# 二进制安装Kubernetes（k8s） v1.24.1 IPv4/IPv6双栈 --- Ubuntu版本

[Kubernetes](https://github.com/cby-chen/Kubernetes) 开源不易，帮忙点个star，谢谢了🌹

# 介绍

kubernetes二进制安装

后续尽可能第一时间更新新版本文档，更新后内容在GitHub。

本文是使用的是Ubuntu作为基底，其他文档请在GitHub上查看。

1.23.3 和 1.23.4 和 1.23.5 和 1.23.6 和 1.24.0 和1.24.1 文档以及安装包已生成。

我使用IPV6的目的是在公网进行访问，所以我配置了IPV6静态地址。

若您没有IPV6环境，或者不想使用IPv6，不对主机进行配置IPv6地址即可。

不配置IPV6，不影响后续，不过集群依旧是支持IPv6的。为后期留有扩展可能性。

https://github.com/cby-chen/Kubernetes/

手动项目地址：https://github.com/cby-chen/Kubernetes

脚本项目地址：https://github.com/cby-chen/Binary_installation_of_Kubernetes

kubernetes 1.24 变化较大，详细见：https://kubernetes.io/zh/blog/2022/04/07/upcoming-changes-in-kubernetes-1-24/


# 1.环境

| 主机名称 | IP地址       | 说明       | 软件                                                         |
| -------- | ------------ | ---------- | ------------------------------------------------------------ |
| Master01 | 192.168.1.11 | master节点 | kube-apiserver、kube-controller-manager、kube-scheduler、etcd、<br />kubelet、kube-proxy、nfs-client、haproxy、keepalived |
| Master02 | 192.168.1.12 | master节点 | kube-apiserver、kube-controller-manager、kube-scheduler、etcd、<br />kubelet、kube-proxy、nfs-client、haproxy、keepalived |
| Master03 | 192.168.1.13 | master节点 | kube-apiserver、kube-controller-manager、kube-scheduler、etcd、<br />kubelet、kube-proxy、nfs-client、haproxy、keepalived |
| Node01   | 192.168.1.14 | node节点   | kubelet、kube-proxy、nfs-client                              |
| Node02   | 192.168.1.15 | node节点   | kubelet、kube-proxy、nfs-client                              |
|          | 192.168.1.19 | VIP        |                                                              |

| 软件                                                         | 版本        |
| :----------------------------------------------------------- | :---------- |
| kernel                                                       | 5.4.0-86    |
| Ubuntu                                                       | 2004 及以上 |
| kube-apiserver、kube-controller-manager、kube-scheduler、kubelet、kube-proxy | v1.24.1     |
| etcd                                                         | v3.5.4      |
| containerd                                                   | v1.5.11     |
| cfssl                                                        | v1.6.1      |
| cni                                                          | v1.1.1      |
| crictl                                                       | v1.24.2     |
| haproxy                                                      | v1.8.27     |
| keepalived                                                   | v2.1.5      |



网段

物理主机：10.0.0.0/24

service：10.96.0.0/12

pod：172.16.0.0/12

建议k8s集群与etcd集群分开安装



安装包已经整理好：https://github.com/cby-chen/Kubernetes/releases/download/v1.24.1/kubernetes-v1.24.1.tar



## 1.1.k8s基础系统环境配置

### 1.2.配置IP

```shell
root@hello:~# vim /etc/netplan/00-installer-config.yaml
root@hello:~#
root@hello:~# cat /etc/netplan/00-installer-config.yaml
# This is the network config written by 'subiquity'
network:
  ethernets:
    ens18:
       addresses:
         - 192.168.1.11/24
       gateway4: 192.168.1.1
       nameservers:
           addresses: [8.8.8.8]
  version: 2
root@hello:~#
root@hello:~# netplan apply
root@hello:~#

```

### 1.3.设置主机名

```shell
hostnamectl set-hostname k8s-master01
hostnamectl set-hostname k8s-master02
hostnamectl set-hostname k8s-master03
hostnamectl set-hostname k8s-node01
hostnamectl set-hostname k8s-node02
```

