Fragment  VS  Activity

Android是在Android 3.0 (API level 11)开始引入Fragment的。

  可以把Fragment想成Activity中的模块,这个模块有自己的布局,有自己的生命周期,单独处理自己的输入,在Activity运行的时候可以加载或者移除Fragment模块。

  可以把Fragment设计成可以在多个Activity中复用的模块。

  当开发的应用程序同时适用于平板电脑和手机时,可以利用Fragment实现灵活的布局,改善用户体验。

  如图:


 Fragment的生命周期

  因为Fragment必须嵌入在Acitivity中使用,所以Fragment的生命周期和它所在的Activity是密切相关的。

  如果Activity是暂停状态,其中所有的Fragment都是暂停状态;如果Activity是stopped状态,这个Activity中所有的Fragment都不能被启动;如果Activity被销毁,那么它其中的所有Fragment都会被销毁。

  但是,当Activity在活动状态,可以独立控制Fragment的状态,比如加上或者移除Fragment。

  当这样进行fragment transaction(转换)的时候,可以把fragment放入Activity的back stack中,这样用户就可以进行返回操作。

Fragment的使用相关

  使用Fragment时,需要继承Fragment或者Fragment的子类(DialogFragment, ListFragment, PreferenceFragment, WebViewFragment),所以Fragment的代码看起来和Activity的类似。



使用Support Library

  Support Library是一个提供了API库函数的JAR文件,这样就可以在旧版本的Android上使用一些新版本的APIs。

  比如android-support-v4.jar.它就提供了Fragment的APIs,使得在Android 1.6 (API level 4)以上的系统都可以使用Fragment。

  为了确定没有在旧版本系统上使用新版本的APIs,需要如下导入语句:



  import android.support.v4.app.Fragment;



  import android.support.v4.app.FragmentManager;



  同时应该将上述的包拷入libs项目下的libs文件夹,然后在项目的Properties中添加:右键单击项目,选Properties,左边选Java Build Path,然后Add External JARs…,添加android-support-v4.jar.



  当创建包含Fragment的Activity时,如果用的是Support Library,那么继承的就应该是FragmentActivity而不是Activity。



  onCreate()



  系统在创建Fragment的时候调用这个方法,这里应该初始化相关的组件,一些即便是被暂停或者被停止时依然需要保留的东西。



  onCreateView()



  当第一次绘制Fragment的UI时系统调用这个方法,必须返回一个View,如果Fragment不提供UI也可以返回null。



  注意,如果继承自ListFragment,onCreateView()默认的实现会返回一个ListView,所以不用自己实现。



onPause()



  当用户离开Fragment时第一个调用这个方法,需要提交一些变化,因为用户很可能不再返回来。





实现Fragment的UI



  提供Fragment的UI,必须实现onCreateView()方法。

  假设Fragment的布局设置写在example_fragment.xml资源文件中,那么onCreateView()方法可以如下写:



public static class ExampleFragment extends Fragment

{

    @Override

    public View onCreateView(LayoutInflater inflater, ViewGroup container,

  Bundle savedInstanceState)

    {

        // Inflate the layout for this fragment

        return inflater.inflate(R.layout.example_fragment, container, false);

    }



  onCreateView()中container参数代表该Fragment在Activity中的父控件;savedInstanceState提供了上一个实例的数据。



  inflate()方法的三个参数:



  第一个是resource ID,指明了当前的Fragment对应的资源文件;



  第二个参数是父容器控件;



  第三个布尔值参数表明是否连接该布局和其父容器控件,在这里的情况设置为false,因为系统已经插入了这个布局到父控件,设置为true将会产生多余的一个View Group。



把Fragment加入Activity

  当Fragment被加入Activity中时,它会处在对应的View Group中。

  Fragment有两种加载方式:一种是在Activity的layout中使用标签<fragment>声明;另一种方法是在代码中把它加入到一个指定的ViewGroup中。

  另外,Fragment它可以并不是Activity布局中的任何一部分,它可以是一个不可见的部分。这部分内容先略过。

加载方式1:通过Activity的布局文件将Fragment加入Activity



  在Activity的布局文件中,将Fragment作为一个子标签加入即可。如:

<?xml version="1.0" encoding="utf-8"?>

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"

    android:orientation="horizontal"

    android:layout_width="match_parent"

    android:layout_height="match_parent">

    <fragment android:name="com.example.news.ArticleListFragment"

            android:id="@+id/list"

            android:layout_weight="1"

            android:layout_width="0dp"

            android:layout_height="match_parent" />

    <fragment android:name="com.example.news.ArticleReaderFragment"

            android:id="@+id/viewer"

            android:layout_weight="2"

            android:layout_width="0dp"

            android:layout_height="match_parent" />

</LinearLayout>

  其中android:name属性填上你自己创建的fragment的完整类名。

  当系统创建这个Activity的布局文件时,系统会实例化每一个fragment,并且调用它们的onCreateView()方法,来获得相应fragment的布局,并将返回值插入fragment标签所在的地方。

  有三种方法为Fragment提供ID:

  android:id属性:唯一的id

  android:tag属性:唯一的字符串



  如果上面两个都没提供,系统使用容器view的ID。





加载方式2:通过编程的方式将Fragment加入到一个ViewGroup中

  当Activity处于Running状态下的时候,可以在Activity的布局中动态地加入Fragment,只需要指定加入这个Fragment的父View Group即可。

  首先,需要一个FragmentTransaction实例:



FragmentManager fragmentManager = getFragmentManager()



FragmentTransaction fragmentTransaction = fragmentManager.beginTransaction();



 (注:如果import android.support.v4.app.FragmentManager;那么使用的是:FragmentManager fragmentManager = getSupportFragmentManager();)



  之后,用add()方法加上Fragment的对象:



ExampleFragment fragment = new ExampleFragment();



fragmentTransaction.add(R.id.fragment_container, fragment);



fragmentTransaction.commit();



  其中第一个参数是这个fragment的容器,即父控件组。



  最后需要调用commit()方法使得FragmentTransaction实例的改变生效。

文章来源: shq5785.blog.csdn.net,作者:No Silver Bullet,版权归原作者所有,如需转载,请联系作者。

原文链接:shq5785.blog.csdn.net/article/details/46494489
