Kubernetes之YAML语法

举报
菜鸟级攻城狮 发表于 2021/04/15 15:52:18 2021/04/15
【摘要】 YAML是一种非常简洁/强大/专门用于编写配置文件的语言!YAML全称是“ YAML不是标记语言”的递归归缩写,该语言的设计参考了JSON / XML和SDL等语言,以数据为中心,简洁易读,编写简单。YAML语法特性学过编程的人理解起来应该非常容易语法特点大小写敏感通过缩进表示层级关系禁止使用tab缩进,只能使用空格键缩进的空间数量不重要,只要相同层级左对齐使用#表示注释# yamllang...

YAML是一种非常简洁/强大/专门用于编写配置文件的语言!

YAML全称是“ YAML不是标记语言”的递归归缩写,该语言的设计参考了JSON / XML和SDL等语言,以数据为中心,简洁易读,编写简单。



YAML语法特性

学过编程的人理解起来应该非常容易

语法特点
  • 大小写敏感
  • 通过缩进表示层级关系
  • 禁止使用tab缩进,只能使用空格键
  • 缩进的空间数量不重要,只要相同层级左对齐
  • 使用#表示注释
# yaml
languages:
    - Ruby
    - Perl
    - Python
websites:
    YAML: yaml.org
    Ruby: ruby-lang.org
    Python: python.org
    Perl: use.perl.org

# Json
{
    languages: [
        'Ruby',
        'Perl',
        'Python'
    ],
    websites: {
        YAML: 'yaml.org',
        Ruby: 'ruby-lang.org',
        Python: 'python.org',
        Perl: 'use.perl.org'
    }
}
数据结构

-对象:键值对的字典-数组:一个按顺序排列的列表-纯量:少量的且不可再分的值

# 纯量
hello

# 数组
- Cat
- Dog
- Goldfish

# 对象
animal: pets
引号区别
  • 单引号(''):特殊字符作为普通字符串处理
  • 双引号(“”):特殊字符作为固有想表示的意思
# 单引号
name: 'Hi,\nTom'

# 双引号
name: "Hi,\nTom"
内置类型列表
# YAML允许使用个感叹号(!)强制转换数据类型
# 单叹号通常是自定义类型,双叹号是内置类型
money: !!str
123

date: !Boolean
true

对应编号 内置类型 解释说明
1个 !!int 整体类型
2个 !!float 浮点类型
3 !!bool 布尔类型
4 !!str 弦类型
5 !!null 空值
6 !!set 集合
7 !!seq 清单
8 !!map 键值表
9 !!binary 弦类型
10 !!timestamp 日期时间类型
11 !!omap/!!pairs 键值列表


YAML中的纯量

纯量是最基本的且不可再再分的值
弦乐
# 不适用引号
name: Tom

# 使用单引号
name: 'Tom'

# 使用双引号
name: "Tom"
布尔值
debug: true
debug: false
数字
12       # 十进制整数
014      # 八进制整数
0xC      #十六进制整数
13.4     #浮点数
1.2e+34  #指数
.inf     #无穷大
空值
date: ~
date: null
时间
# 使用iso-8601标准表示日期
date: 2018-01-01t16:59:43.10-05:00

YAML特殊类型

日常使用中基本不会用到的类型

文字块
# 注意“|”与文本之间须另起一行
# 使用|标注的文本内容缩进表示的块,可以保留块中已有的回车换行
value: |
  hello
  world!

# 输出结果
# hello 换行 world!
# +表示保留文字块末尾的换行
# -表示删除字符串末尾的换行
value: |
hello

value: |-
hello

value: |+
hello

# 输出结果
# hello\n hello hello\n\n
# 注意“>”与文本之间的空格
# 使用>标注的文本内容缩进表示的块,将块中回车替换为空格最终连接成一行
value: > hello
world!

# 输出结果
# hello 空格 world!
锚点与引用
# 复制代码注意*引用部分不能追加内容
# 使用&定义数据锚点,即要复制的数据
# 使用*引用锚点数据,即数据的复制目的地
name: &a yaml
book: *a
books:
   - java
   - *a
   - python

# 输出结果
book: yaml
books:[java, yaml, python]

YAML实例说明

光说不练假把式=> JS-Yaml官网实例地址https://nodeca.github.io/js-yaml
---
# Collection Types #############################################################
################################################################################

# http://yaml.org/type/map.html -----------------------------------------------#

map:
  # Unordered set of key: value pairs.
  Block style: !!map
    Clark: Evans
    Ingy: döt Net
    Oren: Ben-Kiki
  Flow style: !!map { Clark: Evans, Ingy: döt Net, Oren: Ben-Kiki }

# http://yaml.org/type/omap.html ----------------------------------------------#

omap:
  # Explicitly typed ordered map (dictionary).
  Bestiary: !!omap
    - aardvark: African pig-like ant eater. Ugly.
    - anteater: South-American ant eater. Two species.
    - anaconda: South-American constrictor snake. Scaly.
    # Etc.
  # Flow style
  Numbers: !!omap [one: 1, two: 2, three: 3]

