安装Harbor仓库
【摘要】 安装Harbor 安装docker# 安装 apt 依赖包apt-get install \ apt-transport-https \ ca-certificates \ curl \ gnupg-agent \ software-properties-common# 添加 Docker 的官方 GPG 密钥curl -fsSL https://mirror...
安装Harbor
安装docker
# 安装 apt 依赖包
apt-get install \
apt-transport-https \
ca-certificates \
curl \
gnupg-agent \
software-properties-common
# 添加 Docker 的官方 GPG 密钥
curl -fsSL https://mirrors.ustc.edu.cn/docker-ce/linux/ubuntu/gpg | sudo apt-key add -
# 使用以下指令设置稳定版仓库
add-apt-repository \
"deb [arch=amd64] https://mirrors.ustc.edu.cn/docker-ce/linux/ubuntu/ \
$(lsb_release -cs) \
stable"
# 安装最新版本的 Docker Engine-Community 和 containerd
apt-get update
apt-get install docker-ce docker-ce-cli containerd.io
安装docker compose
# 配置Docker Compose
root@cby:~# wget https://ghproxy.com/https://github.com/docker/compose/releases/download/v2.12.2/docker-compose-linux-x86_64
root@cby:~# mv docker-compose-linux-x86_64 /usr/local/bin/docker-compose
root@cby:~# chmod +x /usr/local/bin/docker-compose
root@cby:~# docker-compose --version
Docker Compose version v2.12.2
root@cby:~#
下载harbor安装包
# 下载Docker Harbor安装包
wget https://ghproxy.com/https://github.com/goharbor/harbor/releases/download/v2.6.2/harbor-offline-installer-v2.6.2.tgz
# 解压安装包
root@cby:~# tar xvf harbor-offline-installer-v2.6.2.tgz -C /usr/local/
harbor/harbor.v2.6.2.tar.gz
harbor/prepare
harbor/LICENSE
harbor/install.sh
harbor/common.sh
harbor/harbor.yml.tmpl
root@cby:~# cd /usr/local/harbor/
创建证书
# 创建ca证书目录
root@cby:/usr/local/harbor# mkdir ca
root@cby:/usr/local/harbor# cd ca/
root@cby:/usr/local/harbor/ca#
# 生成CA证书私钥
root@cby:/usr/local/harbor/ca# openssl genrsa -out ca.key 4096
# 生成CA证书
root@cby:/usr/local/harbor/ca# openssl req -x509 -new -nodes -sha512 -days 3650 \
-subj "/C=CN/ST=Beijing/L=Beijing/O=example/OU=Personal/CN=hb.oiox.cn" \
-key ca.key \
-out ca.crt
# 生成服务器证书 生成私钥
root@cby:/usr/local/harbor/ca# openssl genrsa -out hb.oiox.cn.key 4096
# 生成证书签名请求（CSR）
root@cby:/usr/local/harbor/ca# openssl req -sha512 -new \
-subj "/C=CN/ST=Beijing/L=Beijing/O=example/OU=Personal/CN=hb.oiox.cn" \
-key hb.oiox.cn.key \
-out hb.oiox.cn.csr
# 生成一个x509 v3扩展文件
root@cby:/usr/local/harbor/ca# cat > v3.ext <<-EOF
authorityKeyIdentifier=keyid,issuer
basicConstraints=CA:FALSE
keyUsage = digitalSignature, nonRepudiation, keyEncipherment, dataEncipherment
extendedKeyUsage = serverAuth
subjectAltName = @alt_names
[alt_names]
DNS.1=oiox.cn
DNS.2=hb.oiox.cn
DNS.3=www.oiox.cn
EOF
# 使用该v3.ext文件为您的Harbor主机生成证书
root@cby:/usr/local/harbor/ca# openssl x509 -req -sha512 -days 3650 \
-extfile v3.ext \
-CA ca.crt -CAkey ca.key -CAcreateserial \
-in hb.oiox.cn.csr \
-out hb.oiox.cn.crt
配置docker证书
# 转换crt为cert，供Docker使用，Docker守护程序将.crt文件解释为CA证书，并将.cert文件解释为客户端证书
root@cby:/usr/local/harbor/ca# openssl x509 -inform PEM -in hb.oiox.cn.crt -out hb.oiox.cn.cert
# 将服务器证书，密钥和CA文件复制到Harbor主机上的Docker证书文件夹中。您必须首先创建适当的文件夹
root@cby:/usr/local/harbor/ca# mkdir -p /etc/docker/certs.d/hb.oiox.cn/
