【摘要】 相关信息 本篇主要学习Druid 对Sql的语法解析。学习完之后,我们可以对任意sql进行解析,同时也可以基于AST语法树来生成sql语句。 (opens new window) # 一、AST AST是abstract syntax t...

相关信息

本篇主要学习Druid 对Sql的语法解析。学习完之后,我们可以对任意sql进行解析,同时也可以基于AST语法树来生成sql语句。

(opens new window)

# 一、AST

AST是abstract syntax tree的缩写,也就是抽象语法树。和所有的Parser一样,Druid Parser会生成一个抽象语法树。

在Druid中,AST节点类型主要包括SQLObject、SQLExpr、SQLStatement三种抽象类型。


        interface SQLObject {}
        interface SQLExpr extends SQLObject {}
        interface SQLStatement extends SQLObject {}
        interface SQLTableSource extends SQLObject {}
        class SQLSelect extends SQLObject {}
        class SQLSelectQueryBlock extends SQLObject {}


1 2 3 4 5 6 7 8

# 二、语法树解析

# 2.1 核心类介绍

# 2.1.1 SQLStatemment DQL & DML顶级抽象

  • DQL 数据查询语言 select
  • DML 数据操纵语言 insert update delete

最常用的Statement当然是SELECT/UPDATE/DELETE/INSERT,他们分别是

核心类 说明
SQLSelectStatement 查询语句
SQLUpdateStatement 更新语句
SQLDeleteStatement 删除语句
SQLInsertStatement 新增语句

        @Test
        public void statement() {
           // 以下全部 true
           System.out.println(SQLUtils.parseSingleMysqlStatement("select * from users") instanceof SQLSelectStatement);
           System.out.println(SQLUtils.parseSingleMysqlStatement("insert into users(id,name,age) values (1,'孙悟空',500)") instanceof SQLInsertStatement);
           System.out.println(SQLUtils.parseSingleMysqlStatement("update users set name = '唐僧' where id = 1 ") instanceof SQLUpdateStatement);
           System.out.println(SQLUtils.parseSingleMysqlStatement("delete from users where id = 1") instanceof SQLDeleteStatement);
        }


1 2 3 4 5 6 7 8

# 2.1.2 SQLSelect SQL查询

SQLSelectStatement包含一个SQLSelect,SQLSelect包含一个SQLSelectQuery。SQLSelectQuery有主要的两个派生类, 分别是SQLSelectQueryBlock(单表sql查询)和SQLUnionQuery(union查询 (opens new window))。


        /**
         * SQLSelectStatement包含一个SQLSelect,SQLSelect包含一个SQLSelectQuery。SQLSelectQuery有主要的两个派生类,
         * 分别是SQLSelectQueryBlock(单表sql查询)和SQLUnionQuery(联合查询)。
         */
            @Test
           public void SQLSelectQuery() {
               // true
                System.out.println(parseSQLSelectQuery("select * from users") instanceof SQLSelectQueryBlock);
               // true
                System.out.println(parseSQLSelectQuery("select name from users union select name from school") instanceof SQLUnionQuery);
            }
           public SQLSelectQuery parseSQLSelectQuery(String sql) {
                SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement(sql);
                SQLSelectStatement sqlSelectStatement = Utils.cast(sqlStatement, SQLSelectStatement.class);
                SQLSelect select = sqlSelectStatement.getSelect();
               return select.getQuery();
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

# 2.1.3 SQLExpr

SQLExpr 是有几个实现类的。


        select id,name,age from users where id = 1 and name = '孙悟空';
        select u.id, u.name from users as u where id = 1 and name = ?;


1 2 3
核心类 举例 说明 适用范围 快速记忆
SQLIdentifierExpr id,name,age SQLIdentifierExpr 查询字段或者where条件 唯一标记
SQLPropertyExpr u.id,u.name 区别于SQLIdentifierExpr,适用于有别名的场景; SQLPropertyExpr.name = id, SQLPropertyExpr.owner = SQLIdentifierExpr = u) 查询字段或者where条件 有别名就是它
SQLBinaryOpExpr id = 1, id > 5 SQLBinaryOpExpr(left = SQLIdentifierExpr = id ,right = SQLValuableExpr = 1) where条件 有操作符就是它
SQLVariantRefExpr id = ? 变量 where条件 有变量符就是它
SQLIntegerExpr id = 1 数字类型 值类型 -
SQLCharExpr name = '孙悟空' 字符类型 值类型 -