### 1.4.配置apt源

```shell
sudo sed -i 's/archive.ubuntu.com/mirrors.ustc.edu.cn/g' /etc/apt/sources.list
```

### 1.5.安装一些必备工具

```shell
apt install  wget jq psmisc vim net-tools nfs-kernel-server  telnet lvm2 git tar curl -y
```

### 1.6.选择性下载需要工具

```shell
1.下载kubernetes1.24.+的二进制包
github二进制包下载地址：https://github.com/kubernetes/kubernetes/blob/master/CHANGELOG/CHANGELOG-1.24.md

wget https://dl.k8s.io/v1.24.1/kubernetes-server-linux-amd64.tar.gz

2.下载etcdctl二进制包
github二进制包下载地址：https://github.com/etcd-io/etcd/releases

wget https://github.com/etcd-io/etcd/releases/download/v3.5.4/etcd-v3.5.4-linux-amd64.tar.gz

3.docker-ce二进制包下载地址
二进制包下载地址：https://download.docker.com/linux/static/stable/x86_64/

这里需要下载20.10.+版本

wget https://download.docker.com/linux/static/stable/x86_64/docker-20.10.14.tgz

4.containerd二进制包下载
github下载地址：https://github.com/containerd/containerd/releases

containerd下载时下载带cni插件的二进制包。

wget https://github.com/containerd/containerd/releases/download/v1.6.4/cri-containerd-cni-1.6.4-linux-amd64.tar.gz

5.下载cfssl二进制包
github二进制包下载地址：https://github.com/cloudflare/cfssl/releases

wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl_1.6.1_linux_amd64
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssljson_1.6.1_linux_amd64
wget https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl-certinfo_1.6.1_linux_amd64

6.cni插件下载
github下载地址：https://github.com/containernetworking/plugins/releases

wget https://github.com/containernetworking/plugins/releases/download/v1.1.1/cni-plugins-linux-amd64-v1.1.1.tgz

7.crictl客户端二进制下载
github下载：https://github.com/kubernetes-sigs/cri-tools/releases

wget https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.24.2/crictl-v1.24.2-linux-amd64.tar.gz
```

### 1.7.关闭防火墙

```shell
systemctl disable --now ufw
```

### 1.8.关闭交换分区

```shell
sed -ri 's/.*swap.*/#&/' /etc/fstab
swapoff -a && sysctl -w vm.swappiness=0

cat /etc/fstab
# /dev/mapper/centos-swap swap                    swap    defaults        0 0
```

### 1.9.进行时间同步 (lb除外)

```shell
# 服务端

apt install chrony -y
cat > /etc/chrony/chrony.conf << EOF
pool ntp.aliyun.com iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
allow 192.168.1.0/24
local stratum 10
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony
EOF

systemctl restart chronyd
systemctl enable chronyd

# 客户端

apt install chrony -y
vim /etc/chrony/chrony.conf
cat /etc/chrony/chrony.conf | grep -v  "^#" | grep -v "^$"
pool 192.168.1.11 iburst
driftfile /var/lib/chrony/drift
makestep 1.0 3
rtcsync
keyfile /etc/chrony.keys
leapsectz right/UTC
logdir /var/log/chrony

systemctl restart chronyd ; systemctl enable chronyd

# 客户端安装一条命令
yum install chrony -y ; sed -i "s#2.centos.pool.ntp.org#192.168.1.11#g" /etc/chrony/chrony.conf ; systemctl restart chronyd ; systemctl enable chronyd


#使用客户端进行验证
chronyc sources -v
```

### 1.10.配置ulimit

```shell
ulimit -SHn 65535
cat >> /etc/security/limits.conf <<EOF
* soft nofile 655360
* hard nofile 131072
* soft nproc 655350
* hard nproc 655350
* seft memlock unlimited
* hard memlock unlimitedd
EOF
```

### 1.11.配置免密登录

```shell
apt install -y sshpass
ssh-keygen -f /root/.ssh/id_rsa -P ''
export IP="192.168.1.11 192.168.1.12 192.168.1.13 192.168.1.14 192.168.1.15"
export SSHPASS=123123
for HOST in $IP;do
     sshpass -e ssh-copy-id -o StrictHostKeyChecking=no $HOST
done
```

### 1.12.安装ipvsadm (lb除外)

```shell
apt install ipvsadm ipset sysstat conntrack -y

cat >> /etc/modules-load.d/ipvs.conf <<EOF
ip_vs
ip_vs_rr
ip_vs_wrr
ip_vs_sh
nf_conntrack
ip_tables
ip_set
xt_set
ipt_set
ipt_rpfilter
ipt_REJECT
ipip
EOF

systemctl restart systemd-modules-load.service

lsmod | grep -e ip_vs -e nf_conntrack
ip_vs_sh               16384  0
ip_vs_wrr              16384  0
ip_vs_rr               16384  0
ip_vs                 155648  6 ip_vs_rr,ip_vs_sh,ip_vs_wrr
nf_conntrack          139264  1 ip_vs
nf_defrag_ipv6         24576  2 nf_conntrack,ip_vs
nf_defrag_ipv4         16384  1 nf_conntrack
libcrc32c              16384  4 nf_conntrack,btrfs,raid456,ip_vs
```

### 1.13.修改内核参数 (lb除外)

```shell
cat <<EOF > /etc/sysctl.d/k8s.conf
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-iptables = 1
fs.may_detach_mounts = 1
vm.overcommit_memory=1
vm.panic_on_oom=0
fs.inotify.max_user_watches=89100
fs.file-max=52706963
fs.nr_open=52706963
net.netfilter.nf_conntrack_max=2310720


net.ipv4.tcp_keepalive_time = 600
net.ipv4.tcp_keepalive_probes = 3
net.ipv4.tcp_keepalive_intvl =15
net.ipv4.tcp_max_tw_buckets = 36000
net.ipv4.tcp_tw_reuse = 1
net.ipv4.tcp_max_orphans = 327680
net.ipv4.tcp_orphan_retries = 3
net.ipv4.tcp_syncookies = 1
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.ip_conntrack_max = 65536
net.ipv4.tcp_max_syn_backlog = 16384
net.ipv4.tcp_timestamps = 0
net.core.somaxconn = 16384

net.ipv6.conf.all.disable_ipv6 = 0
net.ipv6.conf.default.disable_ipv6 = 0
net.ipv6.conf.lo.disable_ipv6 = 0
net.ipv6.conf.all.forwarding = 0

EOF

sysctl --system
```

