Qt&Vtk-011-Cone6

DreamLife 发表于 2022/04/14 23:39:05 2022/04/14

【摘要】文章目录 Qt&Vtk-Cone61 代码搬运1.1 cone6.h1.2 cone6.cpp 2 运行效果3 知识点3.1 vtkBoxWidget ★ 源码 ★ ...

文章目录

Qt&Vtk-Cone6

Qt&Vtk-Cone6

今天我们又来搬运代码了，今天还是搞Cone，哈哈哈，已经是第六个Cone，不过这是最后一个了，还有点意思，先看看官方的例子。

1 代码搬运

1.1 cone6.h

#ifndef CONE6_H
#define CONE6_H

#include <QWidget>
#include <QTimer>
#include <QDebug>
#include <QString>
#include <QTextBrowser>
#include "QVTKOpenGLWidget.h"               //新版本，旧版QVTKWidget
#include "vtkAutoInit.h"

#include "vtkConeSource.h"
#include "vtkPolyDataMapper.h"
#include "vtkRenderer.h"
#include "vtkRenderWindow.h"
#include "vtkRenderWindowInteractor.h"
#include "vtkCamera.h"
#include "vtkActor.h"
#include "vtkCommand.h"
#include "vtkBoxWidget.h"
#include "vtkTransform.h"
#include "vtkInteractorStyleTrackballCamera.h"


namespace Ui {
class Cone6;
}




class vtkMyCallBack : public vtkCommand
{
public:
    static vtkMyCallBack *New()
    {
        return new vtkMyCallBack;
    }
    void Execute(vtkObject *caller, unsigned long eventId, void *callData) override;
};


class Cone6 : public QWidget
{
    Q_OBJECT

public:
    explicit Cone6(QWidget *parent = 0);
    ~Cone6();

    void startInteractor();

private:
    Ui::Cone6 *ui;


    vtkConeSource *cone = nullptr;

    vtkPolyDataMapper *mapper = nullptr;

    vtkActor *actor = nullptr;

    vtkRenderer *render = nullptr;

    vtkRenderWindowInteractor *iren = nullptr;

    vtkInteractorStyleTrackballCamera * style = nullptr;

    vtkBoxWidget *boxWidget = nullptr;

    vtkMyCallBack *callback = nullptr;

};

#endif // CONE6_H




  1
  2
  3
  4
  5
  6
  7
  8
  9
  10
  11
  12
  13
  14
  15
  16
  17
  18
  19
  20
  21
  22
  23
  24
  25
  26
  27
  28
  29
  30
  31
  32
  33
  34
  35
  36
  37
  38
  39
  40
  41
  42
  43
  44
  45
  46
  47
  48
  49
  50
  51
  52
  53
  54
  55
  56
  57
  58
  59
  60
  61
  62
  63
  64
  65
  66
  67
  68
  69
  70
  71
  72
  73
  74
  75
  76

1.2 cone6.cpp

#include "cone6.h"
#include "ui_cone6.h"

Cone6::Cone6(QWidget *parent) :
    QWidget(parent),
    ui(new Ui::Cone6)
{
    ui->setupUi(this);


    cone = vtkConeSource::New();
    cone->SetRadius(1);
    cone->SetResolution(20);
    cone->SetHeight(3);



    mapper = vtkPolyDataMapper::New();
    mapper->SetInputConnection(cone->GetOutputPort());



    actor = vtkActor::New();
    actor->SetMapper(mapper);


    render = vtkRenderer::New();
    render->AddActor(actor);
    render->SetBackground(0,0,1);


    ui->widget->GetRenderWindow()->AddRenderer(render);


    iren = vtkRenderWindowInteractor::New();
    iren->SetRenderWindow(ui->widget->GetRenderWindow());



    style = vtkInteractorStyleTrackballCamera::New();
    iren->SetInteractorStyle(style);


    boxWidget = vtkBoxWidget::New();
    boxWidget->SetInteractor(iren);
    boxWidget->SetPlaceFactor(1.25);

    boxWidget->SetProp3D(actor);
    boxWidget->PlaceWidget();


    callback = vtkMyCallBack::New();
    boxWidget->AddObserver(vtkCommand::InteractionEvent,callback);
    boxWidget->On();

    iren->Initialize();


}

Cone6::~Cone6()
{
    delete ui;
}

void Cone6::startInteractor()
{
    iren->Start();
}

void vtkMyCallBack::Execute(vtkObject *caller, unsigned long eventId, void *callData)
{
    vtkTransform *t = vtkTransform::New();
    vtkBoxWidget *widget = reinterpret_cast<vtkBoxWidget*>(caller);
    widget->GetTransform(t);
    widget->GetProp3D()->SetUserTransform(t);
    t->Delete();
}
