【LiteOS】小白进阶之如何创建 LiteOS 任务（三）

1、任务结构体

      typedef struct tagTskInitParam
      {
         TSK_ENTRY_FUNC       pfnTaskEntry;               /**< Task entrance function               */
         UINT16               usTaskPrio;                 /**< Task priority                 */
         UINT32               auwArgs[4];                 /**< Task parameters, of which the maximum number is four          */
         UINT32               uwStackSize;                /**< Task stack size               */
         CHAR                 *pcName;                    /**< Task name                     */
         UINT32               uwResved;                   /**< Reserved. It is automatically deleted if set to LOS_TASK_STATUS_DETACHED. It is unable to be deleted if set to 0.*/
      } TSK_INIT_PARAM_S;



auwArgs：

是指任务入口参数，比如任务入口参数为 void Task1(UINT32 arg);

在创建任务时将xx.auwArgs[0]=0，在刚开始调取任务时就会将 0 传到 Task1 函数。

pcName：

任务名称，这个是不能给空的

uwResved：

这个并不是保留的，而是定义在任务执行完后要不要自删除，LOS_TASK_STATUS_DETACHED

2、任务创建

      UINT32 g_uwTskLoID;
      UINT32 g_uwTskHiID;
      #define TSK_PRIOR_HI 4
      #define TSK_PRIOR_LO 5



2.1、创建两个任务

创建任务时要锁任务调度。

      UINT32 Example_TskCaseEntry(VOID)
      {
        UINT32 uwRet;
        TSK_INIT_PARAM_S stInitParam;
        // 锁任务调度
        LOS_TaskLock();
        printf("LOS_TaskLock() Success!\r\n");
        stInitParam.pfnTaskEntry = (TSK_ENTRY_FUNC)Example_TaskHi;
        stInitParam.usTaskPrio = TSK_PRIOR_HI;
        stInitParam.pcName = "HIGH_NAME";
        stInitParam.uwStackSize = 0x400;
        stInitParam.uwResved   = LOS_TASK_STATUS_DETACHED;
        // 创建高优先级任务，由于锁任务调度，任务创建成功后不会马上执行
        uwRet = LOS_TaskCreate(&g_uwTskHiID, &stInitParam);
        if (uwRet != LOS_OK)
        {
            LOS_TaskUnlock();
            printf("Example_TaskHi create Failed!\r\n");
            return LOS_NOK;
        }
        printf("Example_TaskHi create Success!\r\n");
        stInitParam.pfnTaskEntry = (TSK_ENTRY_FUNC)Example_TaskLo;
        stInitParam.usTaskPrio = TSK_PRIOR_LO;
        stInitParam.pcName = "LOW_NAME";
        stInitParam.uwStackSize = 0x400;
        stInitParam.uwResved   = LOS_TASK_STATUS_DETACHED;
        /*创建低优先级任务，由于锁任务调度，任务创建成功后不会马上执行*/
        uwRet = LOS_TaskCreate(&g_uwTskLoID, &stInitParam);
        if (uwRet != LOS_OK)
        {
            LOS_TaskUnlock();
            printf("Example_TaskLo create Failed!\r\n");
            return LOS_NOK;
        }
        printf("Example_TaskLo create Success!\r\n");
        // 解锁任务调度，此时会发生任务调度，执行就绪列表中最高优先级任务
        LOS_TaskUnlock();
        while(1){};
        return LOS_OK;
      }



2.2、高优先级任务

      UINT32 Example_TaskHi()
      {
        UINT32 uwRet;
        UINT32 uwCurrentID;
        TSK_INFO_S stTaskInfo;
        printf("Enter TaskHi Handler.\r\n");
        // 延时 2 个 Tick，延时后该任务会挂起，执行剩余任务中最高优先级的任务(g_uwTskLoID任务)
        uwRet = LOS_TaskDelay(2);
        if (uwRet != LOS_OK)
        {
            printf("Delay Task Failed.\r\n");
            return LOS_NOK;
        }
        // 2 个 Tick 时间到了后，该任务恢复，继续执行
        printf("TaskHi LOS_TaskDelay Done.\r\n");
        // 挂起自身任务
        uwRet = LOS_TaskSuspend(g_uwTskHiID);
        if (uwRet != LOS_OK)
        {
            printf("Suspend TaskHi Failed.\r\n");
            return LOS_NOK;
        }
        printf("TaskHi LOS_TaskResume Success.\r\n");
      }



2.3、低优先级任务


      UINT32 Example_TaskLo()
      {
        UINT32 uwRet;
        UINT32 uwCurrentID;
        TSK_INFO_S stTaskInfo;
        printf("Enter TaskLo Handler.\r\n");
        // 延时2个Tick，延时后该任务会挂起，执行剩余任务中就高优先级的任务(背景任务)
        uwRet = LOS_TaskDelay(2);
        if (uwRet != LOS_OK)
        {
            printf("Delay TaskLo Failed.\r\n");
            return LOS_NOK;
        }
        printf("TaskHi LOS_TaskSuspend Success.\r\n");
        // 恢复被挂起的任务 g_uwTskHiID
        uwRet = LOS_TaskResume(g_uwTskHiID);
        if (uwRet != LOS_OK)
        {
            printf("Resume TaskHi Failed.\r\n");
            return LOS_NOK;
        }
        printf("TaskHi LOS_TaskDelete Success.\r\n");
      }