# 2.1.3.1 SQLBinaryOpExpr


        /**
         * 操作符相关: SQLBinaryOpExpr
         */
            @Test
           public void SQLBinaryOpExpr() {
                String sql = "select * from users where id > 1 and age = 18";
                SQLSelectQuery sqlSelectQuery = Utils.parseSQLSelectQuery(sql);
                SQLSelectQueryBlock selectQueryBlock = Utils.cast(sqlSelectQuery, SQLSelectQueryBlock.class);
                SQLExpr where = selectQueryBlock.getWhere();
                List<SQLObject> conditions = where.getChildren();
               // [id > 1 , age = 18] 出现了操作符所以是SQLBinaryOpExpr
               for (SQLObject condition : conditions) {
                    SQLBinaryOpExpr conditionExpr = Utils.cast(condition, SQLBinaryOpExpr.class);
                    SQLBinaryOperator operator = conditionExpr.getOperator();
                    SQLIdentifierExpr conditionColumn = Utils.cast(conditionExpr.getLeft(), SQLIdentifierExpr.class);
                    SQLValuableExpr conditionColumnValue = Utils.cast(conditionExpr.getRight(), SQLValuableExpr.class);
                    Utils.print("条件字段:{},操作符号:{},条件值:{}", conditionColumn.getName(), operator.name, conditionColumnValue);
                }
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19

# 2.1.3.2 SQLVariantRefExpr


        @Test
           public void SQLVariantRefExpr() {
                String sql = "select * from users where id = ? and name = ?";
                SQLSelectQuery sqlSelectQuery = Utils.parseSQLSelectQuery(sql);
                SQLSelectQueryBlock selectQueryBlock = Utils.cast(sqlSelectQuery, SQLSelectQueryBlock.class);
                SQLExpr where = selectQueryBlock.getWhere();
                List<SQLObject> conditions = where.getChildren();
               // [id = ?] 出现了变量符,所以要用SQLVariantRefExpr
               for (SQLObject condition : conditions) {
                    SQLBinaryOpExpr conditionExpr = Utils.cast(condition, SQLBinaryOpExpr.class);
                    SQLBinaryOperator operator = conditionExpr.getOperator();
                    SQLIdentifierExpr conditionColumn = Utils.cast(conditionExpr.getLeft(), SQLIdentifierExpr.class);
                    SQLVariantRefExpr conditionColumnValue = Utils.cast(conditionExpr.getRight(), SQLVariantRefExpr.class);
                   int index = conditionColumnValue.getIndex();
                    Utils.print("条件字段:{},操作符号:{},索引位:{}", conditionColumn.getName(), operator.name, index);
                }
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

# 2.1.4 SQLTableSource

常见的SQLTableSource包括SQLExprTableSource、SQLJoinTableSource、SQLSubqueryTableSource、SQLWithSubqueryClause.Entry

核心类 举例 说明 快速记忆
SQLExprTableSource select * from emp where i = 3 name = SQLIdentifierExpr = emp 单表查询
SQLJoinTableSource select * from emp e inner join org o on e.org_id = o.id left = SQLExprTableSource(emp e),right = SQLExprTableSource(org o), condition = SQLBinaryOpExpr(e.org_id = o.id) join 查询使用
SQLSubqueryTableSource select * from (select * from temp) a from(...)是一个SQLSubqueryTableSource 子查询语句
SQLWithSubqueryClause WITH RECURSIVE ancestors AS (SELECT * FROM org UNION SELECT f.* FROM org f, ancestors a WHERE f.id = a.parent_id ) SELECT * FROM ancestors; ancestors AS (...) 是一个SQLWithSubqueryClause.Entry with

# 2.2 SQL语句解析示例

# 2.2.1 解析 Where

注意如果条件语句中只有一个条件,那么where就是一个 SQLBinaryOpExpr。 当条件大于2个,使用 where.getChildren()