root@cby:/usr/local/harbor/ca# cp hb.oiox.cn.cert /etc/docker/certs.d/hb.oiox.cn/
root@cby:/usr/local/harbor/ca# cp hb.oiox.cn.key /etc/docker/certs.d/hb.oiox.cn/
root@cby:/usr/local/harbor/ca# cp ca.crt /etc/docker/certs.d/hb.oiox.cn/
# 如果将默认nginx端口443 映射到其他端口，请创建文件夹
# /etc/docker/certs.d/yourdomain.com:port
# 重新启动Docker Engine
root@cby:/usr/local/harbor/ca# systemctl restart docker
查看文件
# 查看目录下证书文件
root@cby:/usr/local/harbor/ca# ll
total 36
drwxr-xr-x 2 root root 4096 Nov 16 06:23 ./
drwxr-xr-x 5 root root 4096 Nov 16 06:16 ../
-rw-r--r-- 1 root root 2041 Nov 16 06:20 ca.crt
-rw------- 1 root root 3272 Nov 16 06:16 ca.key
-rw-r--r-- 1 root root 2143 Nov 16 06:23 hb.oiox.cn.cert
-rw-r--r-- 1 root root 2143 Nov 16 06:22 hb.oiox.cn.crt
-rw-r--r-- 1 root root 1704 Nov 16 06:22 hb.oiox.cn.csr
-rw------- 1 root root 3268 Nov 16 06:22 hb.oiox.cn.key
-rw-r--r-- 1 root root 261 Nov 16 06:22 v3.ext
root@cby:/usr/local/harbor/ca#
配置harbor服务
# 配置harbor文件
root@cby:/usr/local/harbor# cp harbor.yml.tmpl harbor.yml
root@cby:/usr/local/harbor# vim harbor.yml
root@cby:/usr/local/harbor# cat harbor.yml | grep -v '^#' | grep -v '^$' | grep -v ' #'
hostname: hb.oiox.cn
http:
port: 80
https:
port: 443
certificate: /usr/local/harbor/ca/hb.oiox.cn.crt
private_key: /usr/local/harbor/ca/hb.oiox.cn.key
harbor_admin_password: Harbor12345
database:
password: root123
max_idle_conns: 100
max_open_conns: 900
data_volume: /data
trivy:
ignore_unfixed: false
skip_update: false
offline_scan: false
security_check: vuln
insecure: false
jobservice:
max_job_workers: 10
notification:
webhook_job_max_retry: 10
chart:
absolute_url: disabled
log:
level: info
local:
rotate_count: 50
rotate_size: 200M
location: /var/log/harbor
_version: 2.6.0
proxy:
http_proxy:
https_proxy:
no_proxy:
components:
- core
- jobservice
- trivy
upload_purging:
enabled: true
age: 168h
interval: 24h
dryrun: false
cache:
enabled: false
expire_hours: 24
root@cby:/usr/local/harbor#
安装harbor
# 进行安装
root@cby:/usr/local/harbor# ./install.sh
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
tput: No value for $TERM and no -T specified
[Step 0]: checking if docker is installed ...
Note: docker version: 20.10.21
[Step 1]: checking docker-compose is installed ...
Note: docker-compose version: 2.12.2
[Step 2]: loading Harbor images ...
Loaded image: goharbor/harbor-jobservice:v2.6.2
Loaded image: goharbor/trivy-adapter-photon:v2.6.2
Loaded image: goharbor/chartmuseum-photon:v2.6.2
Loaded image: goharbor/redis-photon:v2.6.2
Loaded image: goharbor/nginx-photon:v2.6.2
Loaded image: goharbor/notary-signer-photon:v2.6.2
Loaded image: goharbor/harbor-core:v2.6.2
Loaded image: goharbor/harbor-db:v2.6.2
Loaded image: goharbor/harbor-registryctl:v2.6.2
Loaded image: goharbor/harbor-exporter:v2.6.2
Loaded image: goharbor/prepare:v2.6.2
Loaded image: goharbor/registry-photon:v2.6.2
Loaded image: goharbor/notary-server-photon:v2.6.2
Loaded image: goharbor/harbor-portal:v2.6.2
Loaded image: goharbor/harbor-log:v2.6.2
[Step 3]: preparing environment ...
