HMI-20-[刷新问题]解决界面刷新卡顿问题

先描述现象，就是我的这两个表转速表和速度表，他们按照正常的是同时开始转，完了再同时回到起点，但是呢，我在其他的电脑上实验的时候，发现会有不同步显现，特别明显。

所以，我担心是我的频繁刷新导致的，因为我的刷新频率太高了

每个表里面有两个定时器，定时10毫秒，每个定时器对应的操作里面都有updata这样等于我一个表每秒就要刷新100*100 次，两个表，同时刷新，那就是100*100*100*100 ，着个刷新频率可能真的是太高了，

剩下的呢，就是把原来的仪表的自检函数优化，增加线程，完美解决问题。但是目前的版本还是没有优化的版本，

看下修改后的代码吧，修改之前的改吗可以看前面的内容

      #ifndef TACHOMETER_H
      #define TACHOMETER_H
      #include <QWidget>
      #include <QPainter>
      #include <QPaintEvent>
      #include <QThread>
      class TachoThread :  public QThread
      {
          Q_OBJECT
      public:
         /**
       * @brief run
       * 重载线程函数
       */
         virtual void run();
      signals:
         void signal_selfInspection(int number);
         void signal_finished();
      private:
         int m_number = 0;
         bool flagDESC = false;
      };
      namespace Ui {
      class Tachometer;
      }
      class Tachometer : public QWidget
      {
          Q_OBJECT
      public:
         explicit Tachometer(QWidget *parent = 0);
          ~Tachometer();
         /**
       * @brief selfInspection
       * 转速表自检程序
       */
         void selfInspection();
         /**
       * @brief setTacho
       * @param tacho
       * 设置发动机转速0-8000 转速
       */
         void setTacho(int tacho = 0);
         /**
       * @brief setTemperature
       * @param temperatur
       * 设置温度
       */
         void setTemperature(int temperatur = 0);
      signals:
         /**
       * @brief signalSelfInspection
       * 自检完成信号
       */
         void signalSelfInspectionfinished();
      private:
         /**
       * @brief eventFilter
       * @param watched
       * @param event
       * @return
       * 事件过滤器器
       */
         bool eventFilter(QObject *watched, QEvent *event);
         /**
       * @brief drawPonter
       * @param angle
       * 绘制指针
       */
         void drawPonter(int angle = -135);
         /**
       * @brief drawPonterShade
       * @param angle
       * 绘制指针阴影
       */
         void drawPonterShade(int angle = -135);
         /**
       * @brief drawTemperature
       * @param temperature
       * 绘制温度表
       */
         void drawTemperature(int temperature = 0);
      private slots:
         /**
       * @brief slot_tachoSelfInspection
       * @param number
       * 完成自检动画
       */
         void slot_tachoSelfInspection(int number);
      public:
         int currentTacho = 0;           //当前转速
         int currentTemperature = 0;     //当前温度
      private:
          Ui::Tachometer *ui;
         int m_Angle = 0;            //转速表角度
         int m_Temperature = 0;
         double m_shadeOpacity = 0.0;    //指针阴影透明度
          TachoThread *m_tachoThread = NULL;
      };
      #endif // TACHOMETER_H




