目录

Sink

预定义Sink

基于控制台和文件的Sink

自定义Sink

MySQL

Sink

预定义Sink

基于控制台和文件的Sink

• API

1.ds.print 直接输出到控制台

2.ds.printToErr() 直接输出到控制台,用红色

3.ds.writeAsText("本地/HDFS的path",WriteMode.OVERWRITE).setParallelism(1)

• 注意:

在输出到path的时候,可以在前面设置并行度,如果

并行度>1,则path为目录

并行度=1,则path为文件名

• 代码演示:














      package cn.itcast.sink;


























      import org.apache.flink.core.fs.FileSystem;













      import org.apache.flink.streaming.api.datastream.DataStream;













      import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;


























      /**













       * Author itcast













       * Desc













       * 1.ds.print 直接输出到控制台













       * 2.ds.printToErr() 直接输出到控制台,用红色













       * 3.ds.collect 将分布式数据收集为本地集合













       * 4.ds.setParallelism(1).writeAsText("本地/HDFS的path",WriteMode.OVERWRITE)













       */













      public class SinkDemo01 {













          public static void main(String[] args) throws Exception {













              //1.env













              StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();


























              //2.source













              //DataStream<String> ds = env.fromElements("hadoop", "flink");













              DataStream<String> ds = env.readTextFile("data/input/words.txt");


























              //3.transformation













              //4.sink













              ds.print();













              ds.printToErr();













              ds.writeAsText("data/output/test", FileSystem.WriteMode.OVERWRITE).setParallelism(2);













              //注意:













              //Parallelism=1为文件













              //Parallelism>1为文件夹


























              //5.execute













              env.execute();













          }













      }





自定义Sink

MySQL

• 需求:

将Flink集合中的数据通过自定义Sink保存到MySQL

• 代码实现:














      package cn.itcast.sink;


























      import lombok.AllArgsConstructor;













      import lombok.Data;













      import lombok.NoArgsConstructor;













      import org.apache.flink.configuration.Configuration;













      import org.apache.flink.streaming.api.datastream.DataStream;













      import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;













      import org.apache.flink.streaming.api.functions.sink.RichSinkFunction;


























      import java.sql.Connection;













      import java.sql.DriverManager;













      import java.sql.PreparedStatement;


























      /**













       * Author itcast













       * Desc













       * 使用自定义sink将数据保存到MySQL













       */













      public class SinkDemo02_MySQL {













          public static void main(String[] args) throws Exception {













              //1.env













              StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();













              //2.Source













              DataStream<Student> studentDS = env.fromElements(new Student(null, "tonyma", 18));













              //3.Transformation













              //4.Sink













              studentDS.addSink(new MySQLSink());


























              //5.execute













              env.execute();













          }













          @Data













          @NoArgsConstructor













          @AllArgsConstructor













          public static class Student {













              private Integer id;













              private String name;













              private Integer age;













          }


























          public static class MySQLSink extends RichSinkFunction<Student> {













              private Connection conn = null;













              private PreparedStatement ps = null;


























              @Override













              public void open(Configuration parameters) throws Exception {













                  //加载驱动,开启连接













                  //Class.forName("com.mysql.jdbc.Driver");













                  conn = DriverManager.getConnection("jdbc:mysql://localhost:3306/bigdata", "root", "root");













                  String sql = "INSERT INTO `t_student` (`id`, `name`, `age`) VALUES (null, ?, ?)";













                  ps = conn.prepareStatement(sql);













              }


























              @Override













              public void invoke(Student value, Context context) throws Exception {













                  //给ps中的?设置具体值













                  ps.setString(1,value.getName());













                  ps.setInt(2,value.getAge());













                  //执行sql













                  ps.executeUpdate();













              }


























              @Override













              public void close() throws Exception {













                  if (conn != null) conn.close();













                  if (ps != null) ps.close();













              }













          }













      }