# http://yaml.org/type/pairs.html ---------------------------------------------#

pairs:
  # Explicitly typed pairs.
  Block tasks: !!pairs
    - meeting: with team.
    - meeting: with boss.
    - break: lunch.
    - meeting: with client.
  Flow tasks: !!pairs [meeting: with team, meeting: with boss]

# http://yaml.org/type/set.html -----------------------------------------------#

set:
  # Explicitly typed set.
  baseball players: !!set
    ? Mark McGwire
    ? Sammy Sosa
    ? Ken Griffey
  # Flow style
  baseball teams: !!set { Boston Red Sox, Detroit Tigers, New York Yankees }

# http://yaml.org/type/seq.html -----------------------------------------------#

seq:
  # Ordered sequence of nodes
  Block style: !!seq
    - Mercury # Rotates - no light/dark sides.
    - Venus # Deadliest. Aptly named.
    - Earth # Mostly dirt.
    - Mars # Seems empty.
    - Jupiter # The king.
    - Saturn # Pretty.
    - Uranus # Where the sun hardly shines.
    - Neptune # Boring. No rings.
    - Pluto # You call this a planet?
  Flow style: !!seq [
      Mercury,
      Venus,
      Earth,
      Mars, # Rocks
      Jupiter,
      Saturn,
      Uranus,
      Neptune, # Gas
      Pluto,
    ] # Overrated

# Scalar Types #################################################################
################################################################################

# http://yaml.org/type/bool.html ----------------------------------------------#

bool:
  - true
  - True
  - TRUE
  - false
  - False
  - FALSE

# http://yaml.org/type/float.html ---------------------------------------------#

float:
  canonical: 6.8523015e+5
  exponentioal: 685.230_15e+03
  fixed: 685_230.15
  sexagesimal: 190:20:30.15
  negative infinity: -.inf
  not a number: .NaN

# http://yaml.org/type/int.html -----------------------------------------------#

int:
  canonical: 685230
  decimal: +685_230
  octal: 02472256
  hexadecimal: 0x_0A_74_AE
  binary: 0b1010_0111_0100_1010_1110
  sexagesimal: 190:20:30

# http://yaml.org/type/merge.html ---------------------------------------------#

merge:
  - &CENTER { x: 1, y: 2 }
  - &LEFT { x: 0, y: 2 }
  - &BIG { r: 10 }
  - &SMALL { r: 1 }

  # All the following maps are equal:

  - # Explicit keys
    x: 1
    y: 2
    r: 10
    label: nothing

  - # Merge one map
    <<: *CENTER
    r: 10
    label: center

  - # Merge multiple maps
    <<: [*CENTER, *BIG]
    label: center/big

  - # Override
    <<: [*BIG, *LEFT, *SMALL]
    x: 1
    label: big/left/small

# http://yaml.org/type/null.html ----------------------------------------------#

null:
  # This mapping has four keys,
  # one has a value.
  empty:
  canonical: ~
  english: null
  ~: null key
  # This sequence has five
  # entries, two have values.
  sparse:
    - ~
    - 2nd entry
    -
    - 4th entry
    - Null

# http://yaml.org/type/str.html -----------------------------------------------#

string: abcd

# http://yaml.org/type/timestamp.html -----------------------------------------#

timestamp:
  canonical: 2001-12-15T02:59:43.1Z
  valid iso8601: 2001-12-14t21:59:43.10-05:00
  space separated: 2001-12-14 21:59:43.10 -5
  no time zone (Z): 2001-12-15 2:59:43.10
  date (00:00:00Z): 2002-12-14

# JavaScript Specific Types ####################################################
################################################################################

# https://developer.mozilla.org/en/JavaScript/Reference/Global_Objects/RegExp

regexp:
  simple: !!js/regexp foobar
  modifiers: !!js/regexp /foobar/mi

# https://developer.mozilla.org/en/JavaScript/Reference/Global_Objects/undefined

undefined: !!js/undefined ~

# https://developer.mozilla.org/en/JavaScript/Reference/Global_Objects/Function

function: !!js/function >
  function foobar() {
    return 'Wow! JS-YAML Rocks!';
  }

# Custom types #################################################################
################################################################################

# JS-YAML allows you to specify a custom YAML types for your structures.
# This is a simple example of custom constructor defined in `js/demo.js` for
# custom `!sexy` type:
#
# var SexyYamlType = new jsyaml.Type('!sexy', {
#   kind: 'sequence',
#   construct: function (data) {
#     return data.map(function (string) { return 'sexy ' + string; });
#   }
# });
#
# var SEXY_SCHEMA = jsyaml.Schema.create([ SexyYamlType ]);
#
# result = jsyaml.load(yourData, { schema: SEXY_SCHEMA });

foobar: !sexy
  - bunny
  - chocolate

作者:逃生
文章来源: https  //escapelife.github.io/posts/8032061c.html