### 1.14.所有节点配置hosts本地解析

```shell
cat > /etc/hosts <<EOF
127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
::1         localhost localhost.localdomain localhost6 localhost6.localdomain6

192.168.1.11 k8s-master01
192.168.1.12 k8s-master02
192.168.1.13 k8s-master03
192.168.1.14 k8s-node01
192.168.1.15 k8s-node02
192.168.1.19 lb-vip
EOF
```

# 2.k8s基本组件安装

## 2.1.所有k8s节点安装Containerd作为Runtime

```shell
wget https://github.com/containernetworking/plugins/releases/download/v1.1.1/cni-plugins-linux-amd64-v1.1.1.tgz

#创建cni插件所需目录
mkdir -p /etc/cni/net.d /opt/cni/bin
#解压cni二进制包
tar xf cni-plugins-linux-amd64-v1.1.1.tgz -C /opt/cni/bin/


wget https://github.com/containerd/containerd/releases/download/v1.6.4/cri-containerd-cni-1.6.4-linux-amd64.tar.gz

#解压
tar -C / -xzf cri-containerd-cni-1.6.4-linux-amd64.tar.gz

#创建服务启动文件
cat > /etc/systemd/system/containerd.service <<EOF
[Unit]
Description=containerd container runtime
Documentation=https://containerd.io
After=network.target local-fs.target

[Service]
ExecStartPre=-/sbin/modprobe overlay
ExecStart=/usr/local/bin/containerd
Type=notify
Delegate=yes
KillMode=process
Restart=always
RestartSec=5
LimitNPROC=infinity
LimitCORE=infinity
LimitNOFILE=infinity
TasksMax=infinity
OOMScoreAdjust=-999

[Install]
WantedBy=multi-user.target
EOF
```

### 2.1.1配置Containerd所需的模块

```shell
cat <<EOF | sudo tee /etc/modules-load.d/containerd.conf
overlay
br_netfilter
EOF
```

### 2.1.2加载模块

```shell
systemctl restart systemd-modules-load.service
```

### 2.1.3配置Containerd所需的内核

```shell
cat <<EOF | sudo tee /etc/sysctl.d/99-kubernetes-cri.conf
net.bridge.bridge-nf-call-iptables  = 1
net.ipv4.ip_forward                 = 1
net.bridge.bridge-nf-call-ip6tables = 1
EOF

# 加载内核

sysctl --system
```

### 2.1.4创建Containerd的配置文件

```shell
mkdir -p /etc/containerd
containerd config default | tee /etc/containerd/config.toml


修改Containerd的配置文件
sed -i "s#SystemdCgroup\ \=\ false#SystemdCgroup\ \=\ true#g" /etc/containerd/config.toml

cat /etc/containerd/config.toml | grep SystemdCgroup

sed -i "s#k8s.gcr.io#registry.cn-hangzhou.aliyuncs.com/chenby#g" /etc/containerd/config.toml

cat /etc/containerd/config.toml | grep sandbox_image

# 找到containerd.runtimes.runc.options，在其下加入SystemdCgroup = true

[plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
              SystemdCgroup = true
    [plugins."io.containerd.grpc.v1.cri".cni]


# 将sandbox_image默认地址改为符合版本地址

    sandbox_image = "registry.cn-hangzhou.aliyuncs.com/chenby/pause:3.6"
```

### 2.1.5启动并设置为开机启动

```shell
systemctl daemon-reload
systemctl enable --now containerd
```

### 2.1.6配置crictl客户端连接的运行时位置

```shell
wget https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.24.2/crictl-v1.24.2-linux-amd64.tar.gz

#解压
tar xf crictl-v1.24.2-linux-amd64.tar.gz -C /usr/bin/
#生成配置文件

cat > /etc/crictl.yaml <<EOF
runtime-endpoint: unix:///run/containerd/containerd.sock
image-endpoint: unix:///run/containerd/containerd.sock
timeout: 10
debug: false
EOF

#测试
systemctl restart  containerd
crictl info

