【小程序】004 父子组件数据双向绑定
【摘要】 父子组件数据双向绑定 音乐小程序歌单组件的实现
以一个tabBar为例解释父子组件传值
实现自定义组件思维导图
理解父子组件传值有一定难度，小伙伴们可以尝试在白纸上默写父子传值的路径与方法
1、创建一个页面：
2、创建组件：
3、myComponent.json声明组件：
4、mypage.json声明使用组件
5、myComponent中配置组件wxml
6、myComponent中配置组件wxss
此处使用flex布局
.active：实现选中变红样式
7、myComponent中配置组件js
组件.js中是component对象
页面.js中是page对象
8、myPage.wxml中使用组件
9、myPage.js中处理逻辑
回到音乐小程序
下面我们进行歌单组件的实现
1、在页面playlist.json声明使用自定义组件“L-playlist”，且使用组件所处的相对路径
2、在页面playlist.js的data中存放歌单列表
比如：
playlist:[
{"_id":"08560c9e5d042a5c0174f1ca26f1d7b2","copywrier":"热门推荐","playCount":1.4641238e+06,"highQuality":false,"type":0.0,"canDislike":true,"name":"天气转热了，适合听点凉爽的歌。","alg":"cityLevel_unknow","createTime":{"$date":"2019-06-14T23:14:36.746Z"},"id":2.780381322e+09,"picUrl":"https://p2.music.126.net/Biky7TE4CtW6NjGuqoUKZg==/109951164041827987.jpg","trackCount":53.0},
{"_id":"08560c9e5d042a5c0174f1da7aa357aa","highQuality":false,"copywriter":"热门推荐","canDislike":true,"playCount":622822.6,"id":2.740107647e+09,"name":"「时空潜行」囿于昼夜的空想主义者","type":0.0,"alg":"cityLevel_unknow","createTime":{"$date":"2019-06-14T23:14:36.955Z"},"picUrl":"https://p2.music.126.net/Q0eS0avwGK04LufWM7qJug==/109951164116217181.jpg","trackCount":20.0},
{"_id":"08560c9e5d042a5c0174f1de21c7e79e","id":2.828842343e+09,"type":0.0,"name":"粤语情诗：与你听风声，观赏过夜星","picUrl":"https://p2.music.126.net/K9IcG8cU6v4_SwuQ_x2xMA==/109951164124604652.jpg","highQuality":false,"alg":"cityLevel_unknow","playCount":1.785097e+06,"trackCount":52.0,"copywriter":"热门推荐","canDislike":true,"createTime":{"$date":"2019-06-14T23:14:36.982Z"}},
{"_id":"08560c9e5d042a5d0174f1e67d1bb16f","playCount":7.719329e+06,"highQuality":false,"trackCount":950.0,"alg":"cityLevel_unknow","id":9.17794768e+08,"type":0.0,"name":"翻唱简史：日本四百首","canDislike":true,"createTime":{"$date":"2019-06-14T23:14:37.037Z"},"copywriter":"热门推荐","picUrl":"https://p2.music.126.net/NczCuurE5eVvObUjssoGjQ==/109951163788653124.jpg"},
{"_id":"08560c9e5d042a5d0174f1ea32c4c288","type":0.0,"copywriter":"热门推荐","highQuality":false,"createTime":{"$date":"2019-06-14T23:14:37.097Z"},"id":2.201879658e+09,"alg":"cityLevel_unknow","playCount":1.06749088e+08,"name":"你的青春里有没有属于你的一首歌？","picUrl":"https://p2.music.126.net/wpahk9cQCDtdzJPE52EzJQ==/109951163271025942.jpg","canDislike":true,"trackCount":169.0},
{"_id":"08560c9e5d0829820362a79f4b049d2d","alg":"cityLevel_unknow","name":"「乐队的夏天」参赛歌曲合集丨EP04更新","highQuality":false,"picUrl":"http://p2.music.126.net/2WE5C2EypEwLJd2qXFd4cw==/109951164086686815.jpg","trackCount":158.0,"createTime":{"$date":"2019-06-18T00:00:02.553Z"},"copywriter":"热门推荐","playCount":1.5742008e+06,"canDislike":true,"id":2.79477263e+09,"type":0.0}
]
3、在页面playlist.wxml中使用block对L-playlist进行wx遍历
4、在组件playlist.wxml中填好固定样式，并通过绑定组件playlist.js中properties的内容
<!-- 歌单列表 -->
<view class="play-container">
<block wx:for="{{playlist}}" wx:key="_id">
<L-playlist playlist="{{item}}"></L-playlist>
</block>
</view>
5、组件playlist.js中properties的内容用于存放从页面playlist.js通过属性=“值”传递过来的内容，注意要声明存放内容类型type:Object,其中value:{}是无任何操作下的默认值
properties: {
playlist:{
type:Object,
value:{}
}
},
6、用定位做右上角的听歌数目，注意耳机图片其实是使用背景图background，小程序中背景图目前不允许使用网络图片，需要使用小程序本地的图片，我们可以将图片转变为base64格式，再放入url中。有些background会重复，使用样式去重
background-repeat: no-repeat;
图片转变为base64格式网站：https://c.runoob.com/front-end/59
7、wxss样式
组件样式负责一个图片框架样式
.playlist-container{
width: 220rpx;
position: relative;
padding-bottom: 20rpx;
}
.playlist-image{
width: 100%;
height: 220rpx;
border-radius: 6rpx;
}
.playlist-playcount{
font-size: 24rpx;
color:#fff;
text-shadow: 1px 0 0 rgba(0, 0,0,0.15)
position： absolute;
right: 10rpx;
top: 4rpx;
padding-left: 26rpx;
}
.playlist-name{
font-size: 26rpx;
line-height: 1.2;
padding: 2px 0 0 6px;
display: -webkit-box;
-webkit-box-orient: vertical;
-webkit-line-clamp: 2;
overflow: hidden;
text-overflow: ellipsis;
}
如果歌单图片下面的文字过长，可以使用-webkit-box将过长的内容隐藏并以...代替
-webkit-box-orient: vertical决定从顶部向底部垂直布置子元素
-webkit-line-clamp决定超出第几行开始隐藏文字
组件样式负责多个图片框架整体排版
.playlist-container{
display: flex;
flex-wrap: wrap;
justify-content: space-around;
margin-top: 10rpx;
flex-direction: row;
}
注意：tabBar组件例子参考自黑马教程，此处用来学习
