【画图】基于Python的神经网络可视化工具

项目链接：

https://github.com/Prodicode/ann-visualizer?utm_source=mybridge&utm_medium=blog&utm_campaign=read_more

A python library for visualizing Artificial Neural Networks (ANN)

如何安装

From Github

1. Download the ann_visualizer folder from the github repository.
2. Place the ann_visualizer folder in the same directory as your main python script.

From pip

Use the following command:

pip3 install ann_visualizer


Make sure you have graphviz installed. Install it using:

sudo apt-get install graphviz && pip3 install graphviz


人工神经网络绘图示例














      import keras;













      from keras.models import Sequential;













      from keras.layers import Dense;


























      network = Sequential();












 #Hidden Layer#1













      network.add(Dense(units=6,













       activation='relu',













       kernel_initializer='uniform',













       input_dim=11));

























 #Hidden Layer#2













      network.add(Dense(units=6,













       activation='relu',













       kernel_initializer='uniform'));

























 #Exit Layer













      network.add(Dense(units=1,













       activation='sigmoid',













       kernel_initializer='uniform'));


























      from ann_visualizer.visualize import ann_viz;


























      ann_viz(network, title="");





卷积神经网络绘图示例














      import keras;













      from keras.models import Sequential;













      from keras.layers import Dense;













      from ann_visualizer.visualize import ann_viz













      model = build_cnn_model()













      ann_viz(model, title="")


























      def build_cnn_model():













        model = keras.models.Sequential()


























        model.add(













       Conv2D(












 32, (3, 3),













       padding="same",













       input_shape=(32, 32, 3),













       activation="relu"))













        model.add(Dropout(0.2))


























        model.add(













       Conv2D(












 32, (3, 3),













       padding="same",













       input_shape=(32, 32, 3),













       activation="relu"))













        model.add(MaxPooling2D(pool_size=(2, 2)))













        model.add(Dropout(0.2))


























        model.add(













       Conv2D(












 64, (3, 3),













       padding="same",













       input_shape=(32, 32, 3),













       activation="relu"))













        model.add(Dropout(0.2))


























        model.add(













       Conv2D(












 64, (3, 3),













       padding="same",













       input_shape=(32, 32, 3),













       activation="relu"))













        model.add(MaxPooling2D(pool_size=(2, 2)))













        model.add(Dropout(0.2))


























        model.add(Flatten())













        model.add(Dense(512, activation="relu"))













        model.add(Dropout(0.2))


























        model.add(Dense(10, activation="softmax"))

























  return model