```



## 2.2.k8s与etcd下载及安装（仅在master01操作）

### 2.2.1解压k8s安装包

```shell
# 下载安装包
wget https://dl.k8s.io/v1.24.1/kubernetes-server-linux-amd64.tar.gz
wget https://github.com/etcd-io/etcd/releases/download/v3.5.4/etcd-v3.5.4-linux-amd64.tar.gz

# 解压k8s安装文件
cd cby
tar -xf kubernetes-server-linux-amd64.tar.gz  --strip-components=3 -C /usr/local/bin kubernetes/server/bin/kube{let,ctl,-apiserver,-controller-manager,-scheduler,-proxy}

# 解压etcd安装文件
tar -xf etcd-v3.5.4-linux-amd64.tar.gz --strip-components=1 -C /usr/local/bin etcd-v3.5.4-linux-amd64/etcd{,ctl}

# 查看/usr/local/bin下内容

ls /usr/local/bin/
etcd  etcdctl  kube-apiserver  kube-controller-manager  kubectl  kubelet  kube-proxy  kube-scheduler

```

### 2.2.2查看版本

```shell
[root@k8s-master01 ~]# kubelet --version
Kubernetes v1.24.1
[root@k8s-master01 ~]# etcdctl version
etcdctl version: 3.5.4
API version: 3.5
[root@k8s-master01 ~]#
```

### 2.2.3将组件发送至其他k8s节点

```shell
Master='k8s-master02 k8s-master03'
Work='k8s-node01 k8s-node02'

for NODE in $Master; do echo $NODE; scp /usr/local/bin/kube{let,ctl,-apiserver,-controller-manager,-scheduler,-proxy} $NODE:/usr/local/bin/; scp /usr/local/bin/etcd* $NODE:/usr/local/bin/; done

for NODE in $Work; do     scp /usr/local/bin/kube{let,-proxy} $NODE:/usr/local/bin/ ; done

mkdir -p /opt/cni/bin
```

