matplotlib scatter 绘制散点图

x [19  5 16 17  0  2  9 12  5 19  8  9  1 16  7]
y [16  9  6 17  5  4 10  6  4 14  5 10  3  2  7]
y_ticks [ 0  1  2  3  4  5  6  7  8  9 10 11 12 13 14 15 16 17 18 19 20]

help(plt.scatter)

Help on function scatter in module matplotlib.pyplot:

scatter(x, y, s=None, c=None, marker=None, cmap=None, norm=None, vmin=None, vmax=None, alpha=None, linewidths=None, verts=None, edgecolors=None, hold=None, data=None, **kwargs)
    Make a scatter plot of `x` vs `y`.

    Marker size is scaled by `s` and marker color is mapped to `c`.

    Parameters
    ----------
    x, y : array_like, shape (n, )
        Input data

    s : scalar or array_like, shape (n, ), optional
        size in points^2.  Default is `rcParams['lines.markersize'] ** 2`.

    c : color, sequence, or sequence of color, optional, default: 'b'
        `c` can be a single color format string, or a sequence of color
        specifications of length `N`, or a sequence of `N` numbers to be
        mapped to colors using the `cmap` and `norm` specified via kwargs
        (see below). Note that `c` should not be a single numeric RGB or
        RGBA sequence because that is indistinguishable from an array of
        values to be colormapped.  `c` can be a 2-D array in which the
        rows are RGB or RGBA, however, including the case of a single
        row to specify the same color for all points.

    marker : `~matplotlib.markers.MarkerStyle`, optional, default: 'o'
        See `~matplotlib.markers` for more information on the different
        styles of markers scatter supports. `marker` can be either
        an instance of the class or the text shorthand for a particular
        marker.

    cmap : `~matplotlib.colors.Colormap`, optional, default: None
        A `~matplotlib.colors.Colormap` instance or registered name.
        `cmap` is only used if `c` is an array of floats. If None,
        defaults to rc `image.cmap`.

    norm : `~matplotlib.colors.Normalize`, optional, default: None
        A `~matplotlib.colors.Normalize` instance is used to scale
        luminance data to 0, 1. `norm` is only used if `c` is an array of
        floats. If `None`, use the default :func:`normalize`.

    vmin, vmax : scalar, optional, default: None
        `vmin` and `vmax` are used in conjunction with `norm` to normalize
        luminance data.  If either are `None`, the min and max of the
        color array is used.  Note if you pass a `norm` instance, your
        settings for `vmin` and `vmax` will be ignored.

    alpha : scalar, optional, default: None
        The alpha blending value, between 0 (transparent) and 1 (opaque)

    linewidths : scalar or array_like, optional, default: None
        If None, defaults to (lines.linewidth,).

    verts : sequence of (x, y), optional
        If `marker` is None, these vertices will be used to
        construct the marker.  The center of the marker is located
        at (0,0) in normalized units.  The overall marker is rescaled
        by ``s``.

    edgecolors : color or sequence of color, optional, default: None
        If None, defaults to 'face'

        If 'face', the edge color will always be the same as
        the face color.

        If it is 'none', the patch boundary will not
        be drawn.

        For non-filled markers, the `edgecolors` kwarg
        is ignored and forced to 'face' internally.

    Returns
    -------
    paths : `~matplotlib.collections.PathCollection`

    Other Parameters
    ----------------
    **kwargs : `~matplotlib.collections.Collection` properties

    See Also
    --------
    plot : to plot scatter plots when markers are identical in size and
        color

    Notes
    -----

    * The `plot` function will be faster for scatterplots where markers
      don't vary in size or color.

    * Any or all of `x`, `y`, `s`, and `c` may be masked arrays, in which
      case all masks will be combined and only unmasked points will be
      plotted.

      Fundamentally, scatter works with 1-D arrays; `x`, `y`, `s`, and `c`
      may be input as 2-D arrays, but within scatter they will be
      flattened. The exception is `c`, which will be flattened only if its
      size matches the size of `x` and `y`.

    .. note::
        In addition to the above described arguments, this function can take a
        **data** keyword argument. If such a **data** argument is given, the
        following arguments are replaced by **data[<arg>]**:

        * All arguments with the following names: 'c', 'color', 'edgecolors', 'facecolor', 'facecolors', 'linewidths', 's', 'x', 'y'.