[Step 4]: preparing harbor configs ...
prepare base dir is set to /usr/local/harbor
Clearing the configuration file: /config/core/app.conf
Clearing the configuration file: /config/core/env
Clearing the configuration file: /config/jobservice/env
Clearing the configuration file: /config/jobservice/config.yml
Clearing the configuration file: /config/nginx/nginx.conf
Clearing the configuration file: /config/registryctl/env
Clearing the configuration file: /config/registryctl/config.yml
Clearing the configuration file: /config/portal/nginx.conf
Clearing the configuration file: /config/db/env
Clearing the configuration file: /config/registry/passwd
Clearing the configuration file: /config/registry/config.yml
Clearing the configuration file: /config/log/logrotate.conf
Clearing the configuration file: /config/log/rsyslog_docker.conf
Generated configuration file: /config/portal/nginx.conf
Generated configuration file: /config/log/logrotate.conf
Generated configuration file: /config/log/rsyslog_docker.conf
Generated configuration file: /config/nginx/nginx.conf
Generated configuration file: /config/core/env
Generated configuration file: /config/core/app.conf
Generated configuration file: /config/registry/config.yml
Generated configuration file: /config/registryctl/env
Generated configuration file: /config/registryctl/config.yml
Generated configuration file: /config/db/env
Generated configuration file: /config/jobservice/env
Generated configuration file: /config/jobservice/config.yml
loaded secret from file: /data/secret/keys/secretkey
Generated configuration file: /compose_location/docker-compose.yml
Clean up the input dir
Note: stopping existing Harbor instance ...
[Step 5]: starting Harbor ...
[+] Running 10/10
⠿ Network harbor_harbor Created 0.0s
⠿ Container harbor-log Started 0.6s
⠿ Container harbor-portal Started 0.8s
⠿ Container registryctl Started 1.1s
⠿ Container redis Started 0.9s
⠿ Container registry Started 1.1s
⠿ Container harbor-db Started 1.2s
⠿ Container harbor-core Started 1.3s
⠿ Container nginx Started 1.9s
⠿ Container harbor-jobservice Started 2.0s
✔ ----Harbor has been installed and started successfully.----
root@cby:/usr/local/harbor#
root@cby:/usr/local/harbor#
root@cby:/usr/local/harbor#
配置解析和docker
# FQDN解析
cat > /etc/hosts <<EOF
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6
192.168.8.61 k8s-master01
192.168.8.62 k8s-master02
192.168.8.63 k8s-master03
192.168.8.64 k8s-node01
192.168.8.65 k8s-node02
192.168.8.66 lb-vip
192.168.8.3 hb.oiox.cn
EOF
# 例如docker的配置
[root@k8s-master-1 ~]# cat > /etc/docker/daemon.json <<EOF
{
"registry-mirrors": [
"https://hub-mirror.c.163.com",
"https://mirror.baidubce.com"
],
"exec-opts": ["native.cgroupdriver=systemd"],
"insecure-registries": ["hb.oiox.cn"]
}
EOF
# 重新启动docker
[root@k8s-master-1 ~]# systemctl restart docker && systemctl status docker -l
测试使用
# 登陆
[root@k8s-master-1 ~]# docker login hb.oiox.cn
Username: admin
Password:
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store
Login Succeeded
[root@k8s-master-1 ~]#
# 测试使用
[root@k8s-master-1 ~]# docker pull registry.cn-hangzhou.aliyuncs.com/google_containers/dashboard:v2.7.0
[root@k8s-master-1 ~]# docker tag registry.cn-hangzhou.aliyuncs.com/google_containers/dashboard:v2.7.0
[root@k8s-master-1 ~]# docker push hb.oiox.cn/library/dashboard:v2.7.0
[root@k8s-master-1 ~]# docker pull hb.oiox.cn/library/dashboard:v2.7.0
关于
https://www.oiox.cn/index.php/start-page.html
CSDN、GitHub、51CTO、知乎、开源中国、思否、掘金、简书、华为云、阿里云、腾讯云、哔哩哔哩、今日头条、新浪微博、个人博客
全网可搜《小陈运维》
文章主要发布于微信公众号