## 2.3创建证书相关文件

```shell
mkdir pki
cd pki
cat > admin-csr.json << EOF
{
  "CN": "admin",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:masters",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF

cat > ca-config.json << EOF
{
  "signing": {
    "default": {
      "expiry": "876000h"
    },
    "profiles": {
      "kubernetes": {
        "usages": [
            "signing",
            "key encipherment",
            "server auth",
            "client auth"
        ],
        "expiry": "876000h"
      }
    }
  }
}
EOF

cat > etcd-ca-csr.json  << EOF
{
  "CN": "etcd",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "etcd",
      "OU": "Etcd Security"
    }
  ],
  "ca": {
    "expiry": "876000h"
  }
}
EOF

cat > front-proxy-ca-csr.json  << EOF
{
  "CN": "kubernetes",
  "key": {
     "algo": "rsa",
     "size": 2048
  },
  "ca": {
    "expiry": "876000h"
  }
}
EOF

cat > kubelet-csr.json  << EOF
{
  "CN": "system:node:\$NODE",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "L": "Beijing",
      "ST": "Beijing",
      "O": "system:nodes",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF

cat > manager-csr.json << EOF
{
  "CN": "system:kube-controller-manager",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:kube-controller-manager",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF

cat > apiserver-csr.json << EOF
{
  "CN": "kube-apiserver",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "Kubernetes",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF


cat > ca-csr.json   << EOF
{
  "CN": "kubernetes",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "Kubernetes",
      "OU": "Kubernetes-manual"
    }
  ],
  "ca": {
    "expiry": "876000h"
  }
}
EOF

cat > etcd-csr.json << EOF
{
  "CN": "etcd",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "etcd",
      "OU": "Etcd Security"
    }
  ]
}
EOF


cat > front-proxy-client-csr.json  << EOF
{
  "CN": "front-proxy-client",
  "key": {
     "algo": "rsa",
     "size": 2048
  }
}
EOF


cat > kube-proxy-csr.json  << EOF
{
  "CN": "system:kube-proxy",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:kube-proxy",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF


cat > scheduler-csr.json << EOF
{
  "CN": "system:kube-scheduler",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "Beijing",
      "L": "Beijing",
      "O": "system:kube-scheduler",
      "OU": "Kubernetes-manual"
    }
  ]
}
EOF

cd ..
mkdir bootstrap
cd bootstrap
cat > bootstrap.secret.yaml << EOF
apiVersion: v1
kind: Secret
metadata:
  name: bootstrap-token-c8ad9c
  namespace: kube-system
type: bootstrap.kubernetes.io/token
stringData:
  description: "The default bootstrap token generated by 'kubelet '."
  token-id: c8ad9c
  token-secret: 2e4d610cf3e7426e
  usage-bootstrap-authentication: "true"
  usage-bootstrap-signing: "true"
  auth-extra-groups:  system:bootstrappers:default-node-token,system:bootstrappers:worker,system:bootstrappers:ingress

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: kubelet-bootstrap
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:node-bootstrapper
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: Group
  name: system:bootstrappers:default-node-token
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: node-autoapprove-bootstrap
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:certificates.k8s.io:certificatesigningrequests:nodeclient
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: Group
  name: system:bootstrappers:default-node-token
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: node-autoapprove-certificate-rotation
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:certificates.k8s.io:certificatesigningrequests:selfnodeclient
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: Group
  name: system:nodes
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  annotations:
    rbac.authorization.kubernetes.io/autoupdate: "true"
  labels:
    kubernetes.io/bootstrapping: rbac-defaults
  name: system:kube-apiserver-to-kubelet
rules:
  - apiGroups:
      - ""
    resources:
      - nodes/proxy
      - nodes/stats
      - nodes/log
      - nodes/spec
      - nodes/metrics
    verbs:
      - "*"
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: system:kube-apiserver
  namespace: ""
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:kube-apiserver-to-kubelet
subjects:
  - apiGroup: rbac.authorization.k8s.io
    kind: User
    name: kube-apiserver
EOF


cd ..
mkdir coredns
cd coredns
cat > coredns.yaml << EOF
apiVersion: v1
kind: ServiceAccount
metadata:
  name: coredns
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  labels:
    kubernetes.io/bootstrapping: rbac-defaults
  name: system:coredns
rules:
  - apiGroups:
    - ""
    resources:
    - endpoints
    - services
    - pods
    - namespaces
    verbs:
    - list
    - watch
  - apiGroups:
    - discovery.k8s.io
    resources:
    - endpointslices
    verbs:
    - list
    - watch
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  annotations:
    rbac.authorization.kubernetes.io/autoupdate: "true"
  labels:
    kubernetes.io/bootstrapping: rbac-defaults
  name: system:coredns
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:coredns
subjects:
- kind: ServiceAccount
  name: coredns
  namespace: kube-system
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: coredns
  namespace: kube-system
data:
  Corefile: |
    .:53 {
        errors
        health {
          lameduck 5s
        }
        ready
        kubernetes cluster.local in-addr.arpa ip6.arpa {
          fallthrough in-addr.arpa ip6.arpa
        }
        prometheus :9153
        forward . /etc/resolv.conf {
          max_concurrent 1000
        }
        cache 30
        loop
        reload
        loadbalance
    }
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: coredns
  namespace: kube-system
  labels:
    k8s-app: kube-dns
    kubernetes.io/name: "CoreDNS"
spec:
  # replicas: not specified here:
  # 1. Default is 1.
  # 2. Will be tuned in real time if DNS horizontal auto-scaling is turned on.
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 1
  selector:
    matchLabels:
      k8s-app: kube-dns
  template:
    metadata:
      labels:
        k8s-app: kube-dns
    spec:
      priorityClassName: system-cluster-critical
      serviceAccountName: coredns
      tolerations:
        - key: "CriticalAddonsOnly"
          operator: "Exists"
      nodeSelector:
        kubernetes.io/os: linux
      affinity:
         podAntiAffinity:
           preferredDuringSchedulingIgnoredDuringExecution:
           - weight: 100
             podAffinityTerm:
               labelSelector:
                 matchExpressions:
                   - key: k8s-app
                     operator: In
                     values: ["kube-dns"]
               topologyKey: kubernetes.io/hostname
      containers:
      - name: coredns
        image: registry.cn-beijing.aliyuncs.com/dotbalo/coredns:1.8.6
        imagePullPolicy: IfNotPresent
        resources:
          limits:
            memory: 170Mi
          requests:
            cpu: 100m
            memory: 70Mi
        args: [ "-conf", "/etc/coredns/Corefile" ]
        volumeMounts:
        - name: config-volume
          mountPath: /etc/coredns
          readOnly: true
        ports:
        - containerPort: 53
          name: dns
          protocol: UDP
        - containerPort: 53
          name: dns-tcp
          protocol: TCP
        - containerPort: 9153
          name: metrics
          protocol: TCP
        securityContext:
          allowPrivilegeEscalation: false
          capabilities:
            add:
            - NET_BIND_SERVICE
            drop:
            - all
          readOnlyRootFilesystem: true
        livenessProbe:
          httpGet:
            path: /health
            port: 8080
            scheme: HTTP
          initialDelaySeconds: 60
          timeoutSeconds: 5
          successThreshold: 1
          failureThreshold: 5
        readinessProbe:
          httpGet:
            path: /ready
            port: 8181
            scheme: HTTP
      dnsPolicy: Default
      volumes:
        - name: config-volume
          configMap:
            name: coredns
            items:
            - key: Corefile
              path: Corefile
---
apiVersion: v1
kind: Service
metadata:
  name: kube-dns
  namespace: kube-system
  annotations:
    prometheus.io/port: "9153"
    prometheus.io/scrape: "true"
  labels:
    k8s-app: kube-dns
    kubernetes.io/cluster-service: "true"
    kubernetes.io/name: "CoreDNS"
spec:
  selector:
    k8s-app: kube-dns
  clusterIP: 10.96.0.10
  ports:
  - name: dns
    port: 53
    protocol: UDP
  - name: dns-tcp
    port: 53
    protocol: TCP
  - name: metrics
    port: 9153
    protocol: TCP
EOF


cd ..
mkdir metrics-server
cd metrics-server
cat > metrics-server.yaml << EOF
apiVersion: v1
kind: ServiceAccount
metadata:
  labels:
    k8s-app: metrics-server
  name: metrics-server
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  labels:
    k8s-app: metrics-server
    rbac.authorization.k8s.io/aggregate-to-admin: "true"
    rbac.authorization.k8s.io/aggregate-to-edit: "true"
    rbac.authorization.k8s.io/aggregate-to-view: "true"
  name: system:aggregated-metrics-reader
rules:
- apiGroups:
  - metrics.k8s.io
  resources:
  - pods
  - nodes
  verbs:
  - get
  - list
  - watch
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  labels:
    k8s-app: metrics-server
  name: system:metrics-server
rules:
- apiGroups:
  - ""
  resources:
  - pods
  - nodes
  - nodes/stats
  - namespaces
  - configmaps
  verbs:
  - get
  - list
  - watch
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  labels:
    k8s-app: metrics-server
  name: metrics-server-auth-reader
  namespace: kube-system
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: extension-apiserver-authentication-reader
subjects:
- kind: ServiceAccount
  name: metrics-server
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  labels:
    k8s-app: metrics-server
  name: metrics-server:system:auth-delegator
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:auth-delegator
subjects:
- kind: ServiceAccount
  name: metrics-server
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  labels:
    k8s-app: metrics-server
  name: system:metrics-server
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:metrics-server
subjects:
- kind: ServiceAccount
  name: metrics-server
  namespace: kube-system
---
apiVersion: v1
kind: Service
metadata:
  labels:
    k8s-app: metrics-server
  name: metrics-server
  namespace: kube-system
spec:
  ports:
  - name: https
    port: 443
    protocol: TCP
    targetPort: https
  selector:
    k8s-app: metrics-server
---
apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    k8s-app: metrics-server
  name: metrics-server
  namespace: kube-system
spec:
  selector:
    matchLabels:
      k8s-app: metrics-server
  strategy:
    rollingUpdate:
      maxUnavailable: 0
  template:
    metadata:
      labels:
        k8s-app: metrics-server
    spec:
      containers:
      - args:
        - --cert-dir=/tmp
        - --secure-port=4443
        - --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname
        - --kubelet-use-node-status-port
        - --metric-resolution=15s
        - --kubelet-insecure-tls
        - --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.pem # change to front-proxy-ca.crt for kubeadm
        - --requestheader-username-headers=X-Remote-User
        - --requestheader-group-headers=X-Remote-Group
        - --requestheader-extra-headers-prefix=X-Remote-Extra-
        image: registry.cn-beijing.aliyuncs.com/dotbalo/metrics-server:0.5.0
        imagePullPolicy: IfNotPresent
        livenessProbe:
          failureThreshold: 3
          httpGet:
            path: /livez
            port: https
            scheme: HTTPS
          periodSeconds: 10
        name: metrics-server
        ports:
        - containerPort: 4443
          name: https
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /readyz
            port: https
            scheme: HTTPS
          initialDelaySeconds: 20
          periodSeconds: 10
        resources:
          requests:
            cpu: 100m
            memory: 200Mi
        securityContext:
          readOnlyRootFilesystem: true
          runAsNonRoot: true
          runAsUser: 1000
        volumeMounts:
        - mountPath: /tmp
          name: tmp-dir
        - name: ca-ssl
          mountPath: /etc/kubernetes/pki
      nodeSelector:
        kubernetes.io/os: linux
      priorityClassName: system-cluster-critical
      serviceAccountName: metrics-server
      volumes:
      - emptyDir: {}
        name: tmp-dir
      - name: ca-ssl
        hostPath:
          path: /etc/kubernetes/pki

---
apiVersion: apiregistration.k8s.io/v1
kind: APIService
metadata:
  labels:
    k8s-app: metrics-server
  name: v1beta1.metrics.k8s.io
spec:
  group: metrics.k8s.io
  groupPriorityMinimum: 100
  insecureSkipTLSVerify: true
  service:
    name: metrics-server
    namespace: kube-system
  version: v1beta1
  versionPriority: 100
EOF
```

