}
-
-
/// <summary>
-
/// Gets the name used for the take asset name.
-
/// </summary>
-
/// <returns>The name of the asset.</returns>
-
protected virtual string GetAssetName() { return name; }
-
-
/// <summary>
-
/// The device calls this method when a new client is assigned.
-
/// </summary>
-
protected virtual void OnClientAssigned() {}
-
-
/// <summary>
-
/// The device calls this method when the client is unassigned.
-
/// </summary>
-
protected virtual void OnClientUnassigned() {}
-
-
/// <summary>
-
/// The device calls this method when the recording state has changed.
-
/// </summary>
-
protected virtual void OnRecordingChanged() {}
-
-
/// <summary>
-
/// The device calls this method when the slate has changed.
-
/// </summary>
-
protected virtual void OnSlateChanged(ISlate slate) {}
-
-
void ClientStartRecording()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.StartRecording();
-
}
-
-
Refresh();
-
}
-
-
void ClientStopRecording()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.StopRecording();
-
}
-
-
Refresh();
-
}
-
-
void ClientSetDeviceMode(DeviceMode deviceMode)
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.SetLive(deviceMode == DeviceMode.LiveStream);
-
-
SendDeviceState(takeRecorder.IsLive());
-
}
-
}
-
-
void ClientStartPlayer()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.PlayPreview();
-
}
-
-
Refresh();
-
}
-
-
void ClientStopPlayer()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.PausePreview();
-
takeRecorder.SetPreviewTime(0d);
-
}
-
-
Refresh();
-
}
-
-
void ClientPausePlayer()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.PausePreview();
-
}
-
-
Refresh();
-
}
-
-
void ClientSetPlayerTime(double time)
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
takeRecorder.SetPreviewTime(time);
-
}
-
-
Refresh();
-
}
-
-
void SendDeviceState()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
SendDeviceState(takeRecorder.IsLive());
-
}
-
}
-
-
void SendDeviceState(bool isLive)
-
{
-
if (TryGetInternalClient(out var client))
-
{
-
client.SendDeviceMode(isLive ? DeviceMode.LiveStream : DeviceMode.Playback);
-
}
-
}
-
-
void SendRecordingState()
-
{
-
if (TryGetInternalClient(out var client))
-
{
-
client.SendRecordingState(IsRecording());
-
}
-
}
-
-
void SendSlateDescriptor()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
SendSlateDescriptor(takeRecorder.GetActiveSlate());
-
}
-
}
-
-
void SendSlateDescriptor(ISlate slate)
-
{
-
if (TryGetInternalClient(out var client))
-
{
-
client.SendSlateDescriptor(SlateDescriptor.Create(slate));
-
}
-
-
OnSlateChanged(slate);
-
}
-
-
void ClientSetSelectedTake(Guid guid)
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
TakeManager.Default.SelectTake(takeRecorder.GetActiveSlate(), guid);
-
-
SendSlateDescriptor();
-
Refresh();
-
}
-
}
-
-
void ClientSetTakeData(TakeDescriptor descriptor)
-
{
-
TakeManager.Default.SetTakeData(descriptor);
-
-
SendSlateDescriptor();
-
Refresh();
-
}
-
-
void ClientDeleteTake(Guid guid)
-
{
-
TakeManager.Default.DeleteTake(guid);
-
-
SendSlateDescriptor();
-
Refresh();
-
}
-
-
void ClientSetIterationBase(Guid guid)
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
var slate = takeRecorder.GetActiveSlate();
-
-
TakeManager.Default.SetIterationBase(slate, guid);
-
-
SendSlateDescriptor(slate);
-
Refresh();
-
}
-
}
-
-
void ClientClearIterationBase()
-
{
-
var takeRecorder = GetTakeRecorder();
-
-
if (takeRecorder != null)
-
{
-
var slate = takeRecorder.GetActiveSlate();
-
-
TakeManager.Default.ClearIterationBase(slate);
-
-
SendSlateDescriptor(slate);
-
Refresh();
-
}
-
}
-
-
void OnTexturePreviewRequested(Guid guid)
-
{
-
var texture = TakeManager.Default.GetAssetPreview<Texture2D>(guid);
-
-
if (texture != null && TryGetInternalClient(out var client))
-
{
-
client.SendTexturePreview(guid, texture);
-
}
-
}
-
-
bool OnClientConnected(ICompanionAppClient client)
-
{
-
if (m_Client == null && client is TClient c && (!ClientMappingDatabase.TryGetClientAssignment(this, out var clientName, out _) || c.Name == clientName))
-
{
-
SetClient(c, false);
-
return true;
-
}
-
return false;
-
}
-
-
void OnClientDisconnected(ICompanionAppClient client)
-
{
-
if (m_Client == client)
-
{
-
SetClient(null, false);
-
}
-
}
-
}
-
}
本人打包后成功运行，测试脚本：
-
using UnityEngine;
-
using Unity.LiveCapture.CompanionApp;
-
-
public class LiveCaptureExample : MonoBehaviour
-
{
-
LiveCaptureServer server;
-
private void Awake()
-
{
-
server = Resources.Load<LiveCaptureServer>("Live Capture Server");
-
server.Init();
-
server.StartServer();
-
}
-
private void Update()
-
{
-
server.OnUpdate();
-
}
-
private void OnDestroy()
-
{
-
server.StopServer();
-
}
-
}
文章来源: coderz.blog.csdn.net，作者：CoderZ1010，版权归原作者所有，如需转载，请联系作者。
原文链接：coderz.blog.csdn.net/article/details/123455444
【版权声明】本文为华为云社区用户转载文章，如果您发现本社区中有涉嫌抄袭的内容，欢迎发送邮件进行举报，并提供相关证据，一经查实，本社区将立刻删除涉嫌侵权内容，举报邮箱：
cloudbbs@huaweicloud.com
- 点赞
- 收藏
- 关注作者
评论（0）