      #include "tachometer.h"
      #include "ui_tachometer.h"
      #include <QDebug>
      Tachometer::Tachometer(QWidget *parent) :QWidget(parent),ui(new Ui::Tachometer)
      {
          ui->setupUi(this);
          ui->label_mainback->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Tachometer/mainback.png);}");
          ui->label_flag_temperature->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Tachometer/temperature_r.png);}");
          ui->label_pointer->installEventFilter(this);
          ui->label_pointer_shade->installEventFilter(this);
          ui->label_pointer_temperature->installEventFilter(this);
          m_tachoThread = new TachoThread();
         connect(m_tachoThread,&TachoThread::signal_finished,this,[=](){m_tachoThread->terminate();});
         connect(m_tachoThread,&TachoThread::signal_selfInspection,this,&Tachometer::slot_tachoSelfInspection);
         setTacho();
      }
      Tachometer::~Tachometer()
      {
         delete ui;
      }
      void Tachometer::selfInspection()
      {
         if(m_tachoThread)
          {
              m_tachoThread->start();
          }
      }
      void Tachometer::setTacho(int tacho)
      {
          currentTacho = tacho;
          m_Angle = currentTacho*0.03375-135;
         update();
      }
      void Tachometer::setTemperature(int temperatur)
      {
          currentTemperature = temperatur;
          m_Temperature = temperatur;
         if(m_Temperature >75)
          {
              ui->label_flag_temperature->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Tachometer/temperature_r.png);}");
          }
         else
          {
              ui->label_flag_temperature->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Tachometer/temperature_w.png);}");
          }
         update();
      }
      bool Tachometer::eventFilter(QObject *watched, QEvent *event)
      {
         if(watched == ui->label_pointer && event->type() == QEvent::Paint)
          {
             drawPonter(m_Angle);
          }
         if(watched == ui->label_pointer_shade && event->type() == QEvent::Paint)
          {
             drawPonterShade(m_Angle);
          }
         if(watched == ui->label_pointer_temperature && event->type() == QEvent::Paint)
          {
             drawTemperature(m_Temperature);
          }
         return QWidget::eventFilter(watched,event);
      }
      void Tachometer::drawPonter(int angle)
      {
          m_shadeOpacity = currentTacho / 10000.0;
         QPainter painter(ui->label_pointer);
          painter.setRenderHint((QPainter::SmoothPixmapTransform));
          painter.setRenderHint(QPainter::HighQualityAntialiasing);
          painter.translate(304,303.5);
          painter.save();
          painter.rotate(angle);
          painter.drawPixmap(-304,-302,416,500,QPixmap(":/Comfort/Resources/MeterDisplay/Comfort/Tachometer/pointer.png"));
          painter.restore();
      }
      void Tachometer::drawPonterShade(int angle)
      {
         QPainter painter(ui->label_pointer_shade);
          painter.setOpacity(m_shadeOpacity);
          painter.setRenderHint((QPainter::SmoothPixmapTransform));
          painter.setRenderHint(QPainter::HighQualityAntialiasing);
          painter.translate(304,303.5);
          painter.save();
          painter.rotate(angle);
          painter.drawPixmap(-304,-302,416,500,QPixmap(":/Comfort/Resources/MeterDisplay/Comfort/Tachometer/pointer_shade.png"));
          painter.restore();
      }
      void Tachometer::drawTemperature(int temperature)
      {
         QPainter painter(ui->label_pointer_temperature);
          painter.setRenderHint((QPainter::SmoothPixmapTransform));
          painter.setRenderHint(QPainter::HighQualityAntialiasing);
          painter.translate(304,303.5);
          painter.setPen(QPen(Qt::white,6,Qt::SolidLine));
          painter.save();
         if(temperature<=25)
          {
              painter.drawArc(-304,-308,608,608,247*16,temperature*7);
          }
         else if(temperature>25 && temperature <= 50)
          {
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,(temperature-25)*7);
          }
         else if(temperature>50 && temperature <= 75)
          {
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,24*7);
              painter.drawArc(-304,-308,608,608,271*16,(temperature-50)*7);
          }
         else if(temperature>75 && temperature <= 90)
          {
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,24*7);
              painter.drawArc(-304,-308,608,608,271*16,24*7);
              painter.drawArc(-304,-308,608,608,283*16,(temperature-75)*7);
          }
         else if(temperature>90 && temperature <= 100)
          {
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,24*7);
              painter.drawArc(-304,-308,608,608,271*16,24*7);
              painter.drawArc(-304,-308,608,608,283*16,15*7);
              painter.setPen(QPen(Qt::red,6,Qt::SolidLine));
              painter.drawArc(-304,-308,608,608,290*16,(temperature-90)*7);
          }
          painter.restore();
      }
      void Tachometer::slot_tachoSelfInspection(int number)
      {
          currentTacho = number*80;
          m_Angle = number*80*0.03375-135;
         setTemperature(number);
      }
      void TachoThread::run()
      {
         while (true)
          {
             emit signal_selfInspection(m_number);
             if(flagDESC)
              {
                 if(m_number == 0)
                  {
                     emit signal_finished();
                      flagDESC = !flagDESC;
                  }
                  m_number--;
              }
             else
              {
                  m_number++;
                 if(m_number == 100)
                  {
                      flagDESC = !flagDESC;
                  }
              }
             msleep(10);
          }
      }




