JavaScript 瀑布
【摘要】
<!DOCTYPE html>
<html>
<head>
<meta charset="utf8">
<me...
<!DOCTYPE html>
<html>
<head>
<meta charset="utf8">
<meta http-equiv=“X-UA-Compatible” content="IE-edge, chrome=1">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>瀑布(waterful)</title>
<style>
body {
background: #222;
}
</style>
</head>
<body>
<script>
//判断浏览器是否支持canvas
function isSupportCanvas() {
var canvas = document.createElement('canvas');
return !!(canvas.getContext && canvas.getContext("2d"));
}
//requestAnimationFrame会自动使用最优的帧率进行渲染,在我的浏览器上是每秒60帧
function setupRAF() {
var lastTime = 0;
var vendors = ['webkit', 'ms', 'moz', 'o'];
for(var i=0; i<vendors.length && !window.requestAnimationFrame; i++) {
window.requestAnimationFrame = window[vendors[i] + "RequestAnimationFrame"];
window.cancelAnimationFrame = window[vendors[i] + "CancelAnimationFrame"] || window[vendors[i] + "CancelRequestAnimationFrame"]
}
if(!window.requestAnimationFrame) {
window.requestAnimationFrame = function(callback, element) {
var currentTime = new Date().getTime();
var timeToCall = Math.max(0, 16 - (currentTime - lastTime));
var futureTime = currentTime + timeToCall;
var id = window.setTimeout(function() {
callback(futureTime);
}, timeToCall);
lastTime = futureTime;
return id;
}
}
if(!window.cancelAnimationFrame) {
window.cancelAnimationFrame = function(id) {
clearTimeout(id);
}
}
}
//在给定的范围内随机选取一个整数
function randomInt(min, max) {
/*
由于位运算的操作数要求是整数，其结果也是整数，所以经过位运算的都会自动变成整数
可用的取整方法：
(1)~~n
(2)n<<0
(3)n>>0
(4)n|0
(5)Math.floor()
(6)Math.ceil()
(7)Math.round()
值得注意的是，位运算只是去掉小数部分，并不会改变整数部分
*/
return ~~(Math.random() * (max - min) + min);
}
//在对象所表示的范围中随机选取一个数
function randomAtRange(obj) {
return Math.random() * (obj.max - obj.min) + obj.min;
}
//在对象所表示的范围中随机选取一个整数
function randomIntAtRange(obj) {
return randomInt(obj.min, obj.max);
}
//瀑布
var Waterful = function(width, height) {
var doublePI = Math.PI * 2;
var canvas;
var ctx;
//存放水粒子的数组
var particles = [];
//每帧生成或销毁粒子的数量
var particleChangeRate = width / 25;
//垂直方向上的加速度(即重力), 小数点前的0可以省略
var gravity = .15;
//水流粒子
var WaterParticle = function() {
//水流粒子宽度范围
var waterWidthRange = {min: 1, max: 20};
//水流粒子高度范围
var waterHeightRange = {min: 1, max: 45};
//水流粒子落到地上溅起的水花半径范围
var waterBubbleRadiusRange = {min: 1, max: 8};
//水花溅起的高度范围
var waterBubbleSpringRange = {min: 20, max: 30};
//色相范围
var hueRange = {min: 200, max: 220};
//饱和度范围
var saturationRange = {min: 30, max: 60};
//亮度
var lightnessRange = {min: 30, max: 60};
//拼接成一个HSLA颜色值(注意：普通函数的this指代它自己)
this.joinHSLA = function(alpha) {
return "hsla(" + [this.hue, this.saturation + "%", this.lightness + "%", alpha].join(",") + ")";
}
this.init = function() {
//水流粒子的最大半径
var waterMaxRadius = waterWidthRange.max / 2;
//水流粒子初始X坐标的范围
var xRange = {min: waterMaxRadius, max: canvas.width - waterMaxRadius};
//水流粒子宽度
this.width = randomAtRange(waterWidthRange);
//水流粒子高度
this.height = randomAtRange(waterHeightRange);
//水流粒子初始X坐标
this.x = randomAtRange(xRange);
//水流粒子初始Y坐标
this.y = -this.height;
//水流粒子垂直方向上的初始速度
this.velocity = 0;
//水流半径等于水流粒子宽度的一半
this.waterRadius = this.width / 2;
//水花半径
this.waterBubbleRadius = randomAtRange(waterBubbleRadiusRange);
//水花溅起的高度
this.waterBubbleSpring = randomAtRange(waterBubbleSpringRange);
//水流颜色
this.hue = randomIntAtRange(hueRange);
this.saturation = randomIntAtRange(saturationRange);
this.lightness = randomIntAtRange(lightnessRange);