# 3.相关证书生成

```shell
master01节点下载证书生成工具
wget "https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssl_1.6.1_linux_amd64" -O /usr/local/bin/cfssl
wget "https://github.com/cloudflare/cfssl/releases/download/v1.6.1/cfssljson_1.6.1_linux_amd64" -O /usr/local/bin/cfssljson
chmod +x /usr/local/bin/cfssl /usr/local/bin/cfssljson
```

## 3.1.生成etcd证书

特别说明除外，以下操作在所有master节点操作

### 3.1.1所有master节点创建证书存放目录

```shell
mkdir /etc/etcd/ssl -p
```

### 3.1.2master01节点生成etcd证书

```shell
cd pki

# 生成etcd证书和etcd证书的key（如果你觉得以后可能会扩容，可以在ip那多写几个预留出来）

cfssl gencert -initca etcd-ca-csr.json | cfssljson -bare /etc/etcd/ssl/etcd-ca

cfssl gencert \
   -ca=/etc/etcd/ssl/etcd-ca.pem \
   -ca-key=/etc/etcd/ssl/etcd-ca-key.pem \
   -config=ca-config.json \
   -hostname=127.0.0.1,k8s-master01,k8s-master02,k8s-master03,192.168.1.11,192.168.1.12,192.168.1.13,2408:8207:78ca:9fa1::10,2408:8207:78ca:9fa1::20,2408:8207:78ca:9fa1::30 \
   -profile=kubernetes \
   etcd-csr.json | cfssljson -bare /etc/etcd/ssl/etcd
```