      #ifndef SPEEDMETER_H
      #define SPEEDMETER_H
      #include <QWidget>
      #include <QPainter>
      #include <QPaintEvent>
      #include <QThread>
      class SpeedThread :  public QThread
      {
          Q_OBJECT
      public:
         /**
       * @brief run
       * 重载线程函数
       */
         virtual void run();
      signals:
         void signal_selfInspection(int number);
         void signal_finished();
      private:
         int m_number = 0;
         bool flagDESC = false;
      };
      namespace Ui {
      class Speedmeter;
      }
      class Speedmeter : public QWidget
      {
          Q_OBJECT
      public:
         explicit Speedmeter(QWidget *parent = 0);
          ~Speedmeter();
         /**
       * @brief selfInspection
       * 转速表自检程序
       */
         void selfInspection();
         /**
       * @brief setCarSpeed
       * @param speed
       * 设置车速
       */
         void setCarSpeed(int speed = 0);
         /**
       * @brief setOilMass
       * @param mass
       * 设置油量
       */
         void setOilMass(int mass = 0);
      signals:
         /**
       * @brief speedChange
       * @param speed
       * 速度改变信号
       */
         void speedChange(int speed);
         /**
       * @brief signalSelfInspection
       * 自检完成信号
       */
         void signalSelfInspectionfinished();
      private:
         /**
       * @brief eventFilter
       * @param watched
       * @param event
       * @return
       * 事件过滤器器
       */
         bool eventFilter(QObject *watched, QEvent *event);
         /**
       * @brief drawPonter
       * @param angle
       * 绘制指针
       */
         void drawPonter(int angle = -135);
         /**
       * @brief drawPonterShade
       * @param angle
       * 绘制指针阴影
       */
         void drawPonterShade(int angle = -135);
         /**
       * @brief drawOilMass
       * @param mess
       * 绘制油量表
       */
         void drawOilMass(int mass = 0);
      private slots:
         /**
       * @brief slot_tachoSelfInspection
       * @param number
       * 完成自检动画
       */
         void slot_carSpeedSelfInspection(int number);
      public:
         int currentCarSpeed = 0;        //当前车速
         int currentMass = 0;            //当前油量
      private:
          Ui::Speedmeter *ui;
         int m_Angle = 0;            //速度角度
         double m_shadeOpacity = 0.0;    //指针阴影透明度
         int m_OilMass = 0;
          SpeedThread *m_speedThread = NULL;
      };
      #endif // SPEEDMETER_H