        /**
         * 判断where要
         * 1. 注意是SQLBinaryOpExpr(id = 1) or (u.id = 1) 需要注意是否使用了别名<br>
         * 2. 注意如果只有一个查询添加 where本身就是一个SQLBinaryOpExpr,如果是多个就要用 where.getChildren()<br></>
         * 如果有别名: SQLPropertyExpr(name = id , ownerName = u)<br>
         * 如果没别名: SQLIdentifierExpr(name = id) <br></>
         * 值对象: SQLValuableExpr
         *
         * @param where 条件对象
         */
           public static void parseWhere(SQLExpr where) {
               if (where instanceof SQLBinaryOpExpr) {
                   parseSQLBinaryOpExpr(cast(where, SQLBinaryOpExpr.class));
                } else {
                    List<SQLObject> childrenList = where.getChildren();
                   for (SQLObject sqlObject : childrenList) {
                       // 包含了 left 和 right
                        SQLBinaryOpExpr conditionBinary = cast(sqlObject, SQLBinaryOpExpr.class);
                       parseSQLBinaryOpExpr(conditionBinary);
                    }
                }
            }
            public static void parseSQLBinaryOpExpr(SQLBinaryOpExpr conditionBinary) {
                SQLExpr conditionExpr = conditionBinary.getLeft();
                SQLExpr conditionValueExpr = conditionBinary.getRight();
               // 左边有别名所以是SQLPropertyExpr
               if (conditionExpr instanceof SQLPropertyExpr) {
                    SQLPropertyExpr conditionColumnExpr = cast(conditionExpr, SQLPropertyExpr.class);
                   // 右边根据类型进行转换 id是SQLIntegerExpr name是SQLCharExpr
                    SQLValuableExpr conditionColumnValue = cast(conditionValueExpr, SQLValuableExpr.class);
                   print("条件列名:{},条件别名:{},条件值:{}", conditionColumnExpr.getName(), conditionColumnExpr.getOwnernName(), conditionColumnValue);
                }
               // 如果没有别名
               if (conditionExpr instanceof SQLIdentifierExpr) {
                    SQLIdentifierExpr conditionColumnExpr = cast(conditionExpr, SQLIdentifierExpr.class);
                    SQLValuableExpr conditionColumnValue = cast(conditionValueExpr, SQLValuableExpr.class);
                   print("条件列名:{},条件值:{}", conditionColumnExpr.getName(), conditionColumnValue);
                }
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41

# 2.2.2 解析 SQLSelectItem

解析查询的列信息


        /**
             * 解析查询字段,注意是否使用了别名.u.id as userId, u.name as userName, u.age as userAge<br>
             * userId(sqlSelectItem.getAlias)<br>
             * 如果有别名: u.id( id = SQLPropertyExpr.getName,u = SQLPropertyExpr.getOwnernName)<br>
             * 如果没别名: id(id = SQLIdentifierExpr.name)
             *
             * @param selectColumnList 查询字段
             */
            private void parseSQLSelectItem(List<SQLSelectItem> selectColumnList) {
               for (SQLSelectItem sqlSelectItem : selectColumnList) {
                    // u.id as userId(selectColumnAlias)
                    String selectColumnAlias = sqlSelectItem.getAlias();
                    // u.id = SQLPropertyExpr
                    SQLExpr expr = sqlSelectItem.getExpr();
                   if (expr instanceof SQLPropertyExpr) {
                        SQLPropertyExpr selectColumnExpr = cast(expr, SQLPropertyExpr.class);
                       print("列名:{},别名:{},表别名:{}", selectColumnExpr.getName(), selectColumnAlias, selectColumnExpr.getOwnernName());
                    }
                   if (expr instanceof SQLIdentifierExpr) {
                        SQLIdentifierExpr selectColumnExpr = cast(expr, SQLIdentifierExpr.class);
                       print("列名:{},别名:{}", selectColumnExpr.getName(), selectColumnAlias);
                    }
                }
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

