一、适配目的

本任务的主要目的是让Rocketmq支持华为云，主要是在验证Rocketmq在华为云CCE上是否正常使用。帮助拓展华为云的影响力，也方便Rocketmq的用户能够轻松上云。

二、适配任务分析

1、使用最新版Rocketmq在华为CCE集群上完成部署并配置相关topic等。

2、开发并部署Rocketmq发送消息client和接受消息client。

3、验证消息收发功能是否正常。

注：本具体任务内容内容可以参考博客附件。

二、适配过程

1、部署Rocketmq集群

查看Rocketmq官网部署方式：https://rocketmq.apache.org/zh/docs/deploymentOperations/01deploy，可以看到Rocketmq支持多种部署方式，本次采用较为复杂的多节点（集群）多副本模式-同步双写部署方式。使用华为云CCE部署相关实例（容器的yaml文件见附件）。

其中包含2个主broker，每个主broker分别有一个从broker，3个nameserver，另外还部署了2个Rocketmq proxy用于Rocketmq集群的外部访问，后续发送消息client和接受消息client就是连接该proxy进行消息收发验证，再额外部署1个dashboard用于查看消息队列的情况。（dashboard安装和使用：https://rocketmq.apache.org/zh/docs/deploymentOperations/04Dashboard）

CCE配置截图如下：

部署过程中需要的容器镜像包括rocketmq，版本为5.3.1，用于部署broker、namespace、proxy实例。另外一个是dashboard的镜像，用于部署dashboard实例，镜像如图

部署成功之后，我们在集群使用如下命令新建topic，名称是TestTopic1，消费组为TestGroup

sh mqadmin updatetopic -t TestTopic1 -c TestGroup

2、开发并部署发送消息和接受消息client

验证使用https://github.com/apache/servicecomb-fence这个工程作为基础，在工程中引入Rocketmq接入sdk：

同时，接收到消息之后需要落库，我们需要连接GaussDB，链接配置如下

开发消息发送逻辑，其中endpoint是rocketmq的proxy地址，发送的topic是TestTopic1，已经配置好了：

  public String sendMsg(String msg) {

      // Endpoint address, set to the Proxy address and port list, usually xxx:8080;xxx:8081
      String endpoint = "192.168.0.137:8081";
      // The target Topic name for message sending, which needs to be created in advance.
      String topic = "TestTopic1";
      RocketMqMsg mqMsg = new RocketMqMsg();
      mqMsg.setMsgInfo(msg);
      mqMsg.setTopic(topic);
      ClientServiceProvider provider = ClientServiceProvider.loadService();
      ClientConfigurationBuilder builder = ClientConfiguration.newBuilder().setEndpoints(endpoint);
      ClientConfiguration configuration = builder.build();
      // When initializing Producer, communication configuration and pre-bound Topic need to be set.
      Producer producer = null;
      try {
          producer = provider.newProducerBuilder()
                  .setTopics(topic)
                  .setClientConfiguration(configuration)
                  .build();
      }catch (Exception e){

      }

      // Sending a normal message.
      Message message = provider.newMessageBuilder()
              .setTopic(topic)
              // Set the message index key, which can be used to accurately find a specific message.
              .setKeys("messageKey")
              // Set the message Tag, used by the consumer to filter messages by specified Tag.
              .setTag("messageTag")
              // Message body.
              .setBody(name.getBytes())
              .build();
      try {
          // Send the message, paying attention to the sending result and catching exceptions.
          SendReceipt sendReceipt = producer.send(message);

          logger.info("Send message successfully, messageId={}", sendReceipt.getMessageId());

      } catch (ClientException e) {
          logger.error("Failed to send message", e);
      }
      // producer.close();
      return mqMsg.getMsgId();
  }

开发接受消息并落库逻辑，接受的topic是TestTopic1，消费组是TestGroup。

public String consumeMsg() {
        final ClientServiceProvider provider = ClientServiceProvider.loadService();
        // Endpoint address, set to the Proxy address and port list, usually xxx:8080;xxx:8081
        String endpoints = "192.168.0.137:8081";
        ClientConfiguration clientConfiguration = ClientConfiguration.newBuilder()
              .setEndpoints(endpoints)
              .build();
        // Subscription message filtering rule, indicating subscription to all Tag messages.
        String tag = "*";
        FilterExpression filterExpression = new FilterExpression(tag, FilterExpressionType.TAG);
        // Specify the consumer group the consumer belongs to, Group needs to be created in advance.
        String consumerGroup = "TestGroup";
        // Specify which target Topic to subscribe to, Topic needs to be created in advance.
        String topic ="TestTopic1";

    try {
        // Initialize PushConsumer
        PushConsumer pushConsumer = provider.newPushConsumerBuilder()
                .setClientConfiguration(clientConfiguration)
                // Set the consumer group.
                .setConsumerGroup(consumerGroup)
                // Set pre-bound subscription relationship.
                .setSubscriptionExpressions(Collections.singletonMap(topic, filterExpression))
                // Set the message listener.
                .setMessageListener(messageView -> {
                    // Handle messages and return the consumption result.
                    System.out.println(messageView.getMessageId());
                    logger.info("Consume message successfully, messageId={}", messageView.getMessageId());

                    String str = StandardCharsets.UTF_8.decode(messageView.getBody()).toString();
                    rocketMqMsgLogicService.insert(messageView.getMessageId().toString(),
                            topic,str);
                    //info
                    return ConsumeResult.SUCCESS;
                }).build();
        Thread.sleep(Long.MAX_VALUE);
    } catch (Exception e) {
        logger.error(e.getMessage());
    }
    return "正在接受...";
  }

3、部署并验证

打包工程后，上传到华为云的一台ECS上，然后启动工程中的5个服务。

访问地址后点击发送消息，会返回消息ID：

然后点击接受消息，这样就可以从rocketmq获取消息。

通过测试接口/api/resource/v1/rocketMsg/getConsumedMsgByMsgId?msgId=01FA163E156D661D44074C839500000002，可以获取对应消息ID的具体落库信息：

三、交付件

(1) DEMO仓库地址: https://gitcode.com/uiu34/opensource-demo-rocketmq-20241116/overview

(2) DEMO开发提交记录: https://gitcode.com/uiu34/opensource-demo-rocketmq-20241116/commits/detail/22c93f4366d52153c262a7dc4a23f541e85b3425?ref=master

(3) 博客的地址: https://bbs.huaweicloud.com/blogs/439805

四、华为云资源清单

1.1 CCE

1.2 ECS

1.3 GuassDB