      #include "speedmeter.h"
      #include "ui_speedmeter.h"
      #include <QDebug>
      Speedmeter::Speedmeter(QWidget *parent) : QWidget(parent),ui(new Ui::Speedmeter)
      {
          ui->setupUi(this);
          ui->label_mainback->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Speedmeter/mainback.png);}");
          ui->label_flag_oilmass->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Speedmeter/oilmass_o.png);}");
          ui->label_pointer->installEventFilter(this);
          ui->label_pointer_shade->installEventFilter(this);
          ui->label_oilmass->installEventFilter(this);
          m_speedThread = new SpeedThread();
         connect(m_speedThread,&SpeedThread::signal_finished,this,[=](){m_speedThread->terminate();});
         connect(m_speedThread,&SpeedThread::signal_selfInspection,this,&Speedmeter::slot_carSpeedSelfInspection);
         setCarSpeed();
      }
      Speedmeter::~Speedmeter()
      {
         delete ui;
      }
      void Speedmeter::selfInspection()
      {
         if(m_speedThread)
          {
              m_speedThread->start();
          }
      }
      void Speedmeter::setCarSpeed(int speed)
      {
          currentCarSpeed = speed;
         emit speedChange(currentCarSpeed);
          m_Angle = currentCarSpeed*1.125-135;
         update();
      }
      void Speedmeter::setOilMass(int mass)
      {
         if(mass<=10)
          {
              ui->label_flag_oilmass->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Speedmeter/oilmass_o.png);}");
          }
         else
          {
              ui->label_flag_oilmass->setStyleSheet("QLabel{border-image:url(:/Comfort/Resources/MeterDisplay/Comfort/Speedmeter/oilmass_w.png);}");
          }
          m_OilMass = mass;
         update();
      }
      bool Speedmeter::eventFilter(QObject *watched, QEvent *event)
      {
         if(watched == ui->label_pointer && event->type() == QEvent::Paint)
          {
             drawPonter(m_Angle);
          }
         if(watched == ui->label_pointer_shade && event->type() == QEvent::Paint)
          {
             drawPonterShade(m_Angle);
          }
         if(watched == ui->label_oilmass && event->type() == QEvent::Paint)
          {
             drawOilMass(m_OilMass);
          }
         return QWidget::eventFilter(watched,event);
      }
      void Speedmeter::drawPonter(int angle)
      {
          m_shadeOpacity = currentCarSpeed / 300.0;
         QPainter painter(ui->label_pointer);
          painter.setRenderHint((QPainter::SmoothPixmapTransform));
          painter.setRenderHint(QPainter::HighQualityAntialiasing);
          painter.translate(305,303.5);
          painter.save();
          painter.rotate(angle);
          painter.drawPixmap(-304,-302,416,500,QPixmap(":/Comfort/Resources/MeterDisplay/Comfort/Speedmeter/pointer.png"));
          painter.restore();
      }
      void Speedmeter::drawPonterShade(int angle)
      {
         QPainter painter(ui->label_pointer_shade);
          painter.setOpacity(m_shadeOpacity);
          painter.setRenderHint((QPainter::SmoothPixmapTransform));
          painter.setRenderHint(QPainter::HighQualityAntialiasing);
          painter.translate(305,303.5);
          painter.save();
          painter.rotate(angle);
          painter.drawPixmap(-304,-302,416,500,QPixmap(":/Comfort/Resources/MeterDisplay/Comfort/Speedmeter/pointer_shade.png"));
          painter.restore();
      }
      void Speedmeter::drawOilMass(int mass)
      {
         QPainter painter(ui->label_oilmass);
          painter.setRenderHint((QPainter::SmoothPixmapTransform));
          painter.setRenderHint(QPainter::HighQualityAntialiasing);
          painter.translate(305,303.5);
          painter.setPen(QPen(Qt::white,6,Qt::SolidLine));
          painter.save();
         if(mass<=10)
          {
              painter.setPen(QPen(Qt::red,6,Qt::SolidLine));
              painter.drawArc(-304,-308,608,608,247*16,mass*7);
          }
         else if(mass>10 && mass<=25)
          {
              painter.setPen(QPen(Qt::white,6,Qt::SolidLine));
              painter.drawArc(-304,-308,608,608,247*16,mass*7);
          }
         else if(mass>25 && mass <= 50)
          {
              painter.setPen(QPen(Qt::white,6,Qt::SolidLine));
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,(mass-25)*7);
          }
         else if(mass>50 && mass <= 75)
          {
              painter.setPen(QPen(Qt::white,6,Qt::SolidLine));
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,24*7);
              painter.drawArc(-304,-308,608,608,271*16,(mass-50)*7);
          }
         else if(mass>75 && mass <= 100)
          {
              painter.setPen(QPen(Qt::white,6,Qt::SolidLine));
              painter.drawArc(-304,-308,608,608,247*16,24*7);
              painter.drawArc(-304,-308,608,608,259*16,24*7);
              painter.drawArc(-304,-308,608,608,271*16,24*7);
              painter.drawArc(-304,-308,608,608,283*16,(mass-75)*7);
          }
          painter.restore();
      }
      void Speedmeter::slot_carSpeedSelfInspection(int number)
      {
          m_OilMass = number;
         setCarSpeed(number*2.4);
      }
      void SpeedThread::run()
      {
         while (true)
          {
             emit signal_selfInspection(m_number);
             if(flagDESC)
              {
                 if(m_number == 0)
                  {
                     emit signal_finished();
                      flagDESC = !flagDESC;
                  }
                  m_number--;
              }
             else
              {
                  m_number++;
                 if(m_number == 100)
                  {
                      flagDESC = !flagDESC;
                  }
              }
             msleep(10);
          }
      }




2019/08/27 10:58



说明：

本项目中所使借鉴原型来自：[吉利] 博瑞GE | 仪表HMI设计、吉利汽车HMI项目。

设计图的所有权和解释权都归吉利汽车所有。

本项目所有资源文件均有打不死的小海复刻制作。

本项目代码暂时不会开源，有需要的源码的可与我联系，左上角二维码加微信。

本项目仅限学习交流、禁止商业使用。

文章来源: dreamlife.blog.csdn.net，作者：DreamLife.，版权归原作者所有，如需转载，请联系作者。

原文链接：dreamlife.blog.csdn.net/article/details/101363501