//地板高度
this.floorHeight = canvas.height - waterBubbleSpringRange.min - this.height;
//水流粒子是否已经落地变成水花
this.isDead = false;
}
this.update = function() {
this.velocity += gravity;
this.y += this.velocity;
if(this.y > this.floorHeight) {
this.isDead = true;
}
}
this.render = function() {
if(this.isDead) {
//绘制水花
ctx.fillStyle = "hsla(" + this.hue + ", 40%, 40%, 1)";
ctx.fillStyle = this.joinHSLA(.3);
ctx.beginPath();
ctx.arc(this.x, canvas.height - this.waterBubbleSpring, this.waterBubbleRadius, 0, doublePI);
ctx.fill();
} else {
//绘制水流
ctx.strokeStyle = this.joinHSLA(.05);
ctx.lineCap = "round";
ctx.lineWidth = this.waterRadius;
ctx.beginPath();
ctx.moveTo(this.x, this.y);
ctx.lineTo(this.x, this.y + this.height);
ctx.stroke();
}
}
this.init();
}
this.init = function() {
canvas = document.createElement("canvas");
//如果html不支持canvas的话会显示该文本，否则不显示
var textNode = document.createTextNode("Your browser can not support canvas");
canvas.appendChild(textNode);
document.body.appendChild(canvas);
canvas.width = width;
canvas.height = height;
//如果不支持canvas就没必要继续下去了
if(!isSupportCanvas()) {
return;
}
ctx = canvas.getContext("2d");
setupRAF();
loop();
}
function loop() {
/*
先绘制一层朦胧的白非常重要，这样可以省去很多用来填充颜色的粒子
将下面3句换成clearRect就能发现其实绘制的粒子颜色本身是很淡的，如果直接换成深的颜色就会发现空隙衔接处很不均匀
增大粒子数目可以发现颜色会变深，但是粒子数越多画面越卡，所以先绘制上一层白色的蒙版是一种非常取巧的做法
*/
ctx.globalCompositeOperation = 'destination-out';
ctx.fillStyle = 'rgba(255,255,255,.06)';
ctx.fillRect(0, 0, canvas.width, canvas.height);
//ctx.clearRect(0, 0, canvas.width, canvas.height);
ctx.globalCompositeOperation = "lighter";
//添加新粒子
for(var i=0; i<particleChangeRate; i++) {
particles.push(new WaterParticle());
}
//更新渲染粒子
for(var i=0; i<particles.length; i++) {
particles[i].update();
particles[i].render();
}
//绘制水花，并删除消亡的粒子
for(var i=particles.length-1; i>=0; i--) {
if(particles[i].isDead) {
particles.splice(i, 1);
}
}
requestAnimationFrame(loop);
}
}
function init() {
var waterful = new Waterful(300, 300);
waterful.init();
}
init();
</script>
</body>
</html>
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
- 26
- 27
- 28
- 29
- 30
- 31
- 32
- 33
- 34
- 35
- 36
- 37
- 38
- 39
- 40
- 41
- 42
- 43
- 44
- 45
- 46
- 47
- 48
- 49
- 50
- 51
- 52
- 53
- 54
- 55
- 56
- 57
- 58
- 59
- 60
- 61
- 62
- 63
- 64
- 65
- 66
- 67
- 68
- 69
- 70
- 71
- 72
- 73
- 74
- 75
- 76
- 77
- 78
- 79
- 80
- 81
- 82
- 83
- 84
- 85
- 86
- 87
- 88
- 89
- 90
- 91
- 92
- 93
- 94
- 95
- 96
- 97
- 98
- 99
- 100
- 101
- 102
- 103
- 104
- 105
- 106
- 107
- 108
- 109
- 110
- 111
- 112
- 113
- 114
- 115
- 116
- 117
- 118
- 119
- 120
- 121
- 122
- 123
- 124
- 125
- 126
- 127
- 128
- 129
- 130
- 131
- 132
- 133
- 134
- 135
- 136
- 137
- 138
- 139
- 140
- 141
- 142
- 143
- 144
- 145
- 146
- 147
- 148
- 149
- 150
- 151
- 152
- 153
- 154
- 155
- 156
- 157
- 158
- 159
- 160
- 161
- 162
- 163
- 164
- 165
- 166
- 167
- 168
- 169
- 170
- 171
- 172
- 173
- 174
- 175
- 176
- 177
- 178
- 179
- 180
- 181
- 182
- 183
- 184
- 185
- 186
- 187
- 188
- 189
- 190
- 191
- 192
- 193
- 194
- 195
- 196
- 197
- 198
- 199
- 200
- 201
- 202
- 203
- 204
- 205
- 206
- 207
- 208
- 209
- 210
- 211
- 212
- 213
- 214
- 215
- 216
- 217
- 218
- 219
- 220
- 221
- 222
- 223
- 224
- 225
- 226
- 227
- 228
- 229
- 230
- 231
- 232
- 233
- 234
文章来源: blog.csdn.net，作者：福州-司马懿，版权归原作者所有，如需转载，请联系作者。
原文链接：blog.csdn.net/chy555chy/article/details/54730336