# 2.2.3 解析 SQLUpdateSetItem


        @Test
           public void SQLUpdateStatement() {
               SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement("update users u set u.name = '唐僧',age = 18 where u.id = 1 ");
               SQLUpdateStatement sqlUpdateStatement = Utils.cast(sqlStatement, SQLUpdateStatement.class);
                List<SQLUpdateSetItem> setItems = sqlUpdateStatement.getItems();
               for (SQLUpdateSetItem setItem : setItems) {
                   SQLExpr column = setItem.getColumn();
                   if (column instanceof SQLPropertyExpr) {
                       SQLPropertyExpr sqlPropertyExpr = Utils.cast(column, SQLPropertyExpr.class);
                       SQLExpr value = setItem.getValue();
                        Utils.print("column:{},列owner:{},value:{}", sqlPropertyExpr.getName(), sqlPropertyExpr.getOwnernName(), value);
                    }
                   if (column instanceof SQLIdentifierExpr) {
                       SQLExpr value = setItem.getValue();
                        Utils.print("column:{},value:{}", column, value);
                    }
                }
               SQLExpr where = sqlUpdateStatement.getWhere();
                Utils.startParse("解析where", Utils::parseWhere, where);
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

# 2.2.4 解析 SQLLimit


        /**
         * 偏移量,只有2个值
         *
         * @param limit 限制
         */
           private void parseLimit(SQLLimit limit) {
               // 偏移量
               SQLExpr offset = limit.getOffset();
               // 便宜数量
               SQLExpr rowCount = limit.getRowCount();
                print("偏移量:{},偏移数量:{}", offset, rowCount);
            }


1 2 3 4 5 6 7 8 9 10 11 12

# 2.2.5 解析 SQLSelectGroupBy


        @Test
           public void groupBy() {
               SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement("select name,count(1) as count from users group by name,age having count > 2");
               SQLSelectStatement selectStatement = Utils.cast(sqlStatement, SQLSelectStatement.class);
               SQLSelect select = selectStatement.getSelect();
               SQLSelectQueryBlock query = Utils.cast(select.getQuery(), SQLSelectQueryBlock.class);
               SQLSelectGroupByClause groupBy = query.getGroupBy();
                List<SQLExpr> items = groupBy.getItems();
               for (SQLExpr item : items) {
                   // group by name
                   // group by age
                   SQLIdentifierExpr groupByColumn = Utils.cast(item, SQLIdentifierExpr.class);
                    Utils.print("group by {}", groupByColumn);
                }
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

# 2.2.6 解析 Having


        @Test
           public void having() {
               SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement("select name,count(1) as count from users group by name,age having count > 2");
               SQLSelectStatement selectStatement = Utils.cast(sqlStatement, SQLSelectStatement.class);
               SQLSelect select = selectStatement.getSelect();
               SQLSelectQueryBlock query = Utils.cast(select.getQuery(), SQLSelectQueryBlock.class);
               SQLSelectGroupByClause groupBy = query.getGroupBy();
               SQLExpr having = groupBy.getHaving();
               // 因为只有一个条件,所以having就是SQLBinaryOpExpr
               SQLBinaryOpExpr havingExpr = Utils.cast(having, SQLBinaryOpExpr.class);
               // 没有使用别名,所以就是SQLIdentifierExpr
               SQLExpr left = havingExpr.getLeft();
               SQLIdentifierExpr leftExpr = Utils.cast(left, SQLIdentifierExpr.class);
               // 数字类型就是
               SQLExpr right = havingExpr.getRight();
               SQLValuableExpr rightValue = Utils.cast(right, SQLValuableExpr.class);
               SQLBinaryOperator operator = havingExpr.getOperator();
               // left:count, operator:>,right:2
                Utils.print("left:{}, operator:{},right:{}", leftExpr.getName(), operator.name, rightValue.getValue());
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

# 三、语法树生成

前面的内容如果都搞清楚了,那么我们就能对sql进行解析,通知可以修改sql解析后的语法树,同时再将修改后的语法树,重新转换成sql

# 3.1 修改语法树

# 3.1.1 增加一个条件


        @Test
           public void SQLDeleteStatement(){
                SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement("delete from users where id = 1");
                SQLDeleteStatement sqlDeleteStatement = Utils.cast(sqlStatement, SQLDeleteStatement.class);
                sqlDeleteStatement.addCondition(SQLUtils.toSQLExpr("name = '孙悟空'"));
        // DELETE FROM users
        // WHERE id = 1
        // AND name = '孙悟空'
                System.out.println(SQLUtils.toSQLString(sqlDeleteStatement));
            }