### 3.1.3将证书复制到其他节点

```shell
Master='k8s-master02 k8s-master03'

for NODE in $Master; do ssh $NODE "mkdir -p /etc/etcd/ssl"; for FILE in etcd-ca-key.pem  etcd-ca.pem  etcd-key.pem  etcd.pem; do scp /etc/etcd/ssl/${FILE} $NODE:/etc/etcd/ssl/${FILE}; done; done
```

## 3.2.生成k8s相关证书

特别说明除外，以下操作在所有master节点操作

### 3.2.1所有k8s节点创建证书存放目录

```shell
mkdir -p /etc/kubernetes/pki
```

### 3.2.2master01节点生成k8s证书

```shell
# 生成一个根证书 ，多写了一些IP作为预留IP，为将来添加node做准备

cfssl gencert -initca ca-csr.json | cfssljson -bare /etc/kubernetes/pki/ca

# 10.96.0.1是service网段的第一个地址，需要计算，192.168.1.19为高可用vip地址

cfssl gencert   \
-ca=/etc/kubernetes/pki/ca.pem   \
-ca-key=/etc/kubernetes/pki/ca-key.pem   \
-config=ca-config.json   \
-hostname=10.96.0.1,192.168.1.19,127.0.0.1,kubernetes,kubernetes.default,kubernetes.default.svc,kubernetes.default.svc.cluster,kubernetes.default.svc.cluster.local,x.oiox.cn,k.oiox.cn,l.oiox.cn,o.oiox.cn,192.168.1.11,192.168.1.12,192.168.1.13,192.168.1.14,192.168.1.15,192.168.1.16,192.168.1.17,192.168.1.18,2408:8207:78ca:9fa1::10,2408:8207:78ca:9fa1::20,2408:8207:78ca:9fa1::30,2408:8207:78ca:9fa1::40,2408:8207:78ca:9fa1::50,2408:8207:78ca:9fa1::60,2408:8207:78ca:9fa1::70,2408:8207:78ca:9fa1::80,2408:8207:78ca:9fa1::90,2408:8207:78ca:9fa1::100   \
-profile=kubernetes   apiserver-csr.json | cfssljson -bare /etc/kubernetes/pki/apiserver
```

### 3.2.3生成apiserver聚合证书

```shell
cfssl gencert   -initca front-proxy-ca-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-ca

# 有一个警告，可以忽略

cfssl gencert  \
-ca=/etc/kubernetes/pki/front-proxy-ca.pem   \
-ca-key=/etc/kubernetes/pki/front-proxy-ca-key.pem   \
-config=ca-config.json   \
-profile=kubernetes   front-proxy-client-csr.json | cfssljson -bare /etc/kubernetes/pki/front-proxy-client
```

### 3.2.4生成controller-manage的证书

```shell
cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   manager-csr.json | cfssljson -bare /etc/kubernetes/pki/controller-manager

# 设置一个集群项

kubectl config set-cluster kubernetes \
     --certificate-authority=/etc/kubernetes/pki/ca.pem \
     --embed-certs=true \
     --server=https://192.168.1.19:8443 \
     --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

# 设置一个环境项，一个上下文

kubectl config set-context system:kube-controller-manager@kubernetes \
    --cluster=kubernetes \
    --user=system:kube-controller-manager \
    --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

# 设置一个用户项

kubectl config set-credentials system:kube-controller-manager \
     --client-certificate=/etc/kubernetes/pki/controller-manager.pem \
     --client-key=/etc/kubernetes/pki/controller-manager-key.pem \
     --embed-certs=true \
     --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

# 设置默认环境

kubectl config use-context system:kube-controller-manager@kubernetes \
     --kubeconfig=/etc/kubernetes/controller-manager.kubeconfig

cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   scheduler-csr.json | cfssljson -bare /etc/kubernetes/pki/scheduler

kubectl config set-cluster kubernetes \
     --certificate-authority=/etc/kubernetes/pki/ca.pem \
     --embed-certs=true \
     --server=https://192.168.1.19:8443 \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

kubectl config set-credentials system:kube-scheduler \
     --client-certificate=/etc/kubernetes/pki/scheduler.pem \
     --client-key=/etc/kubernetes/pki/scheduler-key.pem \
     --embed-certs=true \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

kubectl config set-context system:kube-scheduler@kubernetes \
     --cluster=kubernetes \
     --user=system:kube-scheduler \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

kubectl config use-context system:kube-scheduler@kubernetes \
     --kubeconfig=/etc/kubernetes/scheduler.kubeconfig

cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   admin-csr.json | cfssljson -bare /etc/kubernetes/pki/admin

kubectl config set-cluster kubernetes     \
  --certificate-authority=/etc/kubernetes/pki/ca.pem     \
  --embed-certs=true     \
  --server=https://192.168.1.19:8443     \
  --kubeconfig=/etc/kubernetes/admin.kubeconfig

kubectl config set-credentials kubernetes-admin  \
  --client-certificate=/etc/kubernetes/pki/admin.pem     \
  --client-key=/etc/kubernetes/pki/admin-key.pem     \
  --embed-certs=true     \
  --kubeconfig=/etc/kubernetes/admin.kubeconfig

kubectl config set-context kubernetes-admin@kubernetes    \
  --cluster=kubernetes     \
  --user=kubernetes-admin     \
  --kubeconfig=/etc/kubernetes/admin.kubeconfig

kubectl config use-context kubernetes-admin@kubernetes  --kubeconfig=/etc/kubernetes/admin.kubeconfig
```

### 3.2.5创建kube-proxy证书

```shell
cfssl gencert \
   -ca=/etc/kubernetes/pki/ca.pem \
   -ca-key=/etc/kubernetes/pki/ca-key.pem \
   -config=ca-config.json \
   -profile=kubernetes \
   kube-proxy-csr.json | cfssljson -bare /etc/kubernetes/pki/kube-proxy

kubectl config set-cluster kubernetes     \
  --certificate-authority=/etc/kubernetes/pki/ca.pem     \
  --embed-certs=true     \
  --server=https://192.168.1.19:8443     \
  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig

kubectl config set-credentials kube-proxy  \
  --client-certificate=/etc/kubernetes/pki/kube-proxy.pem     \
  --client-key=/etc/kubernetes/pki/kube-proxy-key.pem     \
  --embed-certs=true     \
  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig

kubectl config set-context kube-proxy@kubernetes    \
  --cluster=kubernetes     \
  --user=kube-proxy     \
  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig

kubectl config use-context kube-proxy@kubernetes  --kubeconfig=/etc/kubernetes/kube-proxy.kubeconfig
```



### 3.2.5创建ServiceAccount Key ——secret

```shell
openssl genrsa -out /etc/kubernetes/pki/sa.key 2048
openssl rsa -in /etc/kubernetes/pki/sa.key -pubout -out /etc/kubernetes/pki/sa.pub
```

### 3.2.6将证书发送到其他master节点

```shell
#其他节点创建目录
# mkdir  /etc/kubernetes/pki/ -p

for NODE in k8s-master02 k8s-master03; do  for FILE in $(ls /etc/kubernetes/pki | grep -v etcd); do  scp /etc/kubernetes/pki/${FILE} $NODE:/etc/kubernetes/pki/${FILE}; done;  for FILE in admin.kubeconfig controller-manager.kubeconfig scheduler.kubeconfig; do  scp /etc/kubernetes/${FILE} $NODE:/etc/kubernetes/${FILE}; done; done
```

### 3.2.7查看证书

```shell
ls /etc/kubernetes/pki/
admin.csr          ca.csr                      front-proxy-ca.csr          kube-proxy.csr      scheduler-key.pem
admin-key.pem      ca-key.pem                  front-proxy-ca-key.pem      kube-proxy-key.pem  scheduler.pem
admin.pem          ca.pem                      front-proxy-ca.pem          kube-proxy.pem
apiserver.csr      controller-manager.csr      front-proxy-client.csr      sa.key
apiserver-key.pem  controller-manager-key.pem  front-proxy-client-key.pem  sa.pub
apiserver.pem      controller-manager.pem      front-proxy-client.pem      scheduler.csr

# 一共26个就对了

ls /etc/kubernetes/pki/ |wc -l
26
```


> **关于**
>
> https://www.oiox.cn/
>
> https://www.oiox.cn/index.php/start-page.html
>
> **CSDN、GitHub、知乎、开源中国、思否、掘金、简书、华为云、阿里云、腾讯云、哔哩哔哩、今日头条、新浪微博、个人博客**
>
> **全网可搜《小陈运维》**
>
> **文章主要发布于微信公众号：《Linux运维交流社区》**
【版权声明】本文为华为云社区用户原创内容，转载时必须标注文章的来源（华为云社区）、文章链接、文章作者等基本信息， 否则作者和本社区有权追究责任。如果您发现本社区中有涉嫌抄袭的内容，欢迎发送邮件进行举报，并提供相关证据，一经查实，本社区将立刻删除涉嫌侵权内容，举报邮箱： cloudbbs@huaweicloud.com
IPv6 Kubernetes Ubuntu
  • 点赞
  • 收藏
  • 关注作者

评论（0）

0/1000
抱歉，系统识别当前为高风险访问，暂不支持该操作

全部回复

上滑加载中

设置昵称

在此一键设置昵称，即可参与社区互动！

*长度不超过10个汉字或20个英文字符，设置后3个月内不可修改。

*长度不超过10个汉字或20个英文字符，设置后3个月内不可修改。

确认 取消

加入云驻计划，成为创作者

  • 华为云周边好礼
  • 免费体验产品
  • 特殊身份标识
  • 线下官方门票
  • 内部专家零距离
  • 与10000+优质创作者共同成长
立即加入