1 2 3 4 5 6 7 8 9 10

# 3.1.2 修改一个条件值

将条件id = 1 修改成 id = 2


        @Test
           public void SQLDeleteStatement2(){
                SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement("delete from users where id = 1");
                SQLDeleteStatement sqlDeleteStatement = Utils.cast(sqlStatement, SQLDeleteStatement.class);
                SQLExpr where = sqlDeleteStatement.getWhere();
                SQLBinaryOpExpr sqlBinaryOpExpr = Utils.cast(where, SQLBinaryOpExpr.class);
        // DELETE FROM users
        // WHERE id = 2
                sqlBinaryOpExpr.setRight(SQLUtils.toSQLExpr("2"));
                System.out.println(SQLUtils.toSQLString(sqlDeleteStatement));
            }


1 2 3 4 5 6 7 8 9 10 11

# 四、Visitor模式

访问者模式

所有的AST节点都支持Visitor模式,需要自定义遍历逻辑,可以实现相应的ASTVisitorAdapter派生类


        public static class CustomerMySqlASTVisitorAdapter extends MySqlASTVisitorAdapter {
               private final Map<String, SQLTableSource> ALIAS_MAP = new HashMap<String, SQLTableSource>();
               private final Map<String, SQLExpr> ALIAS_COLUMN_MAP = new HashMap<String, SQLExpr>();
               public boolean visit(SQLExprTableSource x) {
                   String alias = x.getAlias();
                   ALIAS_MAP.put(alias, x);
                   return true;
                }
               @Override
               public boolean visit(MySqlSelectQueryBlock x) {
                   List<SQLSelectItem> selectList = x.getSelectList();
                   for (SQLSelectItem sqlSelectItem : selectList) {
                       String alias = sqlSelectItem.getAlias();
                       SQLExpr expr = sqlSelectItem.getExpr();
                       ALIAS_COLUMN_MAP.put(alias, expr);
                    }
                   return true;
                }
               public Map<String, SQLTableSource> getAliasMap() {
                   return ALIAS_MAP;
                }
               public Map<String, SQLExpr> getAliasColumnMap() {
                   return ALIAS_COLUMN_MAP;
                }
            }
           @Test
           public void AliasVisitor() {
               String sql = "select u.id as userId, u.name as userName, age as userAge from users as u where u.id = 1 and u.name = '孙悟空' limit 2,10";
               // 解析SQL
               SQLStatement sqlStatement = SQLUtils.parseSingleMysqlStatement(sql);
               CustomerMySqlASTVisitorAdapter customerMySqlASTVisitorAdapter = new CustomerMySqlASTVisitorAdapter();
                sqlStatement.accept(customerMySqlASTVisitorAdapter);
               // 表别名:{u=users}
               System.out.println("表别名:" + customerMySqlASTVisitorAdapter.getAliasMap());
               // 列别名{userName=u.name, userId=u.id, userAge=age}
               System.out.println("列别名" + customerMySqlASTVisitorAdapter.getAliasColumnMap());
            }


1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

文章来源: springlearn.blog.csdn.net,作者:西魏陶渊明,版权归原作者所有,如需转载,请联系作者。

原文链接:springlearn.blog.csdn.net/article/details/125858132

【版权声明】本文为华为云社区用户转载文章,如果您发现本社区中有涉嫌抄袭的内容,欢迎发送邮件进行举报,并提供相关证据,一经查实,本社区将立刻删除涉嫌侵权内容,举报邮箱: cloudbbs@huaweicloud.com
  • 点赞
  • 收藏
  • 关注作者

评论(0

0/1000
抱歉,系统识别当前为高风险访问,暂不支持该操作

全部回复

上滑加载中

设置昵称

在此一键设置昵称,即可参与社区互动!

*长度不超过10个汉字或20个英文字符,设置后3个月内不可修改。

*长度不超过10个汉字或20个英文字符,设置后3个月内不可修改。
